User Manual
E
NGINEERING
CHANGE CONTROL
Description of Change
Initial Release
For Realtek AC97 CODEC
M7 VKG VIA KM-133A For AMD Athlon/Duron Motherboard
Project:
2001/10/24
Date:
Biostar Group
Owner:
TEL: 886-2-2218-0150 FAX: 886-2-2218-1552
Contact:
Home Page:
1
M7 VKG
V
ALIDATION
COVER SHEET
Revision
1.0
1.0
http://www.biostar.com.tw
T
R
EST
EPORT
Sections/Pages Affected
Date
2001/1/31
2001/10/17
Advertisement
Table of Contents
Related Manuals for Biostar M7 VKG
Summary of Contents for Biostar M7 VKG
- Page 1 COVER SHEET CHANGE CONTROL Description of Change Revision Sections/Pages Affected Date Initial Release 2001/1/31 For Realtek AC97 CODEC 2001/10/17 M7 VKG VIA KM-133A For AMD Athlon/Duron Motherboard Project: 2001/10/24 Date: Biostar Group Owner: TEL: 886-2-2218-0150 FAX: 886-2-2218-1552 Contact: Home Page: http://www.biostar.com.tw...
-
Page 2: Table Of Contents
CONTENTS PRODUCT INFORMATION..............4 Motherboard General Information ................4 Chipset Details ......................4 BIOS Details ....................... 4 CPU Support ....................... 4 Memory Support ......................4 On-board Features and Devices .................. 4 Mechanical ........................5 DESIGN REVIEW-Ver 1.0 ............... 7 Mainboard Voltage Measurement................7 Bus Clock ........................ - Page 3 DVD-ROM........................ 39 FDD........................... 40 HDD .......................... 40 Joystick........................41 Keyboard ........................41 LAN Card........................42 Memory ........................42 Modem Card......................43 Mouse ........................43 Power Supply ......................44 Printer ........................44 Scanner ........................45 SCSI Card........................45 Sound Card........................ 45 LAN HUB .........................
-
Page 4: Product Information
PRODUCT INFORMATION Motherboard General Information Vendor Biostar Model Number M7 VKG Version Number V1.0 Platform Micro ATX FCC ID Number CE Logo Chipset Details System Chipset Vendor North Bridge Revision VT8365A/0050CD South Bridge Revision VT82C686B Clock Generator Vendor Clock Generator Revision... -
Page 5: Mechanical
AGP (2X/4X) Slot Support AMR Slot Support CNR Slot Support ACR Slot Support Ultra DMA 33 Support Ultra DMA 66 Support ATA-100 Support Power on by LAN Support Infrared Support Enhanced Parallel Port DMI Compliance Hardware Monitor Support ACPI v1.0/APM v1.2 Compliance On-board Graphics Controller On-board Network Adapter 10Mb... - Page 6 CD Audio-in Connector in PCB None Excellent Fair Poor AUX Audio-in Connector in PCB None Excellent Fair Poor Telephony Connector in PCB None Excellent Fair Poor Digital Video Connector None Excellent Fair Poor Other Jumper in PCB None Excellent Fair Poor Comments:...
