MINOURA RDA80 - SCHEMATICS Manual

RDA80 Schematics
ER-3
ER-1
ER-7
ER-8
ER-2
Screw-L
ER-4
ER-5
Screw-S
ER-9
ER-6
F-1 : Coupling (Right)
F-2 : Coupling (Left)
F-4 : Coupling Cover (move side)
F-7 : Hub Handle (3/8" thread)
F-8 : Wheel Position Adjust Knob
F-9 : Hub Nut Protector (Grommet)
R8-1 : RDA80 Main Frame
M8-3 : Rubber Frame Cap (38mm)
M8-4 : Rubber Foot Cap (32mm)
SR-5 : V-Belt (K-16)
SR-7 : Drive Roller Pulley
SR-8 : Assistant Roller Pulley
SR-12 : Cap Bolt (M6x12)
SR-13 : Reinforcement Plate
Screw-M
SR-12
M8-3
ER-10
SR-5
ER-11
Screw w/ washer
ER-15
Screw-M
F-4
F-8
R8-1
SR-13
SR-7
ER-12
ER-1 :
ER-2 :
ER-3 :
ER-4 :
ER-5 :
ER-6 :
ER-7 :
ER-8 :
ER-9 :
ER-10 :
ER-11 :
ER-12 :
ER-13 :
ER-14 :
ER-15 :
-  -
F-2 F-4
F-9
F-1
SR-12
M8-4
SR-8
ER-13
<Remote Version>
Upper Case
Lower Case
Top Cover (blue)
Magnet Guide Ring (blue)
Dial Lever (blue)
Spring Holder
Flywheel, Alloy Rotor & Axle
Magnet
Spring
Main Arm
Sub Arm
Pulley Arm
Assistant Pulley Holder
Tension Lever
Remote Bracket & Cable
F-7
M8-4
M8-3
ER-14
