Using an ACP88 with a FireStudio 26x26 and DigiMax FS
8 channel XLR (M) - XLR (F) snake
FireStudio (back)
75 ohm BNC
DigiMax FS (back)
ACP88 (back)
PreSonus Audio Electronics | 7257 Florida Blvd, Baton Rouge, LA USA | Tel: 225-216-7887 | Fax: 225-926-8347 | www.presonus.com | sales@presonus.com
TS - TS
ADAT
TS - TS
XLR (M) - XLR (F)
Insert cables ( = TIP, = RING)
What you will need:
8 Insert cables
2 TS - TS cables
1 XLR (M) - XLR (F) cable
1 8 channel XLR (M) - XLR (F) snake
1 ADAT optical cable
1 75ohm BNC cable
