Pentax 17716 Specifications

| K2000
CAMERA HARDWARE
MODEL: K2000
TYPE: Digital SLR
PRODUCT CODE: xxxxx, UPC: xxxxx
SENSOR
Type: Interline interlace CCD with primary color filter and integrated Shake/Dust
Reduction sensor movement system
Size: 23.5 x 15.7mm
Color depth: 8 bits/channel JPG, 12 bits/channel RAW
Effective pixels: 10.2 MP
Total pixels: 10.75 MP
Recorded resolutions: 10M (3872x2592), 6M (3008x2000), 2M (1824x1216)
Quality levels:  (Best),  (Better),  (Good)
Dust Removal: Image sensor movement combined with SP coating
LENS MOUNT
Type/construction: PENTAX K
AF3
Usable lenses: PENTAX K , K
AF3 AF2
645/67 med format useable w/ adapter and/or restrictions)
SDM function: YES
Power zoom function: n/a
FOCUS SYSTEM
Type: TTL phase-matching 5 point wide autofocus system (SAFOX xxxxx)
Focus modes: AF Auto, AF Single (w/ focus lock), AF Continuous (available in Action
mode including Auto Picture Action, Kids, Pet,
modes, P/A/S/M/B/Sv), Manual
Focus point adjustment: Auto, Wide, Spot
AF assist: YES, via built-in flash
VIEWFINDER
Type: Penta-Mirror
Coverage (field of view): Approx 96%
Magnification: Approx 0.85X (w/ 50mm f/1.4 at infinity)
Standard focusing screen: Natural-Bright-Matte II
Diopter adjustment: -2.5 to 1.5
Depth of field preview: Digital (available as a custom function linked to Help button)
LCD MONITOR
Type: 2.7" TFT color LCD monitor, adjustable brightness
Resolution: 230,000 dots
Wide angle viewable: YES
BUILT-IN FLASH
Type: Retractable P-TTL auto/manual popup flash
Guide number: 11 (100/m)
Coverage: 28mm wide angle (equivalent to 35mm)
Flash modes: On, off, redeye, wireless
Flash exposure compensation: -2 to 1 EV in 1/2 steps
EXTERNAL FLASH
Type: Hot shoe (P-TTL, high speed sync available), wireless with PENTAX dedicated
flash
Synchronization speed: 1/180s
STORAGE MEDIA
Internal memory: n/a
Removable memory: SD, SDHC
INTERFACES
Ports: USB 2.0 hi-speed, video out
Video out: NTSC, PAL
Printer interfaces: PictBridge
POWER SUPPLY
Power source: 4* AA (lithium, NiMH rechargeable, alkaline)
Recordable images: Approx xxxxx (lithium)
Playback time: Approx xxxxx (lithium)
AC adapter available: YES (optional)
PHYSICAL SPECIFICATIONS
Body dimensions (W x H x D): 4.8 x 3.6 x 2.7"
Body weight
Without battery or removable memory: 18.5 oz
Loaded and ready: 20.8 oz (lithium)
Construction material(s): Fiber reinforced plastic polymer covers
stainless steel chassis
Operating temperature: 32-104°F
LANGUAGE SUPPORT
English, French, German, Spanish, Swedish, Dutch, Italian, Russian, Portuguese,
Danish, Finnish, Polish, Czech, Hungarian, Turkish, Greek, Japanese, Korean,
Traditional/Simplified Chinese
bayonet stainless steel mount
, K , and K (K mount, 35mm screwmount,
AF A
Stage Lighting, and Night Snap
around a rugged
IMAGE CAPTURE
IMAGE STABILIZATION
Type: Body-based, sensor shift Shake Reduction
METERING SYSTEM
Type: TTL open aperture, 16 segment metering
Sensitivity range: EV 0-21 (ISO 100, 50mm f/1.4)
Multi-segment: YES, 16 segments
Center weighted: YES
Spot: YES
Exposure compensation: +/- 2 EV (1/2 or 1/3 steps)
Exposure lock: YES (available as a custom function linked to focus lock)
