Dynex DX-CRDRD User Manual

Internal all-in-one card reader/writer
Hide thumbs Also See for DX-CRDRD:
Table of Contents

Advertisement

Quick Links

See also: Manual
Internal All-in-One Card Reader/Writer
DX-CRDRD
USE R GUI DE

Advertisement

Table of Contents
loading

Related Manuals for Dynex DX-CRDRD

Summary of Contents for Dynex DX-CRDRD

  • Page 1 Internal All-in-One Card Reader/Writer DX-CRDRD USE R GUI DE...

  • Page 2: Table Of Contents

    One-year limited warranty..............15 Introduction Congratulations on your purchase of a Dynex DX-CRDRD Internal All-in-One card reader/ writer. This card reader provides an excellent solution for directly accessing media cards at the front of a computer. It is ideal for installation in a 3.5-inch drive bay.

  • Page 3: Features

    Internal All-in-One Card Reader/Writer Features • Provides four media card slots supporting most popular memory cards, including high speed memory cards such as SDHC, CF UDMA, and MS Pro HG. • Provides front access on a computer. • Easily mounts into a 3.5" drive bay. •...

  • Page 4: Installing The Card Reader

    DX-CRDRD Package contents • Card reader with USB 5-pin cable • Mounting screws (ISO 3f 4mm) (4) • Extra front bezel (1) • Utility CD (includes AP drivers and this User Guide) • Quick Setup Guide Minimum system requirements • IBM-compatible PC •...
  • Page 5 Internal All-in-One Card Reader/Writer 3 If you want the alternate colored bezel, change it now by pressing the plastic clips on each side of the card reader with a pen or pencil and pulling the bezel off, then snapping the new bezel into place. Push in plastic clips 4 Locate a USB connector on the motherboard and make sure the connector is...

  • Page 6: Using The Card Reader

    DX-CRDRD 7 Connect your card reader's USB connector to a compatible USB connector on your computer’ s system board (See the illustration under step 4.) 8 Make sure that you have removed any tools or loose screws from inside your computer, then replace your computer's cover.
  • Page 7 Internal All-in-One Card Reader/Writer Understanding card slot compatibility CF UDMA, MD Insert Compact Flash™ (CF) type I/II cards, UDMA cards, or IBM® Microdrive cards into this slot. SD, SDHC, MMC, and xD Insert Secure Digital (SD or SDHC), MultiMediaCards (MMC or MMCplus), and xD picture cards into this slot.
  • Page 8 DX-CRDRD Customizing drive icons To make the media card slots easier to recognize in My Computer or Windows Explorer, you can customize the drive icons. To customize the drive icons using Windows: 1 Save all files and close all programs.

  • Page 9: Uninstalling The Software

    Internal All-in-One Card Reader/Writer 5 After the driver installation is complete, the customized Windows drive icons will not appear in My Computer and Windows Explorer without inserting memory cards into a slot. 6 When Windows detects a card in a slot, the corresponding drive icon appears and indicates the card type.
  • Page 10 DX-CRDRD 3 Locate the software in the list, then click Remove. 4 Follow the on-screen instructions to uninstall the software. To uninstall the software in Windows XP and Windows 2000: 1 Click Start, then Control Panel. 2 Click Add or Remove Programs.
  • Page 11 Internal All-in-One Card Reader/Writer Formatting a memory card If your computer has trouble recognizing a new memory card, format the memory card in your camera or by using the following procedure. Caution: Formatting a memory card permanently deletes all files on the card. Be sure that you copy important files to a computer before formatting a memory card.

  • Page 12: Troubleshooting

    DX-CRDRD Troubleshooting Problem Suggestions Memory card does not appear in • Make sure the card reader has been properly connected to a USB My Computer or Windows connector on your computer’ s system board. Explorer. • Try a different memory card of the same type in the same slot. If the different memory card works, the card reader is functioning and the original memory card is damaged or defective and should be replaced.

  • Page 13: Legal Notices

    Internal All-in-One Card Reader/Writer System Support Windows 2000, Windows XP, Windows Vista, Windows 7 Certification FCC Class B, ICES-003 Supported cards CompactFlash( I & II, UDMA), Micro Drive, Secure Digital (SD, SDHC), MultiMediaCard (MMC, MMC plus), xD Picture card( H type, M type), and Memory Stick (MS, MS Pro, MS Duo, MS Pro Duo, MS Pro HG) cards , Micro SDHC, Micro SD and M2.
  • Page 14 DX-CRDRD...

  • Page 15: One-Year Limited Warranty

    If service of products and parts are required after the Warranty Period expires, you must pay all labor and parts charges. This warranty lasts as long as you own your Dynex Product during the Warranty Period.
  • Page 16 7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645 © 2010 BBY Solutions, Inc. All rights reserved. DYNEX is a trademark of BBY Solutions, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
  • Page 17 Internal All-in-One Card Reader/Writer...
  • Page 18 DX-CRDRD...
  • Page 19 Internal All-in-One Card Reader/Writer...
  • Page 20 7601 Penn Ave. South, Richfield, MN 55423 U.S.A. ENGLISH © 2010 BBY Solutions, Inc. All rights reserved. 10-0881 DYNEX is a trademark of BBY Solutions, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners..
