Contemporary Research ICC-HE Product Manual

Head-end network controller
Hide thumbs Also See for ICC-HE:

Advertisement

Quick Links

Product Manual
ICC-HE
Head-End Network Controller
Ver. 3.1 June 27, 2007
17630 Davenport Road, Suite 113 • Dallas, TX 75252
Phone:972-931-2728 • Toll-Free: 888-972-2728 • Fax: 972-931-2765
E-Mail:
Sales@crwww.com
• Website: www.crwww.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ICC-HE and is the answer not in the manual?

Questions and answers

Summary of Contents for Contemporary Research ICC-HE

  • Page 1 Product Manual ICC-HE Head-End Network Controller Ver. 3.1 June 27, 2007 17630 Davenport Road, Suite 113 • Dallas, TX 75252 Phone:972-931-2728 • Toll-Free: 888-972-2728 • Fax: 972-931-2765 E-Mail: Sales@crwww.com • Website: www.crwww.com...
  • Page 2: Table Of Contents

    RS-232 Device Response ........................18 iC-Net SmartZones..........................20 System Map ............................21 Typical RF and ICC-Net Signal Flow ....................22 Safety Instructions ........................... 23 Limited Warranty and Disclaimer ..................... 24 RF Channel Frequencies ........................25 Contemporary Research ICC-HE Head End...
  • Page 3: Overview

    Employs new S12-series processing, offering software-upgradeable firmware and improved operation New Features (3.1) • New Check RF Levels (AR–page 8) command measures the level of background RF at 5.6MHz, sends a reply that stated background RF level and current RF sensitivity setting. Contemporary Research ICC-HE Head End...
  • Page 4: Specifications

    Red LED indicates a problem within the unit Reset/Default: White button sends press and release RS-232 response to PC software or control system Emergency: Red button sends press and release RS-232 response to PC software or control system Contemporary Research ICC-HE Head End...
  • Page 5: Control Connections

    1: 6-pin captive-screw terminal for system wiring or use with RS-422/485-format fiber or codecs iC-Net Expand RJ-11 female 6-pin Telco jack Recommended Wire: CAT5/CAT3 compatible unshielded, max 3,300 feet [1 Km] from Head End Contemporary Research ICC-HE Head End...
  • Page 6: Icc-Net Connections

    11 to 18 VDC, 12 VDC typical, 300 mA maximum (may be unregulated) UL/CSA listed wall power supply (included for domestic 110 VAC/60 Hz shipments only) Includes 10 dB RF attenuator 12 VDC Power Supply Contemporary Research ICC-HE Head End...
  • Page 7: Installation

    In other applications, the I/O ports can act as closure outputs, activating an external power relay, 2x1 video switcher or other device. You’ll have to choose application – the ports act as either an output or input, not both. See Control Connections on page 4 for wiring and rating information Contemporary Research ICC-HE Head End...
  • Page 8: Rs-232 Terminal Commands

    (DIP Switch 1, page 4). Test the RF receive level a few times when the iC-Net units are not transmitting, then again when one iC-Net unit is set to constantly transmit. The Sensitivity level should fall about halfway between quiet and constant transmit RF levels. Contemporary Research ICC-HE Head End...
  • Page 9: Rs-232 Control Protocol

    <ncb> parameters are set apart by [ ] brackets • Commas separate the bytes, but are not part of the protocol • Double quotes enclose the command string, but are not part of the protocol Contemporary Research ICC-HE Head End...
  • Page 10: Rs-232 He Commands

    “$A5,0,0,3, ‘Y20’” turns Closure 2 off “$A5,0,0,3, ‘Y21’” turns Closure 2 on Device Status "$A5,0,0,2,'SP'" (6 bytes) Queries the Head-End for the number of devices present on the network and the number of devices expected. Contemporary Research ICC-HE Head End...
  • Page 11: Rs-232 Controller Commands

    The following commands summarize RS-232 commands to iC-Net controllers. There is a high degree of compatibility between Contemporary Research devices; most commands execute a similar action or response in nearly all units. Refer to each unit’s Product Manual for specific programming information.
  • Page 12: Audio Commands

