SIPPBX 6200S/GS/N V3.1 Upgrade
Procedure
Prior to start the upgrade procedure, please make sure the latest 3.0 firmware is
installed correctly. Please do the upgrade in local area network and make sure the
SIPPBX 6200S/GS/N will not be restarted during the upgrade. Otherwise, SIPPBX 6200S
GS/N might not boot correctly after upgrade.
Setp1. Backup old configuration for unexpected upgrade result or
downgrade
Crate backup directory:
cd C:\
mkdir 6200bak
cd 6200bak
mkdir dbfile
mkdir binfile
mkdir cdr
FTP Backup Command:
ftp xxx.xxx.xxx.xxx
prompt off
binary
cd d:\
lcd c:\6200bak
cd d:\ap\binfile
lcd c:\6200bak\binfile
mget *
cd d:\ap\dbfile
lcd d:\6200bak\dbfile
mget *
cd d:\ap\cdr
lcd c:\6200bak\cdr
mget *
(Backup Example)

Advertisement

loading
Need help?

Need help?

Do you have a question about the SIPPBX 6200GS - V3.1 UPGRADE PROCEDURE and is the answer not in the manual?

Questions and answers

Related Manuals for WELLTECH SIPPBX 6200GS - V3.1 UPGRADE PROCEDURE

Summary of Contents for WELLTECH SIPPBX 6200GS - V3.1 UPGRADE PROCEDURE

  • Page 1 SIPPBX 6200S/GS/N V3.1 Upgrade Procedure Prior to start the upgrade procedure, please make sure the latest 3.0 firmware is installed correctly. Please do the upgrade in local area network and make sure the SIPPBX 6200S/GS/N will not be restarted during the upgrade. Otherwise, SIPPBX 6200S GS/N might not boot correctly after upgrade.
  • Page 2 Microsoft Windows XP [Version 5.1.2600] (C) Copyright 1985-2001 Microsoft Corp. C:\>ftp 192.168.19.52 Connected to 192.168.19.52. 220 Connected to FTPD User (192.168.19.52:(none)): root 331 Password required for root. Password: 230 User root logged in. ftp> prompt off Interactive mode Off . ftp>...
  • Page 3 226 [Bytes: 1630534][Time: 1.56 s][Speed: 1018.76 K/s] ftp: 1630534 bytes received in 1.56Seconds 1043.88Kbytes/sec. 200 PORT command successful. 150 Opening BINARY mode data connection for SiPBX.bin (5409391 bytes). 226 [Bytes: 5409391][Time: 5.11 s][Speed: 1033.98 K/s] ftp: 5409391 bytes received in 5.11Seconds 1058.80Kbytes/sec. 200 PORT command successful.
  • Page 4 226 [Bytes: 0][Time: 0.01 s][Speed: 0.00 K/s] 200 PORT command successful. 150 Opening BINARY mode data connection for Broadcasting.ini (143 bytes). 226 [Bytes: 143][Time: 0.01 s][Speed: 13.96 K/s] ftp: 143 bytes received in 0.00Seconds 143000.00Kbytes/sec. 200 PORT command successful. 150 Opening BINARY mode data connection for CDRMgr.ini (2384 bytes). 226 [Bytes: 2384][Time: 0.01 s][Speed: 232.81 K/s] ftp: 2384 bytes received in 0.00Seconds 2384000.00Kbytes/sec.
  • Page 5 150 Opening BINARY mode data connection for IPMBoardSet.ini (513 bytes). 226 [Bytes: 513][Time: 0.01 s][Speed: 50.10 K/s] ftp: 513 bytes received in 0.00Seconds 513000.00Kbytes/sec. 200 PORT command successful. 150 Opening BINARY mode data connection for License.ini (405 bytes). 226 [Bytes: 405][Time: 0.01 s][Speed: 39.55 K/s] ftp: 405 bytes received in 0.00Seconds 405000.00Kbytes/sec.
