Summary of Contents for Directed Video VS102
- Page 1 A/V Selector MODEL VS © 2006 Directed Electronics, N85102 01-06 O O W W N N E E R R ’ ’ S S G G U U I I D D E E I I N N S S T T A A L L L L A A T T I I O O N N G G U U I I D D E E...
- Page 2 Specifications ..........8 © 2006 Directed Electronics - all rights reserved...
- Page 3 N N O O N N - - T T R R A A N N S S F F E E R R A A B B L L E E L L I I M M I I T T E E D D C C O O N N S S U U M M E E R R W W A A R R R R A A N N T T Y Y Directed Electronics, Inc. (Directed) promises to the original purchaser that the automotive video monitor...
- Page 4 W W h h a a t t i i s s I I n n c c l l u u d d e e d d A/V selector VS102 Source selector (qty 1) 2-IR extension cables (80”) Power harness 2-DIN cables 1-IR extension cable (195”) © 2006 Directed Electronics - all rights reserved...
- Page 5 Through years of critical testing and hand craftsmanship, we have created a wide range of video entertainment products for your viewing pleasure. To view other great products from Directed Electronics, please visit the Directed Video page at www.directed.com. F F e e a a t t u u r r e e s s This unit provides a 3-input and 3-output A/V selector system, with 3 hard wire remotes.
- Page 6 Pressing the button on the remote source selector switch will scroll the LED down consecutively. Each LED represents the video input source to be displayed to the video monitors. LED1 LED2 LED3 <A/V Source Select> © 2006 Directed Electronics - all rights reserved...
- Page 7 NOTE: The BLUE wire of the Power Harness connects to the emergency brake. All A/V outputs are enabled only when this wire is grounded. The 5A fuse, that is referenced on the POWER CABLE wiring chart, is located inside the attached noise filter box. © 2006 Directed Electronics - all rights reserved VS 102...
- Page 8 0dB (standard) 10Khz ±0.5dB 20Khz ±3.0dB -55dB or greater ±1dB or lower 7.6(W) x 5.4(H) x 1.1(D) inches 192(W) x 136(H) x 29(D) mm 1.3 lbs (570 grams) 6 oz (55 grams) (each) © 2006 Directed Electronics - all rights reserved...
- Page 9 The recipient of more than 20 patents in the field of advanced electronic technology, Directed is ISO 9001 registered. Quality Directed Electronics products are sold and serviced throughout North America and around the world. Call (800) 274-0200 for more information about our products and services.