    Mono/Stereo S7* “$A5,<dh>,<dl>,3,’S7’, <mode>” (7 bytes) 0=mono, 1=stereo Bass Gain S8* “$A5,<dh>,<dl>,3,’S8’, <mode>” (7 bytes) Sets bass gain Treble Gain S9* “$A5,<dh>,<dl>,3,’S9’, <mode>” (7 bytes) Sets treble gain Notes Reserved for future stereo iC-Net products Contemporary Research ICC-HE Head End...
  • Page 13: Channel Commands

    Major and Minor channel numbers. Values may be in hex or decimal. “$A5,1,4,5,’TH’,1,2,3” Device 260, channel 515 “$A5,1,4,5,’TH’,2,2,3” Device 260, virtual channel 2-3 “$A5,1,4,5,’TH’,3,2,3” Device 260, physical channel 2, minor 3 Contemporary Research ICC-HE Head End...
  • Page 14: Tuning Commands

    Notes 1-way units do not send the TM K keypad responses for bit 2 Analog tune ring only, of limited use in 1-way controller IRC/VDC ignores TM Bit 7 (tuning), SO command sets tuning mode Contemporary Research ICC-HE Head End...
  • Page 15: On-Screen Text Commands

    Sets screen timeout to specified time in seconds (1-254). If time is 0 or 255, any text on the screen will persist indefinitely, or until cleared. Notes IRC/VDC will respond to all formatting commands, using white text on transparent background Contemporary Research ICC-HE Head End...
  • Page 16: Rs-232 Response

    RS-232 Response Contemporary Research 2-way iC-Net devices will send a response over the network whenever there is there is a change in status or command from an IR remote or front panel. Response String Structure Characters in response strings are expressed in a combination of hex and ASCII characters. For clarity, the following protocol examples use the following conventions: •...
  • Page 17: Rs-232 He Response

    Tip: If the number of present and expected devices match, the green Net LED on the HE will blink once per second. If the two numbers do not agree, the LED blinks twice per second. Contemporary Research ICC-HE Head End...
  • Page 18: Rs-232 Device Response

    The 0 – 9, Channel Up/Down functions are sent only if enabled in the TM command (Bit 2 = 1). The Channel Up/Down responses will be sent if the Tune Ring contains no channels – see Ex2 in the Tune Ring command section. Contemporary Research ICC-HE Head End...
  • Page 19 11 = Channel 21 = Page Zone 22 = Page Room 25 = Go 21 = Attach Zone 32 = Attach Room Tip: The Menu entries are active even if the TV power is off. Contemporary Research ICC-HE Head End...
  • Page 20: Ic-Net Smartzones

    You've probably figured out that you never want to assign a virtual device number to an actual device in the system. If you assigned #1536 to a device, all the TV controllers in Zone 6 would respond every time you sent a command to that one device. Contemporary Research ICC-HE Head End...
  • Page 21: System Map

    1538 1792 W252 Hallways W253 1793 W254 1794 Floor 1795 E151 1796 2048 E152 Office E153 Admin 2049 E154 A/V Center 2050 1024 4095 Floor All Zones E251 1025 E252 1024 E253 1025 E254 1026 Contemporary Research ICC-HE Head End...
  • Page 22: Typical Rf And Icc-Net Signal Flow

    Typical RF and ICC-Net Signal Flow This diagram shows the structure of a typical Contemporary Research media retrieval system. One of the key aspects iCC-Net communication is to provide a forward and return (sub-channel) path for data if you’re using 2- way TV Controllers.
  • Page 23: Safety Instructions

    Article 820-40 of the National Electrical Code (Section 54 of Canadian Electrical Code, Part I), that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as possible. Contemporary Research ICC-HE Head End...
  • Page 24: Limited Warranty And Disclaimer

    Limited Warranty and Disclaimer Contemporary Research Corporation (CR) warrants this product to be free from defects in material and workmanship under normal use for a period of two years from the date of purchase from CR. Should such a defect occur CR will repair or replace, at their option, the defective product at no cost for parts or labor.
  • Page 25: Rf Channel Frequencies

    HRC/IRC — About 10% of CATV systems use these alternate frequency plans, created to reduce “beat” interference. FCC – U.S. Broadcast VHF/UHF *Channel 1 — IRC/HRC spacing created a Channel 1 between 4 and 5, the rarely used channel must be shifted to different frequency for IC-Net operation Contemporary Research ICC-HE Head End...
