Linear series am/fm stereo receiver with dvd/cd player
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LS5000DVD_UM.qxp
4/18/05
OWNER'S MANUAL
LS5000DVD
AM/FM Stereo Receiver with DVD/CD Player
Designed for In-Wall Installation of Recreational Vehicles, Motor Homes and Mobile Housings
Manufactured under license from Dolby Laboratories.
"Dolby" and the double-D symbol are trademarks of
Dolby Laboratories.Confidential Unpublished works.
© 1992-1997 Dolby Laboratories Inc. All rights reserved.
10:37
Page 1
A Registered Trademark of Magnadyne Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LS5000DVD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dolby Laboratories LS5000DVD

  • Page 1 Designed for In-Wall Installation of Recreational Vehicles, Motor Homes and Mobile Housings Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.Confidential Unpublished works. © 1992-1997 Dolby Laboratories Inc. All rights reserved. A Registered Trademark of Magnadyne Corporation...

  • Page 2: Controls And Functions

    LS5000DVD_UM.qxp 4/18/05 10:37 Page 2 INTRODUCTION Please take the time to read all of the information in this manu- al. Familiarity with installation and operation procedures will help you obtain the best possible performance from your new AM/FM Stereo Receiver with DVD/CD Player. CONTROLS AND FUNCTIONS WARNING! To prevent fire or electrical shock hazard, do not expose this product to moisture, or remove cover or bottom...
  • Page 3 LS5000DVD_UM.qxp 4/18/05 10:37 Page 3 CONTROLS AND FUNCTIONS 1. Power / Mode Button (PWR) Press and hold to turn the unit On/Off. Momentarily press to switch modes from Radio to AUX IN to DVD. 2. Select Button (SEL) Selects the audio mode in the following order: Volume, Bass, Treble and Balance.

  • Page 4: Remote Control Functions

    LS5000DVD_UM.qxp 4/18/05 10:37 Page 4 REMOTE CONTROL FUNCTIONS SOURCE SUBTITLE MENU BAND/SET UP DISP ENTER REPEAT ZOOM – VOLUME ADJUSTMENT 1. Power / Mode Button (PWR) 2. Menu 3. Display Button (DISP) 4. Fast Forward / Fast Reverse Buttons 5. Skip Up / Skip Down Buttons TITLE 6.

  • Page 5: General Operations

    LS5000DVD_UM.qxp 4/18/05 10:37 Page 5 GENERAL OPERATIONS Power On/Off Press and hold the Power / Mode button to turn the unit On or Off. Auxiliary Input Mode To access auxiliary devices, press the Power / Mode button momentarily until "AUX IN" appears in the display. DVD Mode To play a CD or DVD, press the Power / Mode button momentarily until "DVD ON"...

  • Page 6: Sound Controls

    LS5000DVD_UM.qxp 4/18/05 10:37 Page 6 RADIO OPERATION Automatically Store Stations Select a Band (if needed). Press and hold the AS/PS button for more than three seconds. The tuner will search for the six strongest stations and store them in memory. The new sta- tions replace stations that were already stored in the current band.

  • Page 7: Alarm Operation

    LS5000DVD_UM.qxp 4/18/05 10:37 Page 7 ALARM OPERATION The alarm is used to power the unit On at a set time, and to power the unit Off at another set time. Setting the Alarm Timer 1. Press and hold the Alarm button until the display shows “ON A 0:00”.

  • Page 8: Disc Warnings

    LS5000DVD_UM.qxp 4/18/05 10:37 Page 8 DISC WARNINGS Handling a Disc 1. When inserting a disc onto the disc hub, hold it with your thumb, middle finger and index finger. Gently press in the center of the disc until it is securely on the hub. 2.

  • Page 9: Random Feature

    LS5000DVD_UM.qxp 4/18/05 10:37 Page 9 COMPACT DISC OPERATION the disc at that point. To fast reverse through a track during CD play, press and hold the Fast Reverse button. Release the button to play the disc at that point. Track Search To search forwards or backwards for a specific track on a disc, press the Skip Up / Skip Down buttons until you reach the one that you want to listen to.

