- Page 1 v185e/v185es/v185w/v185ws/w185/w185e/W185q LCD Monitor User’s Guide...
- Page 2 Adobe and Acrobat are trademarks of Adobe Systems Incorporated. Bluetooth is a trademark owned by its proprietor and used by Hewlett-Packard Company under license. HP supports lawful use of technology and does not endorse or encourage the use of its products for purposes other than those permitted by copyright law.
-
Page 3: About This Guide
Preface About This Guide This guide is intended for anyone who uses the v185e / v185es / v185w / v185ws / w185 / w185e / W185q LCD Monitor. It describes the monitor’s features, setup, and operation. The sections are as follows: Safety and Maintenance Guidelines Setup Using the Monitor... -
Page 4: Safety And Maintenance Guidelines
Safety and Maintenance Guidelines Important Safety Information The power cord is designed for use with your monitor. To use a different cord, use only a power source and connection compatible with this monitor. For information on the correct power cord set to use with your monitor, see Power Cord Set Requirements. -
Page 5: Cleaning The Monitor
Install your monitor near an outlet that you can easily reach. Disconnect the monitor by grasping the plug firmly and pulling it from the outlet. Never disconnect the monitor by pulling the cord. Do not allow anything to rest on the power cord. Do not walk on the cord. Maintenance Guidelines To enhance the performance and extend the life of your monitor: Do not open your monitor cabinet or attempt to service this product yourself. -
Page 6: Attaching The Base
Setup Base and Tilt Attaching the Base 1 Set the panel face down on a flat , protected surface , such as a table top. 2 Using both hands , align the base with the pedestal and push in firmly to lock in place. Make sure that the base is securely locked in place before continuing with the setup procedure. -
Page 7: Removing The Base
Removing the Base 1 Set the panel face-down on a flat, protected surface. 2 Squeeze the tabs in the bottom of the base to release the lock. 3 Remove the base from the pedestal. CAUTION: To prevent damage, avoid applying pressure to the panel front. Adjusting the Tilt For optimal viewing, adjust the screen tilt to your own preference, as follows: 1 Face the front of the monitor and hold the stand so that you do not topple the monitor while changing the tilt. -
Page 8: Attaching The Cables
Cables Attaching the Cables 1 Turn off your computer. 2 If you are attaching a VGA cable, connect one end of the 15-pin D-Sub VGA cable (blue connector) to the back of the monitor and connect the other end to the computer VGA port. 3 If attaching a DVI cable, connect one end of the cable to the back of the monitor and connect the other end to the computer. - Page 9 4 Connect one end of the power cord to the back of the monitor and plug the other end into a grounded outlet. 5 Turn on your monitor and computer. If your monitor displays an image, installation is complete. If it does not display an image, Technical Support FAQs Using the Monitor.
- Page 10 Wall Mounting Arm Preparing to Install a Wall Mounting Arm (Not supplied) This monitor can be attached to a wall mounting arm that you purchase separately. CAUTION: Before disassembling the monitor, turn off the monitor power, and disconnect all power, video, and audio cables.
-
Page 11: Using The Monitor
Using the Monitor Operating Instructions Control buttons are located on the front of the panel, as shown below. Use the Menu button (B) to adjust the display settings to your personal preferences: Set up the monitor, attach the cables, and adjust the tilt as described in the Setup section above. -
Page 12: External Controls
External Controls Auto button Automatically fine-tunes the image quality. Menu button Opens, selects, or exits the OSD menu. – (minus) button Navigates backward through the OSD menu and decreases adjustment levels. If the OSD menu is inactive, activates the Volume decrease. Navigates forward through the OSD menu and increases adjustment levels. -
Page 13: Setting The Optimal Resolution
Settings Setting the Optimal Resolution The recommended resolution for this monitor is 1366 x 768.To configure the monitor to this resolution, complete the setup procedure and make sure that the monitor is connected to the computer. Turn the monitor on and do the following: ®... - Page 14 Adjusting On-Screen Display Settings Use the OSD menu to adjust the screen image and change settings. To access the OSD menu: 1 If the monitor is not already on, press the Power button to turn the monitor on. 2 Press the Menu button to activate the OSD menu. 3 Press the –...
