Draper EZ FOLD TF-20 Specifications

EZ Fold
Top-of-T
4" OD 11 ga. tubing
Side Brace
2¼" OD 14 ga. tubing
Main Stem
6" OD 11 ga. tubing
Main stem
Direct Mount
goal brace
Side View/Goal Brace Detail
"Goal Brace" feature attaches directly
behind goal mounting plate and directly to
main stem of backstop, which eliminates
strain on backboards.
Draper offers a 25-year limited warranty on the EZ Fold bas ket ball
backstop structure. No other bas ket ball back stop man u fac tur er offers
you this protection. For a copy of the EZ Fold back stop warranty in its
entirety, contact Draper, Inc.
®
Copyright © 2011 Draper Inc. Form EZ-TF-20_Sub11
®
TF-20
Printed in U.S.A.
Basketball Backstop—Ceiling-Suspended,
Forward-Folding, Front-Braced
1. Superstructure supplied for existing
conditions.
2. Contact Draper for Dimensions A & B.
Jackknife (adjustable)
2¼" OD 14 ga. tubing
2½" OD 13 ga. tubing
Shown with
Rectangular
Glass Bank
(72" x 42")
Padding
Face of bank to C L of stem
Bank No. & Type
503152 72" x 48" Rect. Glass
503136 72" x 42" Rect. Glass
503151 72" x 48" Rect. Wood
503140 72" x 42" Rect. Wood
503153 72" x 48" Rect. Fiberglass
503144 72" x 42" Rect. Fiberglass
503154 72" x 48" Rectangular Steel 10
503167 72" x 42" Rectangular Steel 10
5031500 Fan Glass
503148 Fan Fiberglass
503143 Fan Aluminum
PROJECT:
ARCHITECT:
CONTRACTOR:
SUPPLIER:
DATE:
by
¼" Aircraft cable (7000#)
Dim. C
w/o Ht. Adj w Ht. Adj
1
11 / "
4
1
11 / "
4
1
11 / "
8
9
10 / "
16
1
10 / "
2
1
10 / "
2
1
/ "
2
1
/ "
2
11"
1
10 / "
2
3
10 / "
16