  • Page 10: Dvd Operation

    LS5000DVD_UM.qxp 4/18/05 10:37 Page 10 DVD OPERATION General Operations 1. Press and hold the Power / Mode button to turn the unit On. 2. Press on the disc door next to the word “PUSH”, the door will open slightly. Then gently pull the door fully open. 3.

  • Page 11: Initial Dvd Setup

    LS5000DVD_UM.qxp 4/18/05 10:37 Page 11 DVD OPERATION Menu Function Press the Menu button during disc play and the main disc “Root Menu” will be displayed. Scroll through the menu with either the Skip Up / Skip Down buttons or the Fast Forward / Fast Reverse buttons.
  • Page 12 LS5000DVD_UM.qxp 4/18/05 10:37 Page 12 INITIAL DVD SETUP General Submenu Setup -- GENERAL PAGE -- PIC MODE AUTO ANGLE MARK FILM OSD LANG VIDEO CAPTIONS SMART SUPER SMART MAIN PAGE GENERAL SETUP Use the Skip Up / Skip Down buttons or the Fast Forward / Fast Reverse buttons to scroll between the menu items.
  • Page 13 LS5000DVD_UM.qxp 4/18/05 10:37 Page 13 INITIAL DVD SETUP Preferences Setup Submenu -- PREFERENCES PAGE -- TV DISPLAY NORMAL / PS TV TYPE NORMAL / LB AUDIO WIDE SUBTITLE DISC MENU PARENTAL PASSWORD DEFAULTS SMARTNAVI MAIN PAGE SET PREFERENCES Use the Skip Up / Skip Down buttons or the Fast Forward / Fast Reverse buttons to scroll between the menu items.

  • Page 14: Installation

    LS5000DVD_UM.qxp 4/18/05 10:37 Page 14 INSTALLATION Wall Panel Structural Stud " End Caps Caution: Do not install radio without rear cover installed. No user-serviceable parts inside. Rear cover provides protection against potential fire hazard.

  • Page 15: Power Connections

    LS5000DVD_UM.qxp 4/18/05 10:37 Page 15 POWER CONNECTIONS This unit for use only with a 12 Volt DC power source with a negative ground. RED Wire (+) To 12 Volt DC Power BLACK Wire (-) Ground...

  • Page 16: Speaker Connections

    LS5000DVD_UM.qxp 4/18/05 10:37 Page 16 SPEAKER CONNECTIONS Left Speaker (A) Left Speaker (B) Speaker Connections: Do not confuse the A and B speaker sets. BROWN Wire ORANGE Wire GREEN Wire Right Speaker (A) GRAY Wire WHITE Wire BLUE Wire Right Speaker (B)

  • Page 17: Antenna Connections

    If an automotive antenna is not available or is undesired, we recom- mend the use of a Magnadyne DP36AXT di-pole antenna substitute. Insert the male plug from the DP36AXT into the female receptacle of the LS5000DVD unit and allow the cable of the antenna to lay inside the wall.

  • Page 18: Auxiliary Connections

    LS5000DVD_UM.qxp 4/18/05 10:37 Page 18 AUXILIARY CONNECTIONS VCR with Line Out A/V In RCA Connectors: Yellow - Video Input Red - R-CH Input White - L-CH Input Aux Audio Input: Left and Right RCA type input jacks are provided on the back panel for connection to a second sound source such as a TV system or component cassette deck.

  • Page 19: Safety Instructions

    LS5000DVD_UM.qxp 4/18/05 10:37 Page 19 SAFETY INSTRUCTIONS Read Instructions: All the safety and operating instructions should be read before the appliance is operated. Retain Instructions: The safety and operating instructions should be retained for future reference. Heed Warnings: All warnings on the appliance and in the oper- ating instructions should be adhered to.

  • Page 20: Operation And Maintenance

    LS5000DVD_UM.qxp 4/18/05 10:37 Page 20 OPERATION AND MAINTENANCE Damage Requiring Service: The appliance should be serviced by qualified personnel when: A. Objects have fallen, or liquid has spilled into the appliance; or B. The appliance has been exposed to rain; or C.
