Edelbrock dodge viper heat shields installation instructions for 1992-1999 roadster & 1996-1999 coupe

Advertisement

Please study these instructions carefully before installing your new heat shield. If you have any questions, please contact
our Technical Hotline at : 1-800-416-8628 from 7 am – 5 pm, Monday through Friday, Pacific Standard Time or e-mail
us at Edelbrock@Edelbrock.com. Please fill out and mail your warranty card.
WHEN BEING INSTALLED ON VEHICLES WITH
EDELBROCK T.E.S. #66062:
RIGHT SIDE:
1. Remove top of heater blower box from lower heater
box assembly in engine compartment.
2. Remove the bolts from the coolant reservoir so it can
be moved around.
3. Disconnect spark plug wires from spark plugs and
move out of the way.
4. Loosen the 2nd and 4th upper header flange bolts
for mounting bracket installation.
5. Install one mounting bracket on each of the two
header flange bolts loosened in Step 4. Position the
brackets so that the slot on the end is straight down
under the bolt and bracket is flat on top. These
brackets will angle forward and down slightly when
installed properly.
NOTE: Before attempting to install the heat shield
onto the brackets, first measure the distance
between the threaded holes in the mounting
brackets. You should have 9 1/8" from center to
center of holes. If you don't, you can bend the
brackets with a pair of pliers or a small hammer.
Doing this will make heat shield installation much
easier.
6. Install the right side heat shield by angling the front
edge of the heat shield down toward the front half of
the header and slipping it forward between the
header and the coolant reservoir and hose. Once it
©2006 Edelbrock Corporation
Catalog #6700
For 1992-1999 Roadster & 1996-1999 Coupe

INSTALLATION INSTRUCTIONS

7. After you have tightened the heat shield to the
8. Re-install plug wires onto spark plug.
9. Re-install bolts for coolant reservoir bottle. Use
10. Re-install top half of heater blower box.
LEFT SIDE:
1. Disconnect spark plug wires from spark plugs and
move out of the way.
2. Loosen the 2nd and 4th upper header flange bolts
for mounting bracket installation.
Page 1 of 2
Dodge Viper Heat Shields
INSTALLATION INSTRUCTIONS
is down on top of the brackets, slide it toward the
rear of the car, align holes and install supplied bolts
and lock washers.
NOTE: We recommend you use a small amount of
high heat silicone R.T.V. on the top surface of the
mounting bracket to help to keep the shield from
rattling against the mounting brackets.
mounting brackets, tap on the shield to see if you
have rattles. To eliminate rattles, you can: (1) adjust
the shield at the mounting points "slotted holes", (2)
bend the heat shield as needed for clearance, (3)
bend mounting brackets slightly for a better fit on
your vehicle.
NOTE: Spark plug boots, wires and hose should not
contact the sharp edges of the heat shield as they
can be damaged.
plastic ties and hose holder provided in kit as
needed to hold coolant hose away from sharp edges
of heat shield.
Catalog #6700
Brochure #63-6700
Rev. 5/06 - DA/mc