  • Page 6 ftp: 269 bytes received in 0.00Seconds 269000.00Kbytes/sec. 200 PORT command successful. 150 Opening BINARY mode data connection for service.ini (35 bytes). 226 [Bytes: 35][Time: 0.01 s][Speed: 3.42 K/s] ftp: 35 bytes received in 0.00Seconds 35000.00Kbytes/sec. 200 PORT command successful. 150 Opening BINARY mode data connection for SetRoute.bat (250 bytes). 226 [Bytes: 250][Time: 0.01 s][Speed: 24.41 K/s] ftp: 250 bytes received in 0.00Seconds 250000.00Kbytes/sec.
  • Page 7 150 Opening BINARY mode data connection for SysLog.ini (1082 bytes). 226 [Bytes: 1082][Time: 0.01 s][Speed: 105.66 K/s] ftp: 1082 bytes received in 0.00Seconds 1082000.00Kbytes/sec. 200 PORT command successful. 150 Opening BINARY mode data connection for System.ini (247 bytes). 226 [Bytes: 247][Time: 0.01 s][Speed: 24.12 K/s] ftp: 247 bytes received in 0.00Seconds 247000.00Kbytes/sec.
  • Page 8 ftp: 62 bytes received in 0.00Seconds 62000.00Kbytes/sec. 200 PORT command successful. 150 Opening BINARY mode data connection for Weekday.ini (79 bytes). 226 [Bytes: 79][Time: 0.01 s][Speed: 7.71 K/s] ftp: 79 bytes received in 0.00Seconds 79000.00Kbytes/sec. 200 PORT command successful. 150 Opening BINARY mode data connection for WGOS.ini (735 bytes). 226 [Bytes: 735][Time: 0.01 s][Speed: 71.78 K/s] ftp: 735 bytes received in 0.00Seconds 735000.00Kbytes/sec.
  • Page 9 Password: 230 User root logged in. ftp> cd d:\ap\binfile 250 CWD command successful. ftp> Local directory now C:\6200_v3.0. ftp> 200 Type is set to I. ftp> prompt off Interactive mode Off . ftp> mput * 150 Opening BINARY mode data connection for OSAdmin.bin. 226 [Bytes: 1629288][Time: 1.72 s][Speed: 926.14 K/s] ftp: 1629288 bytes sent in 1.67Seconds 974.45Kbytes/sec.
  • Page 10 Import “servicesetting.clf” Call Flow (download from Welltech technical support) Import and Save Service setting call 3. Import Call Auth PIN Call flow (Enhance Service > Call Flow Editor > Call Authorization PIN)
  • Page 11 Import “servicesetting.clf” Call Flow (download from Welltech technical support) Import and Save Service setting call...
  • Page 12 Step 6. Add new voice file for service setting used: FTP new voice upload Command: ftp xxx.xxx.xxx.xxx prompt off binary cd d:\voice\work\0 lcd c:\ss_patch\voice\work\0 mput * cd d:\voice\work\1 lcd c:\ss_patch\voice\work\1 mput * cd d:\voice\work\2 lcd c:\ss_patch\voice\work\2 mput * (Backup Example) C:\>ftp 192.168.19.52 Connected to 192.168.19.52.
  • Page 13 ftp: 20046 bytes sent in 0.00Seconds 20046000.00Kbytes/sec. 200 PORT command successful. 150 Opening BINARY mode data connection for rcDisableCallWaiting.wav. 226 [Bytes: 18116][Time: 0.01 s][Speed: 1179.43 K/s] ftp: 18116 bytes sent in 0.00Seconds 18116000.00Kbytes/sec. 200 PORT command successful. 150 Opening BINARY mode data connection for rcDisableCRBT.wav. 226 [Bytes: 23978][Time: 0.01 s][Speed: 1561.07 K/s] ftp: 23978 bytes sent in 0.00Seconds 23978000.00Kbytes/sec.
  • Page 14 226 [Bytes: 18116][Time: 0.02 s][Speed: 1105.71 K/s] ftp: 18116 bytes sent in 0.00Seconds 18116000.00Kbytes/sec. 200 PORT command successful. ftp> Setp7. Get New License from Welltech sales department for FAX-in Termination service Please send the following information to you sales in order to get the new version license key.
