Edelbrock 71836 Installation Instructions

Please read both your DIRECT PORT INSTRUCTION MANUAL and this JET MAP insert before installing your Edelbrock Nitrous
System. If you have any questions or comments, please feel free to contact our Technical Hotline at: 1-800-416-8628 from 7a.m.-
5p.m., Monday through Friday, Pacific Time or e-mail us at Edelbrock@Edelbrock.com.
Qty. Description
❑ 1
❑ 1
❑ 4
❑ 8
❑ 8
❑ 4
©2005 Edelbrock Corporation
Brochure #63-0410

BILL OF MATERIALS (Excluding Electrical)

Performer RPM Nitrous Solenoid
Performer RPM Fuel Solenoid
Edelbrock E1 Nozzles
3/16" Tubing
Tube Sleeves
Blue Tube Nuts
Approx. HP Gain Nitrous Jet
100 HP 22
150 HP 28
200 HP 34
250 HP 38
This jet map is based on a nitrous system with a flowing fuel pressure
of 6.5 PSI. Any variations different than 6.5 PSI will change your jet map
and potentially damage your engine. We highly recommend using the
Edelbrock Flow Test Tool (Catalog #76506) to set your flowing fuel
pressure.
Edelbrock Corporation • 2700 California St. • Torrance • CA 90503
Tech Line: 800-416-8628
E-Mail: Edelbrock@Edelbrock.com
SUPER VICTOR I4 DIRECT PORT WITH E1 JET MAP
Qty.
❑ 4
❑ 8
❑ 2
❑ 2
❑ 1
❑ 1
❑ 28

Jet Map

Fuel Jet Sugg. Timing Retard
26
32
38
42
Office: 310-781-2222
EDELBROCK NITROUS SYSTEMS
INSTALLATION INSTRUCTIONS
Description
Red Tube Nuts
Compression Fittings
Distribution Blocks
90° Union Fittings
6AN Nitrous Filter Fitting
6AN Red Fuel Fitting
Various Jets
1°-3°
2°-4°
3°-5°
4°-6°
CATALOG #71836
Catalog #71836
Rev. 06/05 - DC/mc