-
Page 15: Osd Menu
OSD Menu The table below shows the OSD menus and their functions at each level. OSD Menu Levels Level 1 Level 2 Level 3 Level 4 Factory Preset Switch Video Input (w185 / W185q only) Brightness Adjustment Scale Reset Cancel Save and Return Contrast Adjustment Scale... - Page 16 OSD Menu Levels (continued) Level 1 Level 2 Level 3 Level 4 Factory Preset Quick View Movie Photo Gaming Text Custom Cancel Save and Return Language Deutsch 简体中文 日本語 English English Español Français Italiano Nederlands Cancel Save and Return Volume(w185 only) Horizontal Adjustment Scale Control(w185 only)
- Page 17 OSD Menu Levels (continued) Level 1 Level 2 Level 3 Level 4 Factory Preset Cancel Save and Return OSD Control Horizontal OSD Adjustment Scale (v185w only) Position Vertical OSD Adjustment Scale Position OSD Transparency Adjustment Scale OSD Timeout Adjustment Scale Cancel Save and Return Information...
-
Page 18: Using The Auto-Adjustment Function
Installing Drivers and Using the Auto-Adjustment Feature Downloading Drivers and Software To download the latest version of drivers and software files from the HP Support Web site: 1 Refer to: http://www.hp.com/support 2 Select your country/region. 3 Select Download Drivers and Software. 4 Enter the model number of your monitor. - Page 19 Technical Support FAQs Technical Support FAQs (Frequently Asked Questions) Problem & Question Possible Solutions Power LED is not on. Make sure the Power button is on and the power cord is properly connected to a grounded power outlet and to the monitor. No Plug &...
- Page 20 Technical Support FAQs (Frequently Asked Questions) (continued) Problem & Question Possible Solutions Missing one of the primary colors (red, Inspect the monitor’s video cable and make sure that none of the pins green, or blue). are bent. Make sure the monitor’s video cable is properly connected to the computer.
-
Page 21: Specifications
Specifications All specifications represent the typical specifications provided by HP’s component manufacturers; actual performance may vary either higher or lower. v185e / v185es / v185w / v185ws / w185 / w185e / W185q Display Type 18.51 inches, TFT LCD 47 cm Viewable Image Size 18.51 -inch diagonal 47 cm... -
Page 22: Preset Display Modes
Preset Display Modes Pixel Format Horz Freq Horz Vert Freq Vert Polarity Pixel Clk Source Preset (kHz) Polarity (Hz) (MHz) 640 x 480 31.469 59.940 25.175 640 x 480 37.861 72.809 31.500 VESA 640 x 480 37.500 75.000 31.500 VESA 720 x 400 31.469 70.087... -
Page 23: Power Cord Set Requirements
Power Cord Set Requirements The monitor power supply is provided with automatic line switching (ALS). This feature allows the monitor to operate on input voltages in the range of 100–240V∿, 50 / 60 Hz, 1.5A. The power cord set (flexible cord or wall plug) received with the monitor meets the requirements for use in the country/region where the equipment was purchased. -
Page 24: Lcd Monitor Quality And Pixel Policy
Plug and Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities. -
Page 25: Declaration Of Conformity For Products Marked With Fcc Logo, United States Only
Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Hewlett-Packard Company may void the user’s authority to operate the equipment. Cables Connections to this device must be made with shielded cables with metallic RFI/EMI connector hoods to maintain compliance with FCC rules and regulations. -
Page 26: European Union Regulatory Notice
EMC Directive 2004/108/EC Compliance with these directives implies conformity to applicable harmonized European standards (European Norms) which are listed on the EU Declaration of Conformity issued by Hewlett-Packard for this product or product family. This compliance is indicated by the following conformity marking placed on the product:... -
Page 27: Japanese Power Cord Notice
Disposal of Waste Equipment by Users in Private Households in the European Union This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. -
Page 28: Japanese Material Content Declaration
Japanese Material Content Declaration A Japanese regulatory requirement, defined by Specification JIS C 0950, 2005, mandates that manufacturers provide Material Content Declarations for certain categories of electronic products offered for sale after July 1, 2006. To view the JIS C 0950 material declaration for this product, visit www.hp.com/go/jisc0950. Korean Notice Materials Disposal This HP product contains Mercury in the fluorescent lamp in the display LCD that might require special handling at... - Page 30 Part number: 506356-003...