-
Page 7: Design Review-Ver 1.0
DESIGN REVIEW-Ver 1.0 Mainboard Voltage Measurement Voltage List Voltage SPEC Voltage Measured Result Battery Voltage 3.0V/7uA Pass 5.0V+-5% 5.06 Pass +12V 12.0V+-5% 11.99 Pass -5.0V+-5% -5.09 Pass -12V -12.0V+-10% -11.78 Pass +3.3V +3.3V+-5% 3.34 Pass Bus Clock Clock Frequency Spec Value (MHz) Measured Value Pass/Fail CPU and Clock Host... -
Page 8: Required Bios Default Settings
REQUIRED BIOS DEFAULT SETTINGS Lists Specification Result BIOS FEATURES SETUP ►Boot Device select Press Enter Pass First Boot Device Floppy Pass Secone Boot Device HDD-0 Pass Third Boot Device LS120 Pass Boot Other Device Enabled Pass ►Shadow Control Press Enter Pass Video BIOS Shadow Enabled... -
Page 9: Power Management Setup
PCI Master 0 WS Write Enabled Pass PCI Delay Transaction Disabled Pass PCI#2 Access #1 Retry Enabled Pass ►AGP Device Control Press Enter Pass AGP Mode Pass AGP Aperture Size 128M Pass AGP Driving Control Auto Pass X AGP Driving Value Pass AGP Master 1 WS Write Disabled... -
Page 10: Pnp / Pci Configuration
►IRQs Activity Monitoring Press Enter Pass IRQ3 (COM2) Enabled Pass IRQ4 (COM1) Enabled Pass IRQ5 (LPT2) Enabled Pass IRQ6 (Floppy Disk) Enabled Pass IRQ7 (LPT1) Enabled Pass IRQ8 (RTC Alarm) Disabled Pass IRQ9 (IRQ2 Redir) Disabled Pass IRQ10 (Reserved) Disabled Pass IRQ11 (Reserved) Disabled... -
Page 11: Pc Health Status
MPU-401 Disabled Pass MPU-401 I/O Address 330-333H Pass Game Port (200-207) Enabled Pass Init Display First PCI Slot Pass Onboard FDD Controller Enabled Pass Onboard Serial Port 1 Auto Pass Onboard IR Port Disable Pass UART 2 Mode HPSIR Pass X IR Function Duplex Half Pass... -
Page 12: Functionality
FUNCTIONALITY Setup Installation Test Of Operating System Pass/Fail Windows 98 Second Edition Pass Windows NT 4.0 Workstation Pass Windows ME Pass Windows 2000 Professional Pass Windows XP Home Edition Pass Windows XP Professional Pass Linux (Red Hat 7.0) Pass Basic On-board Function Test Test Platform MS-DOS Operating Comment... - Page 13 Time Out Function Test Pass Power LED Flash Check Pass CPU FAN Stop Check None Power On Control Power On By RTC Test Pass Power On By LAN Test (Intel SPD3) Pass Power On By Modem Test Pass Boot Management Boot Form CD-ROM Pass Boot From SCSI HDD...
- Page 14 Plug-n-Play Test Pass Multimedia CPU Extensions Pass Memory BIOS ROM Test Pass Parity Test Pass Pattern Test Pass Extended Pattern Test Pass Walking 1’s Test Pass Walking 0’s Test Pass Random Memory Test Pass Address Test Pass Refresh Test Pass Data Bus Test Pass Cache Memory Test...
-
Page 15: Windows 98 Se Operating
APM Functionality Test Pass Device APM Test Pass ACPI Test Pass I82557 Ethernet chip Pass Comments: Test Platform Windows 98 SE Operating Comment Athlon 1300 MHz Memory Samsung 512M X2 Seagate ST315320A CDROM PHILIPS 48X Sound Card On board Video Card On bard LAN Card Intel 82559... - Page 16 Add Modem PnP Test Pass Print Port Test Add Printer PnP Test Pass Add ZIP Device Test Pass LL5 Cable test (Data Transfer test) Pass IrDA Function Test Add IR Printer Test Pass Peer to Peer Data Transfer Test (Ir-In/Ir-Out) Pass FDD Connector Test Create Windows98 Startup Disk...
- Page 17 Setup Installation Winbench 99 By The LAN Pass Setup Installation 3D Winbench 99 By The LAN Pass Add Token Ring LAN Card Test Pass Wake On LAN Test (Standby Mode) Pass ADSL Link Test Pass PCI Slots Test Add SCSI Card Test Pass Add LAN Card Test Pass...
- Page 18 Audio Function Test Audio Drivers Setup Installation Test Pass Audio Control Panel Function Test Pass CD-In Function Check Pass Game Port Test Pass Line-In Function Check Pass Mic-In Function Check Pass R/L Channel Check Pass Sound Recorder Test Pass Run MPG Files Pass System Properties Information Review Pass...
- Page 19 CPU Test Pass Hard Driver Test Pass Floppy Test Pass LS-120 Driver Test Pass CD-ROM/DVD Test Pass ZIP Driver Test Pass Memory Test Pass PCI Test Pass Video Test Pass AGP Test Pass SCSI Test Pass COM Loopback Pass Serial Port Internal Test Pass Parallel Port Internal Test Pass...
- Page 20 3D WinMark Pass 3D WinMark 2000 3D Marks Pass Demo Mode Pass Audio Winbench99 (Based onboard Sound controller) Direct Sound CPU Util 44.1 kHz 16bit Static Hardware Voices Voice 8 2.52 Voice 16 3.99 Voice 32 DirectSound CPU Util , 44.1 kHz , 16 bits Streaming Hardware Voice Voice 8 2.55...
