EAW PH10 Specification Sheet

DESCRIPTION
The PH10 is a weather-resistant paging horn designed for indoor or
outdoor fixed installations.
The PH10 is supplied with an integral 70/100V line transformer
rated to a maximum of 10 watts. Power is adjustable by means of a
recessed rotary switch on the back of the horn, and allows selection
of 5, 2.5, 1.25, 0.625, and OFF for 70.7V operation, and 10, 5, 2.5,
1.25, and OFF for 100V operation. A sixth position is provided for
low-impedance operation at 10W into 8 ohms.
The paging horn assembly is shipped with an adjustable mounting
bracket for easy installation and aiming, and an attached color-
coded speaker cable. It is constructed of high-impact ABS plastic
with a light grey finish.
PH10 DIMENSIONS
Eastern Acoustic Works | One Main Street | Whitinsville, MA 01588 USA | TEL toll free within US/Canada 888.337.7404
TEL outside US 425.892.6503 | FAX 425.485.1152 | Page 1 of 2
Features
• High-efficiency paging horn
• Weather-resistant to withstand demanding environmental
conditions
• Built-in multi-tap constant voltage transformer for 70.7 V
or 100 V distributed systems
• Bypass mode for low-impedance operation into 8 ohms
• Lightweight, UV/weather resistant, high-impact
ABS plastic construction
• Integrated cable strain relief
• Stainless steel mounting bracket
Applications
• Indoor/Outdoor Voice Paging
• Background Music
• Tone Signaling
PH10
PAGING HORN
• Boats
• Mobile Vehicle
• Security
Part No. 0010612 Rev B 07/07
