INSTRUCTION MANUAL
AUTO POWER
DC TO DC POWER CONVERTER
MODEL #091-136-24-12
INPUT: 24 VOLTS DC
OUTPUT: 12 VOLTS, 3 AMPS DC
OUTPUT RIPPLE: 10 mv. RMS, maximum
KUSSMAUL ELECTRONICS CO., INC
170 CHERRY AVE., WEST SAYVILLE, N.Y. 11796
TEL: in NY 631-567-0314
3 YEAR WARRANTY
TOLL FREE: 800-346-0857
FILE: 091-136-24-12
DATE: 01-02-01
.
FAX: 631-567-5826
1
Advertisement
Table of Contents
Summary of Contents for KUSSMAUL 091-136-24-12
- Page 1 MODEL #091-136-24-12 INPUT: 24 VOLTS DC OUTPUT: 12 VOLTS, 3 AMPS DC OUTPUT RIPPLE: 10 mv. RMS, maximum 3 YEAR WARRANTY KUSSMAUL ELECTRONICS CO., INC 170 CHERRY AVE., WEST SAYVILLE, N.Y. 11796 TEL: in NY 631-567-0314 TOLL FREE: 800-346-0857 FAX: 631-567-5826...
- Page 2 INTRODUCTION The Model 091-136-24-12 is a switching power converter designed to operate a 12 volt device from a 24 volt battery. The output is filtered to provide an extremely low ripple so as not to interfere with a radio or other sensitive electronic devices. The device is vented and should be mounted in a dry location with adequate spacing to permit air circulation.
- Page 3 OUTPUT RIPPLE: 10mv. RMS. maximum WARRANTY All product of Kussmaul Electronics Company Inc. are warranted to be free of defects of material or workmanship. Liability is limited to repairing or replacing at our factory, without charge, any material or defects which become apparent in normal use within 3 years from the date the equipment was shipped.
