8 Artificial Lighting
naire scaling has no effect on its luminance
properties.
You can scale luminaire instances and definitions.
Luminaires are scaled relative to their insertion point.
You can scale luminaires only in the Lightscape
Preparation stage.
To scale a luminaire:
Select the luminaire you want to scale.
1.
Right-click the Graphic window, then choose
2.
Transformation.
The Transformation dialog appears.
3. Click the Scale tab.
In the Relative Scale Factor X, Y, and Z boxes, en-
4.
ter a multiplier value.
For example, enter a value of 2 in the X box to double
the size of the selected luminaire in the X direction.
Enter a value of 0.5 to shrink the luminaire to half its
size.
Click Apply to scale the luminaire without closing
5.
the dialog, or click OK to scale the luminaire and close
the Transformation dialog.
Aiming a Luminaire Instance
Lightscape provides an intuitive control for aiming a
luminaire to a particular point in your scene.
144
To aim a luminaire toward a surface:
Select the luminaire instance(s) you want to aim.
1.
Choose Edit | Transformation, or right-click in
2.
the Graphic window, then choose Transformation.
The Transformation dialog appears.
Click the Aim tab.
3.
Enable Pick.
4.
Pick a point on any surface toward which you
5.
want to aim the selected luminaire(s).
Note: You should set your display mode to
solid to ensure that you are picking a surface.
The selected luminaire(s) is aimed at the specified
point.
Selected luminaire oriented toward yellow crosshair