- Page 21 Voice 16 5.47 Voice 32 4.24 Others BAPCo SYSmark 2000 Pass CD Winbench 99 Pass Final Reality Pass Intel Media Benchmark Pass 3D Mark 99 Pass Morewins Continues Test For Over Night Pass Morewins Pass Power DVD Test Pass USBready Pass WinDVD 2000 Pass...
-
Page 22: Windows2000 Operating
Red Alert Pass Rush Hour Pass RedLine Racer Pass SEGA Manx TT Pass SEGA Rally 95 Pass SEGA Daytona USA Pass Speed Demons Pass The Magic School Bus Pass Turok Pass Tonic Trouble Pass Tomb Raider II Pass Worms: 2 Pass Comments: Test Platform... - Page 23 PS/2 Mouse Test Pass COM Port Test Add Serial Mouse PnP Test Pass Add Modem PnP Test Pass Print Port Test Add Printer PnP Test Pass FDD Connector Test Format 1.44 Floppy Driver Pass IDE Connectors Test PIO Mode 4 Hard Disk Test Pass Ultra DMA 33 Hard Disk Test Pass...
- Page 24 Screen Saver Test Pass Check Screen Have No Any Shadow Or Garbage Pass AGP 2X/4X Supports Verify Pass Playing MPEG Files Test Pass Playing VCD Test Pass Playing DVD Test(With WinDVD 2000) Pass Audio Function Test Audio Drivers Setup Installation Test Pass System Properties Information Review Pass...
-
Page 25: Windows Me Operating
Stress Test Pass MS Mouse Pass MS Joystick Pass MS ScanDisk Pass Winstone 2001 Business Winstone 2001 Pass Content Creation Winstone 2001 Pass Winbench 99 Business Disk WinMark 99 Pass Business Graphics WinMark 99 Pass CPUmark32 Pass DirectDraw Tests Pass Disk Inspection Tests Pass Disk WinMark... - Page 26 CDROM TEAC 40 X Sound Card Onboard Video Card Onboard CNR Mode Lectron / PCTel Modem External Modem 3com / U.S Robobit 56K FAX (COM Port ) LAN Card Intel 82559 Test Item Pass/Fail System Comparability Test Windows ME Setup Installation Test Pass Supports Driver Installation Test Pass...
-
Page 27: Windows Xp (Home Edition ) Operating
WinTach 1.2 Pass Speedy 1.0 Pass BCM Diagnostics System Info Pass DMI Info Pass Processor Test Pass Memory Test Pass Audio Test Pass Video Test Pass Graphics Test Pass Hard Disk Test Pass Floppy Disk Test Pass CD-ROM Test Pass MS Mouse Pass MS Joystick... - Page 28 Athlon XP 17 00+ Memory NEC -PC133-256M *2 IBM 76.8G CDROM TEAC 40X Sound Card Onboard Video Card Onboard LAN Card ADMtek / ADM9510 Test Item Pass/Fail System Comparability Test Windows XP Setup Installation Test Pass Supports Driver Installation Test Pass Standby Mode Test Pass...
-
Page 29: Windows Xp (Professional ) Operating
Business Disk WinMark 99 Pass Business Graphics WinMark 99 Pass DirectDraw Tests Pass Disk Inspection Tests Pass Disk WinMark Pass GDI/USER Inspection Tests Pass High-End Disk WinMark 99 Pass High-End Graphics WinMark 99 Pass Video Tests Pass 3D Mark 2000 3D Marks Pass Demo Mode... -
Page 30: Linux (Red Hat/7.0) Operating
Hardware Device Manager review Pass System Event Review Pass Windows XP Utility Test Pass/Fail BurnIn Test CPU-Maths Pass CPU-MMX/SSE Pass Memory (RAM) Pass 2D Graphics Pass 3D Graphics Pass Hard Disk Test Pass Floppy Disk Pass Network Test Pass CD-ROM Pass Winstone 2001 Business Winstone 2001... - Page 31 System Comparability Test Linux Setup Installation Test Pass Shut Down Test Pass Restart Test Pass Device Comparability Test PS/2 Connector Test PS/2 Keyboard Test Pass PS/2 Mouse Test Pass COM Port Test Add Serial Mouse Test Pass Add Modem Test Pass FDD Connector Test Read 1.44 Floppy Disk...