  • Page 15 After Reboot SIPPBX 6200S, you can see the Application: SIPPD Version: 3.0.4; Enhance SW(S) Version: 3.1.0...
  • Page 16 SIPPBX 6200 V3.1 Downgrade to V3.0 Procedure You need to have the backup files from V3.1 Upgrade Procedure Step 2. Otherwise, you cannot do the downgrade procedure. Step 1: Restore the backup firmware and configuration Microsoft Windows XP [Version 5.1.2600] (C) Copyright 1985-2001 Microsoft Corp.
  • Page 17 ftp: 2918511 bytes sent in 3.19Seconds 915.47Kbytes/sec. 200 PORT command successful. 150 Opening BINARY mode data connection for OSAdmin.bin. 226 [Bytes: 1630534][Time: 1.89 s][Speed: 842.05 K/s] ftp: 1630534 bytes sent in 1.88Seconds 869.62Kbytes/sec. 200 PORT command successful. 150 Opening BINARY mode data connection for SiPBX.bin. 226 [Bytes: 5409391][Time: 6.44 s][Speed: 820.54 K/s] ftp: 5409391 bytes sent in 6.39Seconds 846.41Kbytes/sec.
  • Page 18 ftp> lcd c:\6200bak\dbfile Local directory now C:\6200bak\dbfile. ftp> mput * 200 PORT command successful. 150 Opening BINARY mode data connection for aaaclient.ini. 226 [Bytes: 1010][Time: 0.01 s][Speed: 98.63 K/s] ftp: 1010 bytes sent in 0.02Seconds 63.13Kbytes/sec. 200 PORT command successful. 150 Opening BINARY mode data connection for ACDTeller.ini.
  • Page 19 200 PORT command successful. 150 Opening BINARY mode data connection for ENHANCE.GDB. 226 [Bytes: 1089536][Time: 1.30 s][Speed: 820.99 K/s] ftp: 1089536 bytes sent in 1.28Seconds 849.87Kbytes/sec. 200 PORT command successful. 425 ENHANCE_V3.GDB: The system cannot write to the file specified. 200 PORT command successful.
  • Page 20 200 PORT command successful. 150 Opening BINARY mode data connection for proxyserver.ini. 226 [Bytes: 366][Time: 0.01 s][Speed: 35.74 K/s] ftp: 366 bytes sent in 0.00Seconds 366000.00Kbytes/sec. 200 PORT command successful. 150 Opening BINARY mode data connection for RoutingTable.txt. 226 [Bytes: 135][Time: 0.01 s][Speed: 13.18 K/s] ftp: 135 bytes sent in 0.00Seconds 135000.00Kbytes/sec.
  • Page 21 226 [Bytes: 4010][Time: 0.02 s][Speed: 244.75 K/s] ftp: 4010 bytes sent in 0.01Seconds 267.33Kbytes/sec. 200 PORT command successful. 150 Opening BINARY mode data connection for SIPPD.mdb. 226 [Bytes: 1769472][Time: 2.08 s][Speed: 831.57 K/s] ftp: 1769472 bytes sent in 2.06Seconds 858.13Kbytes/sec. 200 PORT command successful.
  • Page 22 200 PORT command successful. 150 Opening BINARY mode data connection for vlan.cfg. 226 [Bytes: 3032][Time: 0.01 s][Speed: 197.40 K/s] ftp: 3032 bytes sent in 0.00Seconds 3032000.00Kbytes/sec. 200 PORT command successful. 150 Opening BINARY mode data connection for VMSNotify.ini. 226 [Bytes: 1888][Time: 0.02 s][Speed: 115.23 K/s] ftp: 1888 bytes sent in 0.01Seconds 125.87Kbytes/sec.
  • Page 23 Setp4. Reboot SIPPBX 6200 and Check Service Status After Reboot SIPPBX 6200S, you can see the Application: SIPPD Version:3.0.3R; Enhance SW Version: 3.0.2...
