Congratulations on purchasing this AIRIS LRD TV.
This guide will help you to start using its basic functions and identify the parts of
the screen.
Front Part
1. Speakers
2. Raise channel
3. Lower channel
4. Raise volume
5. Lower volume
6. Menu
Rear Part (connections)
QUICK START
11
3
4
2
7. Automatic image adjustment/exit
from signal OSD
8. ON/signal selector
9. STANDBY/Operation indicator:
on green when the screen is
functioning
10. Infrared sensor
8
6
5
7
2
3
4
5
6
7
8
9
10
10
9
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AIRIS M137
Summary of Contents for AIRIS M137
- Page 1 QUICK START Congratulations on purchasing this AIRIS LRD TV. This guide will help you to start using its basic functions and identify the parts of the screen. Front Part 1. Speakers 7. Automatic image adjustment/exit 2. Raise channel from signal OSD 3.
- Page 2 Rear Part (connections ) (cont.) 1. S-Video input 7. Compound video & stereo audio 2. Euroconnector input input 3. Audio input for connections 8. Compound video & stereo audio by components input 4. Video inputs by components 9. Stereo audio input (3.5 mm mini- (interlinked YCbCR and Progressive jack) for VGA and DVI video YPbPr)
- Page 3 Remote Control Device Descriptoin (cont.) To insert a one-digit number use the numerical keys from 0 to 9. To insert a two-digit number (10-99) first press any button from 0-9 to insert the first digit and then the second digit in less than 2 seconds, using the buttons from 0-9.
- Page 4 14. Image Button: press this button to select the different image modes from among Personal, Bright, Medium and Standard. 15. AUTO Button: press this button to adjust the image automatically. (continues on next page) (continued from previous page) Remote Control Device Description (cont.) 16.
- Page 5 Channel-Tuning To start tuning in the TV channels, check that the aerial is properly connected and that you have selected the channel setting menu on the screen. FIGURE 1 The menu has the following options: Colour system: the options available are PAL, AUTO and NTSC. It is advisable to leave it on AUTO.
- Page 6 The menu has the following options: Search Mode: Tune in or Surf. Select the SURF option if the TV system is NTSC. Select Tune In if the TV system is PAL. Aerial Type: this enables you to choose between cable or Air. Select AIR to tune in the channels available in Spain.
- Page 7 Lastly, press the MENU key to confirm the change. Follow the same steps with any of the channels you wish.