-
Page 32: Reliability Test
RELIABILITY TEST Motherboard General Information Vendor Biostar Model Number M7VKG Temperature rate ( ℃ ) 0 ~ 45 ℃ Humidity rate ( % ) 0 ~ 60 % Time ( hr ) 72 hr Test Program Continuous Play DVD + Tomb2 DEMO... -
Page 33: Over Clock Test
OVER CLOCK TEST Test Platform Windows Me (FSB:100 MHz) Duron 1100 MHz Memory WINBOND 256M X2 IBM DTLA-307030 CD-ROM LITEON LTN-362 Sound Card On board Video Card On board (Frame buffer 32M) CPU Front Side Bus Clock Winstone 2001 Business Winstone 2001 36.2 Content Creation Winstone2001 42.6... -
Page 34: Over Clock Test
OVER CLOCK TEST Test Platform Windows Me (FSB:133 MHz) Athlon XP 1700 + Memory WINBOND 256M X2 IBM DTLA-307030 CD-ROM LITEON LTN-362 Sound Card On board Video Card On board (Frame buffer 32M) CPU Front Side Bus Clock Winstone 2001 Business Winstone 2001 51.3 53.2... -
Page 35: Performance Test
PERFORMANCE TEST Test Platform Windows ME Memory WINBOND 256M X2 IBM DTLA-307030 CD-ROM LITEON LTN-362 Sound Card On board Video Card On board (Frame buffer 32M) Duron 1100 Athlon 1400 Athlon XP Athlon XP 1700+ 1800+ Winstone 2001 Business Winstone 2001 36.2 48.2 51.3... -
Page 36: Windows2000 (Sp2)
Test Platform Windows2000 (SP2) Memory Nanya 512M IBM DTLA 307030 CD-ROM Pioneer DVD Sound Card Onboard Video Card Onboard VGA (1024x768x16 bit) Intel 82558 Athlon 1400 MHz Athlon XP 1600+ Athlon XP 1800+ Winstone 2001 Business Winstone 2001 42.7 43.2 Content Creation Winstone2001 60.2 62.5... -
Page 37: Windows Xp
Test Platform Windows XP Memory SIEMENS 256MB QUANTUM AS40000 ATA-100 CD-ROM SONY CDU5211 Sound Card On-Board CODEC Video Card On-Board VIDEO Duron 950 Athlon 1200 Athlon 1400 Athlon XP 1700 Winstone 2001 Business Winstone 2001 29.5 41.3 43.7 44.9 Content Creation Winstone2001 41.4 59.1 61.5... -
Page 38: Hardware Compatibility List
HARDWARE COMPATIBILITY LIST Vendor Model Frequency Type Result Athlon 700 MHz Socket A Pass Athlon 750 MHz Socket A Pass Athlon 800 MHz Socket A Pass Athlon 850 MHz Socket A Pass Athlon 900 MHz Socket A Pass Athlon 950 MHz Socket A Pass Athlon... -
Page 39: Camera Device
CREATIVE CD-2421E ATAPI Pass DELTA OIP-CD4800A ATAPI Pass LITE-ON LTN-362 ATAPI Pass LITE-ON 40X MAX ATAPI Pass LITE-ON LTN-483L ATAPI Pass CDR-3000 ATAPI Pass PHILIPS PCA328CD ATAPI Pass PHILIPS PCCD048 ATAPI Pass PLEXTOR PX-32TSI(SCSI) SCSI Pass SONY CDU711 ATAPI Pass SONY CDU4811 ATA-33... -
Page 40: Fdd
SAMSUNG SD-612 ATAPI Pass ACTIMA AD-10S ATAPI Pass Comments: Vendor Model Size Type Result MITSUMI D359T5 1.44 Pass MITSUMI D359T6 1.44 Pass MITSUMI D353T6 1.44 Pass MITSUMI D359M3 1.44 Pass MITSUMI D353M3 1.44 Pass FD1231H 1.44 Pass TEAC FD-235HF 1.44 Pass SONY MPF920-E... -
Page 41: Joystick
QUANTUM EX3200AT 3.2G ATA-33 Pass QUANTUM EX10200AT ATA-33 Pass QUANTUM E5100AT 5.1G ATA-33 Pass QUANTUM CR6400AT 6.4G ATA-33 Pass QUANTUM CX6400AT 6.4G ATA-66 Pass QUANTUM 6.4G SCSI 6.4G SCSI Pass QUANTUM KA9100AT 9.1G ATA-66 Pass QUANTUM KA13600AT ATA-66 Pass QUANTUM KX13600AT ATA-66 Pass... -
Page 42: Lan Card
