- Page 1 DVD HOME THEATER SYSTEM CD-R VIEWER AV I N P U T OWNER'S MANUAL...
-
Page 2: Important Safety Instruction
Important Safety Instructions WARNING WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO... - Page 3 Important Safety Instructions 1. Read Instructions - All the safety and operating instructions should be read before the appliance is operated. 2. Retain Instructions - The safety and operating instructions should be retained for future reference. 3. Heed Warnings - All warnings on the appliance and in the operating instructions should be adhered to. 4.
-
Page 4: Table Of Contents
Important Safety Instruction ... 1-2 Disc Formats ... 4 Before You Start ... 5 Using the remote control ... 5 Parts and Functions ... 6-8 Remote Control ... 6-7 Front and Top Panel ... 8 Display ... 9 Front Panel Display ... 9 Display Information ... -
Page 5: Disc Formats
The Unit can playback. DVDs [8cm(3")/12cm(5”) disc] Audio CDs [8cm(3")/12cm(5”) disc] Region Management Information Region Management Information: This Unit is designed and manufactured to respond to the Region Management Information that is encoded on DVD discs. If the Region number printed on the DVD disc does not correspond to the Region number of this Unit, this Unit cannot play that disc. -
Page 6: Before You Start
Using the Remote Control • Point the Remote Control at the REMOTE SENSOR located on the Unit. • When there is a strong ambient light source, the performance of the infrared REMOTE SENSOR may be degraded, causing unreliable operation. • The recommended effective distance for remote operation is about 16 feet (5 meters). To install Batteries 1. -
Page 7: Parts And Functions
Remote Control S TA N D B Y /O N R E T U R N F U N C T IO N P. S C A N / M E M O RY C V B S D IM M ER PR O LO GIC II V O L U M E S E T U P... -
Page 8: Remote Control
Remote Control O P E N / S TA N D B Y /O N C LO S E F U N C T IO N R E T U R N G O TO P. S C A N / S O U N D M EM O RY C V B S... -
Page 9: Front And Top Panel
Front and Top Panel 1) Disc tray Open or close tray by pushing OPEN/CLOSE button. Place a disc on the disc tray, label side up. 2) STANDBY indicator When the Unit is turned on by pressing the STANDBY/ON button, the light will illuminate a few seconds. -
Page 10: Display
Front Panel Display DOLBY PRO LOGIC II indicator When Dolby Pro Logic sound is selected in AV_IN mode, the light will illuminate. DOLBY DIGITAL indicator Displays while Dolby Digital sound processing is being performed or when the loaded disc contains Dolby Digital sound ANGLE indicator Appears when multiple camera... -
Page 11: Setup
A. Connecting a TV The Unit can be connected to your TV in several different ways, depending on the design of your TV. RCA Audio/Video cable Use the supplied Audio/Video cable. 1. Connect the VIDEO OUT and left/right AUDIO OUT jacks on the unit to the VIDEO IN and left/right AUDIO IN jacks on your TV. - Page 12 Component video outputs (DVD) Some TVs or monitors are equipped with component video inputs. Using the Audio cable (not supplied), connect the left/right AUDIO OUT jacks on your Unit to the left/right AUDIO IN jacks on your TV and the Component video cable (not supplied), connect the Green plug Y VIDEO OUT jack on your Unit to Y VIDEO IN jack on your TV, the Blue plug P and the Red plug P VIDEO OUT jack on your Unit to P...
-
Page 13: Connecting A Vcr
B. Connecting a VCR 1. Using the supplied Audio/Video cable, connect the yellow plug from VIDEO OUT jack on your Unit to VIDEO IN jack on your TV, connect the left/right AUDIO OUT jacks on your Unit to left/right AUDIO IN jacks on your TV. If you want the sound come from the speakers of the Main Unit, you need not to connect the left/right AUDIO... -
Page 14: Connecting The Speakers & Subwoofer
D. Connecting the speakers & subwoofer The speaker cords have been color-coded to simplify connection. Just plug the POSITIVE (+) and NEGATIVE (-) ends of each speaker wire into the corresponding jacks on the rear of the Unit, matching the color tube on the end of the speaker wire to the color-coded connector. -
Page 15: Mounting Rear Surround Speakers
Mounting rear surround speakers 1) Mark the correct mounting position on the wall. 2) Insert a fixing screw(s) at the marked position on the wall. 3) Align the slot hole(s) of the speaker over the screw and pull the speaker downward until it is firmly hooked. DO NOT RETURN THIS TO THE STORE Please call Customer Service at 1-800-252-6123 or visit online help at http://www.1800customersupport.com... -
Page 16: Adjusting The Sound
Bass and treble control the sound from the front left and right speakers. Dolby Digital Dolby Digital is a sound system developed by Dolby Laboratories Inc. that gives movie theatre ambience to audio output when the Unit is connected to a Dolby Digital 5.1 channel processor or amplifier. -
Page 17: Adjusting The Sound
FM stereo reception can otherwise cause disturbing surround signals from a logic decoder. The ultimate "cure" for poor FM stereo reception may be simply to force the audio to mono. Manufactured under license from Dolby Laboratories. 'Dolby' , 'Pro Logic' and the double-D symbol To select the listening channel 1. -
Page 18: Playing A Disc
Basic playback This owner’s manual explains the basic instructions of this DVD Unit. Some DVD discs are produced in a manner that allows specific or limited operation during playback. As such, the DVD Unit may not respond to all operating commands. This is not a defect in the DVD Unit. Refer to the instruction notes of discs. -
Page 19: Fast Foward/Fast Reverse
Fast Forward/Fast Reverse 1. Press the SEARCH SEARCH button when a disc is playing. • The disc begins fast scan at x2 speed. • Four speeds are available. Each time SEARCH button is pressed, the speed of fast scan changes in the following sequence: Note : You also can press... -
