- Page 1 STEREO INTEGRATED AMPLIFIER KAF-3030R KAF-1030 INSTRUCTION MANUAL KENWOOD CORPORATION B60-4527-08 (EN)
-
Page 2: Before Applying Power
Before applying power Caution: Read this page carefully to ensure safe operation. KAF-3030R/1030 (En) Units are designed for operation as follows. Europe and UK ................ AC 230 V only Safety precautions WARNING : TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. -
Page 3: Table Of Contents
KAF-3030R/1030 (En) Special features Adv. DA / CD DIRECT (KAF-3030R only) The Advanced Digital Audio/CD input combined with a “direct” function. This feature allows this amplifier to achieve the highest quality of performance when used with the latest genera- tion of CD (HDCD/SACD) Players or DVD (96/192 kHz 24 bit) Audio Players. SOURCE DIRECT Lets you enjoy high quality sound from the music source selected by the INPUT SELECTOR. - Page 4 Caution: Read this page carefully to ensure IMPORTANT SAFEGUARDS safe operation. KAF-3030R/1030 (En) Please read all of the safety and operating instructions 6. Temperature – The appliance may not function properly before operating this appliance. Adhere to all warnings on the if used at extremely low, or freezing temperatures.
- Page 5 Caution: Read this page carefully to ensure safe operation. KAF-3030R/1030 (En) 13.Lightning – For added protection for this appliance during a 18.Power lines – An outside antenna system should not be lightning storm, or when it is left unattended and unused for located in the vicinity of overhead power lines or other electric long periods of time, unplug it from the wall outlet and light or power circuits, or where it can fall into such power lines...
- Page 6 SWITCHED TOTAL AC 230V SPEAKERS 100W MAX. 200W MAX. (A or B : 4–16 , A and B : 8–16 ) 50Hz 150W KENWOOD CORPORATION MADE IN KOREA Audio cords System control cord Tuner PLAY OUT System control cord REC IN...
-
Page 7: The System Control Connections (Kaf-3030R Only)
3. Do not connect system control cords to any components other than those speci- fied by KENWOOD. It may cause a malfunction and damage your equipment. 4. Be sure the system control plugs are inserted all the way in to the system control terminals. -
Page 8: Connection Of Speakers
KAF-3030R/1030 (En) Connection of speakers Connect the speakers as shown below, ensuring that bare wires do not make contact with other terminals. 1 Strip coating. Speaker system A LEFT RIGHT ª · · ª 2 Loosen. SIGNAL SYSTEM TAPE MD/CD-R Adv. -
Page 9: Main Unit
Controls and indicators KAF-3030R/1030 (En) Main unit KAF-1030 KAF-1030 KAF-1030 INPUT SELECTOR TAPE TUNER PHONO POWER MUTE LOUDNESS SOURCE DIRECT / CD-R KAF-3030R STEREO INTEGRATED AMPLIFER VOLUME CONTROL STANDBY INPUT SELECTOR TAPE POWER TUNER PHONO Adv. DA / CD SOURCE DIRECT SPEAKERS BASS... -
Page 10: Remote Control Unit (Kaf-3030R Only)
(KAF-3030R only) part of the illustration designates keys that can be used to operate KENWOOD components connected with the system control. The rest of the illustration designates keys that have the same functions as the keys on the main unit. -
Page 11: Loading Batteries
Operation of remote control unit (KAF-3030R only) KAF-3030R/1030 (En) Loading batteries Remove the cover......................... Insert batteries. • Insert two AA-size (R6/SUM-3) batteries as indicated by the po- larity marking......................... Close the cover. Operation procedure Pressing the POWER key on the remote control when the standby indicator is lit turns ON the power. -
Page 12: Normal Playback
Playing music KAF-3030R/1030 (En) The figure shows an example for the KAF-3030R. KAF-3030R KAF-1030 Preparation STANDBY ¢ ¡ POWER DISC SKIP POWER TAPE ¶ ¡ ¢ TUNER ¶ fi P.CALL TUNER Adv. DA/CD MUTE TAPE PHONO VOLUME CONTROL SOURCE DIRECT •... -
Page 13: To Mute Sound Temporarily
Sound adjustment functions KAF-3030R/1030 (En) The figure shows an example for the KAF-3030R. ¢ ¡ DISC SKIP TAPE ¶ ¡ ¢ TUNER ¶ fi P.CALL TUNER Adv. DA/CD MUTE TAPE PHONO VOLUME CONTROL SOURCE DIRECT Adv. DA/CD fi POWER DIRECT STEREO INTEGRATED AMPLIFER KAF-3030R VOLUME CONTROL... -
Page 14: Listening To High Quality Sound From Advanced Digital Audio Music Source (Adv. Da / Cd Direct) (Kaf-3030R Only)
Sound adjustment functions KAF-3030R/1030 (En) The figure shows an example for the KAF-3030R. ¢ ¡ DISC SKIP TAPE ¶ ¡ ¢ TUNER ¶ fi P.CALL TUNER Adv. DA/CD MUTE TAPE PHONO VOLUME SOURCE CONTROL DIRECT Adv. DA/CD POWER fi KAF-3030R DIRECT STEREO INTEGRATED AMPLIFER VOLUME CONTROL... -
Page 15: To Record A Music Source
Recording KAF-3030R/1030 (En) The figure shows an example for the KAF-3030R. ¢ ¡ DISC SKIP TAPE ¶ ¡ ¢ TUNER ¶ fi P.CALL TUNER Adv. DA/CD MUTE TAPE PHONO VOLUME SOURCE CONTROL DIRECT Adv. DA/CD fi POWER DIRECT STEREO INTEGRATED AMPLIFER KAF-3030R VOLUME CONTROL STANDBY... - Page 16 • When this unit is connected to a KENWOOD tuner with the RDS EON function using a system control cord, the input of this unit automatically switches to the tuner when the tuner receives a desired program in the EON reservation mode.
- Page 17 Weight (net) ..............7.2 kg Dimensions ............W: 440 mm H: 95 mm D: 400 mm Weight (net) ..............7.8 kg 1. KENWOOD follows a policy of continuous advancements in development. For this reason specifications may be changed without notice. Notes Notes Notes...
- Page 18 KAF-3030R/1030 (En) For your records Record the serial number, found on the back of the unit, in the spaces designated on the warranty card, and in the space provided below. Refer to the model and serial numbers whenever you call upon your dealer for information or service on this product.
