ASSEMBLY INSTRUCTIONS
DX-WD1202
Corner TV Stand
Safety information and specifications ............2
Tools needed ............................................................3
Package contents ...................................................3
Assembly instructions...........................................6

Advertisement

loading
Need help?

Need help?

Do you have a question about the DX-WD1202 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dynex DX-WD1202

Summary of Contents for Dynex DX-WD1202

  • Page 1 ASSEMBLY INSTRUCTIONS DX-WD1202 Corner TV Stand Safety information and specifications ...2 Tools needed ...3 Package contents ...3 Assembly instructions...6...

  • Page 2: Safety Information And Specifications

    17.38" × 5.75" × 17" (44.15 × 14.6 × 43.18 cm) per side Usable lower shelf: W × H × D 16.5" × 8" × 16.75" (4.9 × 20.3 × 42.55 cm) 37.5" (95.88 cm) Need help? Call 800-305-2204 DX-WD1202 39.25" (99.69 cm)

  • Page 3: Tools Needed

    DX-WD1202 Tools needed No. 2 Phillips screwdriver Flatblade screwdriver Package contents Package contents: hardware Note: You may receive extra hardware with your new TV stand. Make sure you have all the hardware necessary to assemble your new TV stand: Label...
  • Page 4 Black 9/16" (14.22 mm) flat head Black 9/16" (14.22 mm) pan head screw Black 1/2" (12.7 mm) flat head screw Brown 7/16" (11.17 mm) large head screw Silver 1/4" (6.35 mm) machine screw Nails Need help? Call 800-305-2204 DX-WD1202 Qty. 100mm...

  • Page 5: Package Contents: Parts

    DX-WD1202 Package contents: parts End (2) Upright (1) Bottom (1) Door (2) Left front and right rear leg (2) Top molding (1) Lower upright (1) Shelf (1) Back (1) Right front and left rear leg (2) Extension (2) Base (1)
  • Page 6 (A) as indicated in the illustration. Do not insert cam dowels into these edges. Do not tighten the hidden cams in this step. You’ll need: Q (30) R (22) Need help? Call 800-305-2204 DX-WD1202 Arrow...
  • Page 7 DX-WD1202 Tightening hidden cams In the remaining steps, use these illustrations for instructions on tightening hidden cams. Warning: Risk of damage or injury. Hidden cams must be completely tightened. Hidden cams that are not completely tightened will loosen, and parts may separate.
  • Page 8 (A). Tighten the four hidden cams. See “Tightening hidden cams” on page 7. Leg with hidden cams Leg with hidden cams Surface with hidden cams You’ll need: Flatblade screwdriver Need help? Call 800-305-2204 DX-WD1202 S (8)
  • Page 9 DX-WD1202 Step 3: Carefully turn the ends (A) over so the side without the hidden cams is facing up. Use a Phillips screwdriver to screw eight black 9/16" flat head screws (FF) (four per end) into the ends (A) until the shoulders of the screws rest on the surface of the ends.
  • Page 10 Insert a hole plug (AA) into the holes on the legs (I and J) that you just attached. This end will now be referred to the right end. This end will now be referred to the left end. You’ll need: Flatblade screwdriver Need help? Call 800-305-2204 DX-WD1202 AA (2)
  • Page 11 DX-WD1202 Step 5: Fasten the stop molding (L) to the top (D). Use a flatblade screwdriver to tighten the four hidden cams. See “Tightening hidden cams” on page 7. Unfinished surface Rounded edge You’ll need: Flatblade screwdriver Need help? Call 800-305-2204...
  • Page 12 (two on the upright (B), two on the left end (A), and one on the leg (J)). See “Tightening hidden cams” on page 7. Surface without hidden cams 210° You’ll need: Flatblade screwdriver Need help? Call 800-305-2204 DX-WD1202 Finished edge Arrow...
  • Page 13 DX-WD1202 Step 7: Fasten the shelf (F) to the left end (A). Use a flatblade screwdriver to tighten the two hidden cams. See “Tightening hidden cams” on page 7. Fasten the shelf (F) to the upright (B). Use a Phillips screwdriver and two black 1 7/8" flat head screws (DD).
  • Page 14 DX-WD1202 Step 8: Fasten the bottom (E) to the left end (A). Use a flatblade screwdriver to tighten the two hidden cams. See “Tightening hidden cams” on page 7. Fasten the bottom (E) to the lower upright (C). Use a Phillips screwdriver and two black 1 7/8" flat head screws (DD).
  • Page 15 DX-WD1202 Step 9: Fasten the right end (A) with the leg (I) to the top (D), bottom (E), shelf (F), and stop molding (L). Use a flatblade screwdriver to tighten the seven hidden cams: A (2), E (2), F(2), and I (1). See “Tightening hidden cams”...
  • Page 16 DX-WD1202 Step 10: With the top of the unit facing down, fasten the foot base (U) to the extension block (K). Use a Phillips screwdriver and four black 9/16" pan head screws (GG). Then, push the foot (T) into the foot base (U).
  • Page 17 DX-WD1202 Step 11: Carefully turn the unit so the front is facing down, then fasten the back (G) to the legs (I and J). Use a Phillips screwdriver and eight brown 7/16" large head screws (II). Fasten the remaining back (G) to your stand using 33 nails (KK).
  • Page 18 DX-WD1202 Step 12: Fasten the hinges (V) to the doors (H). Use a Phillips screwdriver and eight 1/2" flat head screws (HH) (two for each hinge). You’ll need: Phillips screwdriver HH (8) Need help? Call 800-305-2204...
  • Page 19 DX-WD1202 Step 13: Carefully turn the unit so the left end is facing down, then fasten one of the doors (H) to the left end (A). Use a Phillips screwdriver and the screws in the hinges. Note: You may need to loosen the mounting screw to slide the hinge part way out of the slot. Retighten the screw before you mount the hinge to the end.
  • Page 20 To adjust the doors in or out (depth), loosen the mounting screw one turn and move the doors in or out, as needed. Tighten the mounting screw after making adjustments. Horizontal adjusting screw Vertical adjusting screws You’ll need: Phillips screwdriver Mounting screw (depth) Shim Shim Need help? Call 800-305-2204 DX-WD1202...
  • Page 21 DX-WD1202 Step 15: Apply the warning label (BB) to the top (D). You should be able to read the label when the TV is removed from your stand. When the TV is in place, it should hide the label. Peel off the backing and apply the label as shown.
  • Page 22 7601 Penn Avenue South, Richfield, MN USA 55423-3645 © 2011 BBY Solutions, Inc. All rights reserved. DYNEX is a trademark of BBY Solutions, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
  • Page 23 7601 Penn Ave. South, Richfield, MN 55423 U.S.A. © 2011 BBY Solutions, Inc. All rights reserved. DYNEX is a trademark of BBY Solutions, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners. 11-0422...
