MA Technology Companion Pad Quick Start Manual

SOLUTIONS FOR A SMARTER WORLD
Quick Start Guide

Charging the Tablet PC

Starting up the Tablet PC
Administrator
*Note: Windows login requires user setup and will vary by region.

Package List

How to start

1 2
3
4
1 Tablet PC
2 Quick Start Guide
3 Power Adapter
4 Support Disc (depending on SKU)

Using the Touchscreen

Windows
Gesture Action Diagram
Usage
Tapping Click Lightly tapping on an object
in the screen performs the
same function as a mouse
click. A double tap is the
same as a double click.
Flicking Default: Flicking the screen in
Pan Up/ either an up, down, left, or
Down/ right allows you to quickly
Left/Right navigate or scroll through
various screens.
Dragging Mouse Holding your finger on an
Drag item on the screen while
moving your finger around
allows you to drag items to
different locations on the
screen. The same motion
also allows you to slowly
scroll through screens.
Pinching Zoom Touching the screen with
Out two fingers apart and
pinching together allows
for you to zoom out.
Expanding Zoom In Touching the screen with
two fingers close together
and spreading them out
allows for you to zoom in.

Exploring the Tablet PC

Fan (do not block)
1 2 3 4 5
6
7
8
9
10
11
12 12 13
12 12
Using the Touchscreen
Windows
Gesture Action Diagram
Usage
Rotating Rotation Touching two points on
an image and moving
your fingers in a twisting
motion allows you to rotate
images.
Press and Right- Pressing the screen with
Tap Click one finger and then tapping
with a second finger nearby
brings up the right-click
menu.
Press and Right- Pressing, holding, and
Hold Click releasing on the screen
with a finger brings up the
right-click menu.

Taking Care of your Tablet PC

Keeping the Tablet PC Clean

Use a soft, lint-free cloth to clean the touchscreen. Avoid getting moisture in
openings. Do not use aerosol, sprays, solvents, alcohol or abrasives to clean
the device.

Using Connectors and Ports

Never force a connector into a port. Check for any obstructions on the port.
Ensure that the connector matches the port and that you have positioned the
connector correctly in relation to the port.

Glass Parts

The glass touchscreen could break if the device is dropped on a hard surface or
suffers a substantial impact. Glass cracked due to abuse or misuse is not covered
under warranty.

Handling the Tablet PC

Failure to follow the handling information could result in damage to the device.
Exploring the Tablet PC
1 Touch hotkey ¹ 8 USB 2.0 ports
2 Status indicator 9 Audio input and output
3 Light sensor ² for OMTP headset
10 SD card reader
4 Microphone
11 SIM card reader
5 Webcam
12
6 DC input Stereo speakers
Mini-HDMI
7 13 Power button
Status Indicator
Wi-Fi/BT/3G/GPS Wi-Fi/BT/3G/GPS
LED Color
Enabled Disabled
Blue On Off
Power Button LED
LED Color Powered On Powered Off Sleep Mode
Blue On Off Blinking
¹The touch hotkey performs the following functions:
In DOS:
- In the case of an abnormal shut down and subsequent DOS startup
the touch hotkey performs the following keyboard-based functions:
- Short press = "Down arrow" key
- Long press = "Enter" key
In Windows:
- Opens/Minimizes the Launcher
²The Light Sensor performs the following functions:
-Automatically adjusts the brightness of the screen based on ambient light.
-Allows the user to adjust the baseline light level.
Taking Care of your Tablet PC

Transporting the Tablet PC

This device contains sensitive components including a large glass touchscreen.
Do not drop, knock or crush the device.

Battery

The battery is non-replaceable.
Disassembly
Attention: Do not remove any stickers on the device with the mark,
doing so will void the device's warranty.
FCC Notice
Notice (Information to user):
You are cautioned that changes or modifications not expressly approved by the party responsible for
compliance could void your authority to operate the equipment.
Notice
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference and (2) this device must accept any
interference received, including interference that may cause undesired operation.
For P15B equipment
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interfer-
ence will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
For portable devices
FCC RF Radiation Exposure Statement:
1. This Transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This device was tested for typical hand held operations with the device contacted
directly to the human body to the sides of the device. To maintain compliance with FCC RF exposure
compliance requirements, avoid direct contact to the transmitting antenna during transmitting.
1506-0FK2000
