Page 1
D-Link Wireless G DWA-110 802.11g (2.4GHz) Wireless USB 2.0 Adapter Manual Building Networks for People...
Page 2
How to configure DWA-110 in Macintosh OS After you have completed the installation of the DWA-110 into your Macintosh computer (please refer to the Quick Installation Guide included with the product), follow the steps below to access the configuration settings.
Using the Configuration Utility with Macintosh OS (continued) This window will ap- pear displaying the following: Current Wireless Network settings: Network Name, BSSID; Link State; Network Type ; Channel and Signal Strengh. Available Wireless Networks including: SSID;BSSID;Signal ; Channel; Authentication; Encryption Start Scan: Click Start Scan to...
Page 4
Using the Configuration Utility with Macintosh OS (continued) My Networks ADD: Click ADD to creat a new network profile manually. EDIT: Highlight a network profile and click EDIT to configure that network profile . DELETE: Highlight a network profile and click DELETE to remove that network from the profile list.
Page 5
Using the Configuration Utility with Macintosh OS (continued) Connect Order > ADD or EDIT Select the Authentication Type. In the example, WPA-PSK was chosen. Select the Encryption Type. In the example, TKIP was chosen. Enter WPA Pre-Shared Key. In this case 8 digits of 1 have been entered.
