Summary of Contents for Dynamic DX-ARC-SWB
- Page 1 DX Switchbox (DX-ARC-SWB) Installation Manual GBK62297 Issue 1, February 2003...
-
Page 2: About This Manual
Manuals for all other DX Modules present in the system. If there is a specific requirement for your application, please contact Dynamic Controls or one of the sales and service agents, as we can assist you to configure the DX-ARC-SWB for this application. -
Page 3: Table Of Contents
Switched Auxiliary Power Supply Output... 5 Testing the Installation ... 6 Specifications... 6 Electrical Specifications... 6 Physical Specifications ... 7 Appendix... 8 Intended Use Statement... 8 Maintenance... 9 Warranty... 9 Safety and Misuse Warnings... 10 Contact Details ... 10 DX Switchbox (DX-ARC-SWB) – Installation Manual... - Page 4 GBK62297 Issue 1, February 2003...
-
Page 5: Introducing The Dx Switchbox
DX Switchbox (DX-ARC-SWB) – Installation Manual Introducing the DX Switchbox The Dynamic DX Switchbox (DX-ARC- SWB) is a DXBUS compatible module that allows up to 5 seat functions to be operated by switches connected to a DB15 connector. Functionally, it is... -
Page 6: Mounting And Installation
It is preferable that the DX-ARC- SWB is mounted in the following orientations. Parts supplied with the DX-ARC-SWB: Mounting bracket and screws Warning: The DX-ARC-SWB (and associated switches and cabling) is not waterproof and should be mounted and installed to provide maximum protection from ingress of fluids and mechanical abuse. -
Page 7: Programming
Programming For the DX-ARC-SWB to function correctly, the ARC Enable setting must be set to Yes, and the Joystick Actuators setting set to No (depending on the Master Remote used), using the Wizard programmer. Most DX Master Remotes will allow only one Actuator control, the DX- ARC-SWB or the Master Remote, but not both. -
Page 8: Connections And Wiring
3) Elevate the drive wheels. DXBUS The DX-ARC-SWB has 2 DXBUS sockets to connect to the DXBUS system. Both sockets are identical. Connect a DXBUS cable from either socket to the DXBUS socket of any other DX Module. Route and secure the cable to prevent mechanical damage and snagging. -
Page 9: Seat Switches
Use appropriate quality assemblies for the installation of the system. Switched Auxiliary Power Supply Output The mating housing and pins are included with the DX-ARC-SWB. The auxiliary power supply uses the same output as pin 15 of the DB15 connector. The total load of both outputs must not exceed 1 Amp. -
Page 10: Testing The Installation
Turn the powerchair on by pressing the Power button on the DX Master Remote. Check that the green DX-ARC-SWB ‘Status’ light turns on and is steady (i.e. not flashing). Operate each seat switch in turn and check for the correct operation of all seat functions. -
Page 11: Physical Specifications
Material Finish Protection Rating Physical Size: Shipping Weight Operating Temperature Range Storage Temperature Range Operating Humidity Range DX Switchbox (DX-ARC-SWB) – Installation Manual Aluminium alloy Epoxy powder-coated “Rolling Thunder” Not rated 95mm x 61mm x 26mm 100g Nominal Units °C... -
Page 12: Appendix
The DX-ARC-SWB has been classified as a component of a Powered Wheelchair as detailed in 21 CFR § 890.3860 - Class II Medical Device. The DX-ARC-SWB has been classified as a component of a Class I medical device as detailed in the Council Directive 93/42/EEC concerning Medical Devices. -
Page 13: Maintenance
Dynamic Controls. DX Switchbox (DX-ARC-SWB) – Installation Manual... -
Page 14: Safety And Misuse Warnings
GBK62297 Issue 1, February 2003 Safety and Misuse Warnings Do not install, maintain or operate this equipment without reading, understanding and following the proper instructions and manuals, otherwise injury or damage can result. Use appropriate quality assemblies for the installation of the system. Contact Details Dynamic has a global network of sales and service centers.
