USING 3D GLASSES

Power On
Power Off
1
Auto Off*
Battery(Lithium polymer)
discharge
How to re-connect the
glasses
*1
The Auto Off function automatically switches the power off when the glasses loose the signal from the TV.
This may occur when the distance or angle between the device and the TV are out of range; when there is a barrier between the two
devices; or when the device is switched from 3D to 2D mode.

CHARGING THE GLASSES

1
Connect the USB port located under the power button on the glasses to the USB port of the
TV or PC using the supplied 8-pin mini USB cable as shown by the fi gure.
CAUTION
2
Charge the glasses until the LED is green. The glasses will fully charge in about 1 hours 50
!
NOTE
While charging: The LED is red.
When charging is complete: The LED is green.
When the battery is discharged: The Red LED blinks for 1 minute and turns off automatically.
The 3D glasses can still be used while charging via a USB device.
CAUTION
3
Battery life and charging time
▶ 5 min charge : Approximately 7 hours
▶ 30 min charge : Approximately 40 hours
※ Battery life may vary depending on the user's environment.
HOW TO WEAR THE 3D GLASSES
Using 3D glasses may not be convenient for users wearing regular glasses. Adjusting the nose pad can
improve your viewing comfort.
How to adjust the nose pad
1
3
!
Follow the instructions in reverse order to put the nose pad back.
NOTE
The nose pad can be adjusted even if you don't wear glasses.
Button Operation
Press and hold the power button for 1 or 2
seconds.
P re s s a n d h o l d d o w n t h e Po we r b u t to n
(1 second ~2 second)
The device is automatically switched off if there
is no 3D signal for more than one minute.
-
Press the power button for over eight seconds.
Do not insert the supplied 8-pin mini USB cable in the reverse direction. Otherwise, this may
cause damage to the product.
If you use a USB cable other the one (8-pin mini USB) supplied with the product, the product may be damaged.
This equipment shall be powered with USB 2.0 or higher.
Avoid twisting or dropping the 3D glasses as this may cause damage or break them.
2
LED Indication
The red LED blinks once.
The red LED blinks three times.
The red LED blinks three times.
If the battery is discharged, the red LED blinks
for 1 minute and turns off automatically.
* When charging is completed, the LED is lit green.
Release the button when the green LED light
turns on. Then, you will see the green light blink
three times before the device is switched off.
If you switch the power on again, the glasses
will be connected to the TV with the strongest
signal.
Ex.) AG-S350
Pull the nose pad in the direction shown by the
arrow as shown in the image. Be careful not
to twist or lift the nose pad as this can cause
damage.
minute
.
