YURAKU YUR.BEAT CAPSULE SPEAKER G2 Instruction Manual

INSTRUCTION MANUAL
Capsule
Speaker
Yur.Beat Capsule Speaker G2
MINIMUM SIZE. MAXIMUM SOUND.
version 1.00
Yur.Beat Capsule Speaker G2
CONNECTION DIAGRAM
USB interface
1 2 Mini-USB interfaces
for charging
+
Capsule
Speaker
3.5mm
3
Stereo
Plug
mobile phone
PSP iPod MP3/MP4
PC
Laptop
Connection:
Connect part 1 to 2 (mini-USB plug connects to Yur.Beat Capsule
Speaker G2)
Connect part 3 to any audio playback devices (3.5mm stereo plug to
any audio playback devices)
6
Yur.Beat Capsule Speaker G2
INTRODUCTION
Congratulations on your purchase of the Yur.Beat Capsule Speaker
G2. The Capsule Speaker G2 is a revolutionary portable audio
built-in bass support and rechargeable batteries. The design consists
of a patented vacuum bellow that mimics the resonance of a
ensure smooth delivery of the mid-highs. It comes with built-in
rechargeable batteries for easy usage and play time of up to 10 hours.
CAUTION
Please read manual
before using product
Safety Rules
• Please follow the rules depicted in this manual closely to ensure your safety.
Before using the speaker, we would strongly encourage you to read through
this user manual.
• Be more wary of any edges, uneven surfaces, metal parts, accessories and its
packaging so as to prevent any possible injury or damage.
Yur.Beat Capsule Speaker G2
• Keep this speaker out of reach of children. Take note that this speaker is not
edible and should not be placed in your mouth.
• Do not modify, repair or dismantle the speaker. Doing so may result in res,
electric shocks, complete breakdown of the speaker, etc. All of which, are not
covered under warranty.
• Do not use any diluents or volatile liquid to clean the speaker. Keep in mind
that the surface of the speaker should only be wiped with a clean dry cloth.
• Do not use this speaker in locations whereby there are high-temperatures or
high humidity levels (For instance, bathrooms); ideally, the speaker should be
used in a location free of dust and exposure to direct sunlight.
• Do not insert foreign objects, such as pins, into this speaker.
• Do not touch this speaker when your hands are wet as this may result in
electric shocks.
• Turn down the volume before/while using this speaker as sudden loud
sounds may damage it.
• Refrain from dropping the speaker as well as any collision with other objects.
• Do not use this speaker when in hazardous locations.
• Should any abnormal situations or problems occur while using the speaker,
discontinue use of speaker immediately.
2
Yur.Beat Capsule Speaker G2
CHARGING TECHNICAL SPECIFICATIONS
Yur.Beat CAPSULE SPEAKER G2
Net weight: 100g
size 52MM×52MM ×70MM Closed resonator
Speaker Magnetically shielded D36/ 4
Loudspeaker output <3.5W
Rating power 1.7W×2(2.8W×2 Input DC5V)
Frequency response 230HZ-18KHZ
USB OUTLET INPUT/AUDIO UNION CABLE CAPSULE SPEAKER G2
Lithium battery voltage 4.2V
Signal-to-Noise: 86db
1. The Yur.Beat Capsule Speaker G2 is rechargeable via
BATTERY
Standard USB type A interface connects to all PC USB ports
and safety certi ed AC Adaptors.
lithium battery capacity 280MAH
2. The LED on the Capsule Speaker G2 will turn Red during
lithium battery charging Voltage 5V/+0.5V
charging.
3. The LED will turn into Blue once the batteries are fully
charged.
4. General charging time is between 2 to 3 hours.
LED INDICATOR
When Charging When in Use
Blue Blue
G2 fully charged G2 is on
Red Blue (Dim)
G2 is charging Battery Low
7
Yur.Beat Capsule Speaker G2
PACKAGE CONTENTS
The package will contain the following:
• 1 x Capsule Speaker G2
• 1 x User Manual
• 1 x Input / audio union cable
• 1 x Protection Pouch
INSTRUCTION MANUAL
Capsule
Speaker
Capsule
Speaker
MINIMUM SIZE. MAXIMUM SOUND.
version 1.00
USER MANUAL Capsule Speaker G2
INPUT/AUDIO UNION CABLE BLACK POUCH
3
Yur.Beat Capsule Speaker G2
/3W
8
Yur.Beat Capsule Speaker G2
DIAGRAM
CAPSULE MODE
"MINI-SPEAKER"
TOP
DRIVER
LED
ON/OFF
BOTTOM
Separate the speakers from each
MINI-
other by gently pulling each speaker
LED
USB PORTS
apart from the Capsule Mode.
SPEAKER MODE
LEFT RIGHT
EXTENDABLE
RESONANCE
Hold onto the top of each speaker
and twist anti-clockwise to reveal the
SEPARABLE MAGNETIC BASE
4
Declaration of Conformity
Yur.Beat Capsule Speaker G2
EC-Declaration of Conformity to the essential requirements of
the
applicable 89/336/EEC as last amended by EC Directive
93/68/EEC
We, Yuraku Pte Ltd, declare under our sole responsibility as
authorized representative that the following product
Brand Name: Yuraku
Model Name: Capsule Speaker G2
Model No.: XAM2
Is fully in conformity with the essential requirement of the
European Council Directive 93/68/EEC.
This declaration is based on the full compliance of the product
with the following European standards:
EN 55022: 1998 + A1: 2000 + A2: 2003
EN 55024: 1998 + A1: 2001 + A2: 2003
9
Yur.Beat Capsule Speaker G2
MODE OF USAGE
CAPSULE MODE
The Yur.Beat Capsule Speaker G2 can be
connected at the bottom by a magnetic
base to form the Capsule Mode for easy
storage and increased portability.
SPEAKER MODE
resonator.
5
www.yuraku.com.sg
Product designed in Singapore
Manufactured in China
Manual printed in China
