With YPbPr connections, the composite sync is always combined with the Y signal. The iScan Pro
will automatically do this whenever the color space switch is set to YPbPr. It is not required to
configure any of the internal jumpers for any YPbPr device.
Wire Color
Red
Green
Blue
White (or
Gray)
Yellow (or
Black)
RGB/HV RGB/S(comp)
R (Red) R (Red)
G (Green) G (Green)
B (Blue) B (Blue)
H (Horizontal) C-Sync
V (Vertical) no connect
Display Devices
YPbPr
Pr
Y
Pb
no connect
no connect
Table 1: Wire Color Cross-Reference
iScan Pro User Manual
Other
Cr or R-y
Y
Cb or B-y
no connect
no connect