Exposure bracketing: YES, 3 frames, up to +/- 1.5 (1/2 steps) or +/- 1.0 (1/3 steps)
ISO SENSITIVITY
Auto: 100-3200 ISO (1, 1/2, 1/3 steps), up to 1600 ISO in Bulb mode
Manual: 100-3200 ISO (1, 1/2, 1/3 steps), up to 1600 ISO in Bulb mode
WHITE BALANCE*
Auto preset modes: Auto, Daylight, Shade, Cloudy, Fluorescent (D, N, W),
Tungsten, Flash
Manual mode(s): YES
* WB fine adjustment available
SHUTTER
Type: Electronically controlled, vertical run, focal plane shutter
Shutter speed: 1/4000 to 30 sec, bulb available
CAPTURE MODES
Mode selection: Auto Picture (Portrait, Night Portrait, Landscape, Macro, Action),
Picture (Portrait, Landscape, Macro, Action, Night Scene Portrait, Standard
Flash Off), Scene (Night Scene, Surf & Snow, Food, Sunset, Kids, Pet,
Candlelight, Museum, Stage Lighting [2M JPG], Night Snap [2M JPG]),
Program, Sensitivity Priority, Shutter Priority, Aperture Priority, Metered
Manual, Bulb (available in Metered Manual)
Green simplified mode available: n/a
P/A/S/M/B: P, A, S, M (extended modes include Sv, Bulb available in Metered
Manual)
Date stamp: n/a
Digital filters (capture): Toy Camera, High Contrast, Soft, Starburst, Retro, Color
Extract (xxxxx). Custom Image Modes includes Bright, Natural, Portrait,
Landscape, Vibrant, and Monochrome modes. Color Custom Image Modes
include gamut radar and fine adjustment for saturation, hue, contrast, and
sharpness. Monochrome Custom Image Mode includes adjustment for film filter
effects (green, yellow, orange, red, magenta, blue, cyan, infrared), toning
(sepia warm/cool), contrast, and sharpness (regular and fine adj scales).
Data record: Folder Name (standard, date)
DRIVE MODES
Mode selection: Single, Continuous (Hi, Lo), Self-Timer (12s, 2s), Remote (0s, 3s),
Auto Bracket
Continuous FPS:
- 3.2 FPS (4 JPG and Continuous Hi, 4 RAW)
- 1.1 FPS (unlimited JPG and Continuous Lo, 4 RAW)
Self-timer: YES (12s, 2s)
Remote control: YES, infrared (0s, 3s)
PLAYBACK MODES
Mode selection: One shot, index
magnification (quick zoom available), image comparison, image rotation, folder
view, calendar, slideshow, histogram, bright/dark indication, resize, trimming,
DPOF, digital filter, RAW to JPG
Magnification: Up to 16X, scrollable
Digital filters (playback): Toy Camera, High Contrast,
Color Extract, Illustration (Pastel,
(18), Slim (+/- 8), Brightness (+/- 8),
FILE FORMATS
Still: RAW PEF/DNG, JPG (EXIF 2.21), DCF 2.0 (design rule for camera file
system), DPOF, Print Image Matching III
CUSTOM FUNCTIONS
Functions available: 23
FILE STORAGE MATRIX (BASED ON 1GB MEMORY)

JPG
10M (3872x2592) 202
6M (3008x2000) 335
2M (1824x1216) 902
RAW
10M (3872x2592) 58
COMPUTER SYSTEM REQUIREMENTS*
*For device connectivity. Bundled software requirements may vary.
Windows: Windows XP/Vista, USB port
Mac: MacOS-X 10.3 or later, USB 2.0 port
KIT INCLUSIONS
K2000, DA-L 18-55 lens, AF 200FG flash, xxxxx
OPTIONAL ACCESSORIES
Accessory 1,
(4 stops maximum)
(4, 9, or 16 thumbnails, select & delete available),
Soft (3), Starburst, Retro,
Watercolor), HDR (3), B&W, Sepia, Color
Custom

343
570
1549

586
974
2627