K.A.CHEN KB-7000 PS/2 Pass SAMPO F-21BQ PS/2 Pass ACER 6511-TA PS/2 Pass Logitech (IR) Y-RA1 Pass WIRELESS 5110 Pass Comments: LAN Card Vendor Model Type Result 3COM 3C529B Pass 3COM 3C509B-TX Pass 3COM 3C905C-TX-M Pass 3COM 3C359 Token Link XL Pass NE-PCI32 Pass... -
Page 43: Modem Card
48LC8M8A2 128M PC-100 Pass TLC16M8T-7 128M PC-133 Pass MOSEL V54C365804VCT7 PC-133 Pass MOSEL V54C365804VCT7 128M PC-133 Pass Nanya NT5SV32MBAT-7K 512M PC-133 Pass NEC (Singapore) D4564841G5-A10-9JF PC-100 Pass NEC (Japan) D45128163G5-A10-9JF 128M PC-133 Pass NEC (Singapore) D4564841G5-A10-9JA 128M PC-100 Pass NEC (Japan) D4564841G5-A75-9JF 128M PC-133... -
Page 44: Power Supply
Logitech M-S34 PS/2 Pass Logitech M-M30 PS/2 Pass Logitech M-S43 PS/2 Pass Logitech M-CAA43 PS/2 Pass Logitech M-CAB48A PS/2 Pass Logitech M-MM35 Serial Pass Logitech M-MM43 Serial Pass Logitech M-RG45 Pass Microsoft IntelliMouse X04-91790 USB/PS2 Pass Seagate IOWCM-B700 PS/2 Pass WINIC FDM-A50 Pass... -
Page 45: Scanner
Comments: Scanner Vendor Model Drivers Type Result Scan Jet 4200C Pass Scan Jet 5200C Pass Microtek SCAN Makerx6 Pass MUSTEK 1200USB Pass UMAX Astra 1220U Pass UMAX Astra 2000U Pass Comments: SCSI Card Vendor Model Drivers Type Result ADAPTEC 2940U Pass ADAPTEC 2940UW... -
Page 46: Lan Hub
LAN HUB Vendor Model Transfer Rate Result 3COM 100/10 Switch office400 100/10 Pass D-Link DE-812TP+ 10-Base Pass D-Link DE-805TP 10-Base Pass D-Link DE-809TC 10-Base Pass Comments: USB HUB Vendor Model Drivers Result KOUWEL 580H Pass SIIG UH-144 Pass UH-400 Pass D-LINK DU-H4 Pass... -
Page 47: Zip/Ls120
Comments: ZIP/LS120 Vendor Model Size Type Result PANASONIC JU-811T012 100M Pass Iomega Z100P 100M Pass Iomega Z250P 250M Pass Iomega ZIP 100 USB 100M Pass Iomega ZIP 250 USB 250M Pass MATSUSHITA LKM-F734-1 (LS-120) 120M Pass Comments: Monitor Vendor Model Size Type Result... -
Page 48: Software Compatibility List
SOFTWARE COMPATIBILITY LIST Software Version Result MS-DOS 6.22 Pass IBM PCDOS Pass Windows Windows98 Second Edition Pass Windows ME 4.90.3000 Pass Windows NT Workstation Pass Windows 2000 Profession Release Pass Windows XP Home Edition 2002 Pass Windows XP Profession 2002 Pass Linux Red hat Pass... -
Page 49: Vcore Waveform Measurement-Ver/1.0
VCORE WAVEFORM MEASUREMENT-Ver/1.0 Vcore Ripple Test(Dos Mode) Athlon 1.2G VKG/1.0 STP CLK Vcore Condition Just booting on DOS mode, not running any Program Vcore ripple waveform RESULT PASS... -
Page 50: Vcore Transient Test(Dos Mode)
Vcore Transient Test(Dos Mode) Athlon 1.2G VKG/1.0 CH 1 STPCLK pin waveform CH 2 Vcore waveform Condition 1.Boot the system to the Win98SE environment(Command Prompt Only) Dos mode and run the stpclk.bat 2.At the main menu ,type “U” to go to the “Utilities Submenu” 3.At the next menu , type “B”... -
Page 51: Vcore Ripple Test(Open Up The Dos Editor)
Vcore Ripple Test(Open up the DOS Editor) Athlon 1.2G VKG/1.0 CH 1 STPCLK pin waveform CH 2 Vcore waveform Condition 1.Boot the system to the Win98SE environment(Command Prompt Only) Dos mode and run the stpclk.bat 2.At the main menu ,type “U” to go to the “Utilities Submenu” 3.At the next menu , type “B”... -
