5 1/2"
(140 mm)
3/8"
(10 mm)
October 2007
400 S
F
M
erieS
luSh
6 1/4"
(158 mm)
190-00757-03 Rev. A
t
ount
eMplate
Recommended clearance for SD card door
Débattement recommandé pour le cache de la carte SD
Spazio libero consigliato per lo sportello della scheda SD
Empfohlener Abstand für SD-Speicherkartenabdeckung
Se recomienda despejar la puerta de la tarjeta SD
Distância recomendada para a porta do cartão SD
Anbefalet fri plads til SD-kortlåg
Aanbevolen ruimte voor klepje SD-kaart
Suositeltava vapaa tila SD-korttipaikan luukkua varten
Anbefalt klaring for SD-kortdekselet
Rekommenderat utrymme för SD-kortlucka
Рекомендованное свободное пространство для открытия
крышки отсека карты памяти SD
Preporučeni razmak za vrata SD kartice
Συνιστώμενο διάκενο για την θύρα της κάρτας SD
1/2"
13 mm
Printed in Taiwan