Page 20: Angle Selection
Angle selection Some DVDs contain scenes which have been shot from a number of different angles. For these discs, the same scene can be viewed from each of these different angles. 1. While you are playing a DVD with different angles recorded, press the ANGLE button to view the number of the current angle. -
Page 21: Special Functions
Basic playback DISPLAY function Using DISPLAY, you can check and change the current settings of the following items: ANGLE, AUDIO and SUBTITLE. • While the disc is playing, press the DISPLAY button to display the screen shown below. Elapsed time: Elapsed time from the beginning of the chapter which is currently playing. Remaining time: Remaining time of the title which is currently playing. -
Page 22: Locating A Specific Title
Basic playback Locating a specific title If a DVD disc contains title numbers, you can locate a specific title by directly selecting a title number. 1. In stop mode, press the GOTO button. 2. Press button to highlight a specific field and press the corresponding number button(s) for the title you want. -
Page 23: Special Functions
Basic playback Locating a specific time You can move to a specific location by entering its corresponding time (hours, minutes, seconds) 1. Press the GOTO button. 2. Press button to highlight time. 3. Press the corresponding number buttons for the setting point you want. •... -
Page 24: Cd / Dvd Programmable Memory
Advanced CD / DVD programmable memory playback Programmable memory The two types of programmed playback provided by this Unit are title programmed playback and chapter programmed playback. Title / Chapter programmed playback 1.Press the MEMORY button while the disc is stopped. 2.Enter the title numbers in . -
Page 25: Repeat Playback
Advanced playback You can play a specific title or chapter repeatedly. (Title repeat, chapter repeat, A-B repeat) Repeating a title You can play the same title repeatedly. 1. While the disc is playing, press the REPEAT DISC button until the “ indicator displays on the screen. -
Page 26: Playing Mp3 And Picture File Disc
Playing MP3 and Picture File Disc This Unit will play MP3 and Picture files recorded on CD-R discs Playing a MP3 file disc 1. Press the OPEN /CLOSE button, the disc tray opens. 2. Insert a MP3 file disc on the disc tray with the label side up. 3. -
Page 27: Playing A Picture File Disc
Playing MP3 and Picture File Disc Playing a Picture file disc 1. Press the OPEN /CLOSE button, the disc tray opens. 2. Insert a Picture CD on the disc tray with the label side up. 3. Press the OPEN/CLOSE button, the disc tray closes. 4. -
Page 28: Customizing The Function Settings
Customizing the Function Settings LANGUAGE setting 1. Press the FUNCTION button until DVD appears on the display. 2. Press the STOP button so that no disc is playing. 3. Press the SETUP button. 4. Use button to select the Language, then press the ENTER button. 5. -
Page 29: Video Output
Customizing the Function Settings Cut off when a wide-screen video image is played. 4:3 Pan Scan • When wide-screen video material is played, this mode clips the right and left 4:3 Letter Box • When wide-screen video material is played in this mode on a conventional TV 16:9 Wide-screen •... -
Page 30: Brightness
Customizing the Function Settings Brightness 1. Press the SETUP button. 2. Use button to select Video, then press the ENTER button. 3. Use button to select Brightness, and then press the ENTER button. 4. Use button to shift and select the Off/On, then press the ENTER button. 5. -
Page 31: Audio Setting
Customizing the Function Settings AUDIO setting Digital Out 1. Press the SETUP button. 2. Use button to select Audio, press the ENTER button. 3. Use button to select Digital Out, and then press the ENTER button repeatedly to select Digital Out type. 4. -
Page 32: Subwoofer
Customizing the Function Settings Subwoofer 1. Press the SETUP button. 2. Use button to select the Audio, press the ENTER button. 3. Use button to Subwoofer, and then press the ENTER button. 4. Use button to select the desired setting, and then press the ENTER button. 5. -
Page 33: Center Delay
Customizing the Function Settings Center Delay 1. Press the SETUP button. 2. Use button to select the Audio, press the ENTER button. 3. Use button to Center delay, then repeatedly press the ENTER button to select the desired Center Delay type. -
Page 34: Rating Setting
Customizing the Function Settings RATING setting Password/Parental lock DVD discs equipped with the password function are rated according to their content. The contents allowed by a parental lock level and the way a DVD disc can be controlled may vary from disc to disc. For example, if the disc allowed, you could edit out violent scenes unsuitable for children and replace them with more suitable scenes, or you could lock out playback of the disc altogether. -
Page 35: Factory Set
Customizing the Function Settings Factory Set If you want to return the initial language setting to the factory default, do the following: 1. Press the SETUP button. 2. Use button to select the Rating, then press the ENTER button. 3. Use button to shift and select the Factory Set, then press the ENTER button. -
Page 36: Language Code List For Disc Language
Language Code List for Disc Language - 35 -... -
Page 37: Maintenance
Cleaning Disc A defective or soiled disc inserted into the Unit can cause sound to drop out during playback. Handle the disc by holding its inner and outer edges. • Do NOT touch the surface of the unlabeled side of the disc. •... -
Page 38: Trouble Shooting Guide
SYMPTOM CAUSE (AND REMEDY) • The location and orientation of the antenna are incorrect. If you use an indoor antenna, change to an outdoor antenna. • The TV antenna wire is too close to the Unit. Separate the antenna wire of the TV set from the Unit.