Page 52: Vcore Ripple Test(Standby/Resume Mode)
Vcore Ripple Test(Standby/Resume Mode) Athlon 1.2G VKG/1.0 STP CLK Vcore Condition Ripple after Standby/Resume(at STP_CLK) Vcore ripple waveform RESULT PASS... -
Page 53: Vcore Waveform Measurement (Athlon Xp)
VCORE WAVEFORM MEASUREMENT (Athlon XP) Vcore Ripple Test(Dos Mode) Athlon(tm) XP 1800+ VKG/1.0 STP CLK Vcore Condition Just booting on DOS mode, not running any Program Vcore ripple waveform RESULT PASS... -
Page 54: Vcore Transient Test(Dos Mode)
Vcore Transient Test(Dos Mode) Athlon(tm) XP 1800+ VKG/1.0 CH 1 STPCLK pin waveform CH 2 Vcore waveform Condition 7.Boot the system to the Win98SE environment(Command Prompt Only) Dos mode and run the stpclk.bat 8.At the main menu ,type “U” to go to the “Utilities Submenu” 9.At the next menu , type “B”... -
Page 55: Vcore Ripple Test(Open Up The Dos Editor)
Vcore Ripple Test(Open up the DOS Editor) Athlon(tm) XP 1800+ VKG/1.0 CH 1 STPCLK pin waveform CH 2 Vcore waveform Condition 1.Boot the system to the Win98SE environment(Command Prompt Only) Dos mode and run the stpclk.bat 2.At the main menu ,type “U” to go to the “Utilities Submenu” 3.At the next menu , type “B”... -
Page 56: Vcore Ripple Test(Standby/Resume Mode)
Vcore Ripple Test(Standby/Resume Mode) Athlon(tm) XP 1800+ VKG/1.0 STP CLK Vcore Condition Ripple after Standby/Resume(into standby) Vcore ripple waveform RESULT PASS... -
Page 57: Vcore Ripple Test(Standby/Resume Mode)
Vcore Ripple Test(Standby/Resume Mode) Athlon(tm) XP 1800+ VKG/1.0 STP CLK Vcore Condition Ripple after Standby/Resume(resume) Vcore ripple waveform RESULT PASS... -
Page 58: Core Static Load Test
STATIC LOAD TEST CORE Test Environment VKG/1.0 Power Supply HP-300SN VID Setting 1.75V Engineer Signature K.E.Y. Electronic Loading Chroma 63030 O.C.P test Over 60A Pass/Fail PASS O.V.P test 2.05V Pass/Fail PASS AGP Slot PCI Slot Temperature Vcore Vcore 5V ATX Loading Voltage Input... -
Page 59: Thermal Image Test - Ver 1.0
THERMAL IMAGE TEST – Ver 1.0 Motherboard General Information Vendor Biostar Model Number M7VKG Revision Temperature ( ℃ ) 35 ℃ Humidity rate ( % ) 0 ~ 60 % Thermo Tracer NEC TH5104 Test Program 3Dmark2000 The component temperature measured value was based on 35℃ check in the chamber Comments: and the system during in the 3Dmark2000 Looping testing. -
Page 60: Four Corner Test-Ver 1.0
FOUR CORNER TEST-Ver 1.0 Test Equipment & Environment M/B TYPE VKG/1.0 CPU Level Athlon 1.3G/133 RAM TYPE Buffalo 128M pc-133 X2 VGA TYPE ELSA GeForce 2 ULTRA Power Supply FSP-350-60BN Floppy PANASONIC JU-257 IDE1 Primary QUANTUM CX6400AT IDE1 Secondary SEAGATE ST34321A IDE2 Primary PIONEER DVD ROM IDE2 Secondary... -
Page 61: Four Corner Test-Ver 1.0
FOUR CORNER TEST-Ver 1.0 Test Equipment & Environment M/B TYPE VKG/1.0 CPU Level Athlon_xp_1800+ RAM TYPE Buffalo vs-133 128M x2 VGA TYPE Elsa gladiac ultra Power Supply FP ISR0007091 Floppy PANASONIC JU-257 IDE1 Primary QUANTUM CX6400AT IDE1 Secondary SEAGATE ST34321A IDE2 Primary PIONEER DVD ROM IDE2 Secondary...
