SKYTRONIC REMOTE CONTROL 16CH TIMER Manual

Remote Control 16ch Timer & Remote Controlled Dimmer Adaptor
i
ii
CLOCK
iii
PROGRAM
iv
CD
v
HOUR
vi
TEMPSET CANCLE
vii

How the remote control systems works

One of the remote controls (transmitters) send a radio signal to one or more switches or dimmers. When the switch or dimmer receive the
signal it will carry out the order (switch on, off or dimming). To carry out the orders the remote control and switch or dimmer need the same
code. You can set the code in the code-learn function. It is also possible to control several switches at the same time by setting the same
code into the switches. Each switch or dimmer can store 10 codes at most. On this way you can link the parts of the SkyTronic remote control
system together.

Function

•
The transmitter can be remote controlled by the
transmitter within 40-metre range.
•
The transmitter can control up to 16 receivers in the
meantime.
Push "Function" (viii) button to make the "FUN" disappeared in the LCD screen, now the handset can be used as a remote
controller.
*There are 3 ways to code-learn:
st
1. For 1 time ,the receiver will be automatically code-learning after power-on and the LED flashes (i) later.
2. Hold on "ON/OFF/Learning Code" button (ii) for about 2 seconds, it starts to code-learn and the LED flashes.
3. After code-matched, when the receiver is in power-on status, push both the "ON" and "OFF" button in the transmitter ,then the LED
will flashes to indicate the code-learning status.
Notice: Code-learning needs about 15 seconds. After 15 seconds, quit code-learning automatically.

*Storage and Cancellation

Storage: While code-learning, hold on one group's "ON" or "OFF" button in the transmitter until LED stop flashing. The information is
stored consequently. Cancel one group storage information: While code-learning, hold on the "ON" or "OFF" button in the transmitter
until LED stop flashing. The related group's stored information is cancelled consequently. Total Cancellation: While code-learning, hold
on one "OFF" button & "All OFF" button in the transmitter until LED stop flashing. All the information stored is cancelled then.

Control

(1) For switch series receivers:
Push either "ON" button, switch on power supply of the relevant receiver( LED lights on). Push either "OFF" button, switch off power
supply of the relevant receiver (LED lights off)
(2)For dimmer series receivers:
1
RND
2
P-3*4
3
CD-RUN/STOP
4
MIN
ALL viii
1-4 9-12
13-16
5-8
ix
i
Indicator
Dimmer
ON/OFF
ii
Learning Code
iii
E
•
With LCD screen display.
•
Timer-, count-down-, random- & temperature control
functions
