NOVAK SWITCH SYNTHESIZED FM MODULE Manual

Ready to get more frequencies? Choose any of the available channels without buying
another transmitter crystal. Now changing channels is as easy as rotating two dials.
Combine the Switch Module with Novak's XXtra synthesized receiver
and you have all the channels right at the tip of your fingers!
• I N S T A L L
• I N S T A L L
–First, remove the old module from the back of your M8 transmitter.
finger tabs to release.
–Next, insert the Switch Synthesized Module.
with the connector on the bottom of the module, and that the tabs on both sides of the module
'click' into the transmitter.
–With transmitter power turned off, select desired frequency channel by ro-
tating the 10 position dials until they point to the proper channel numbers.
Example: For Ch.76 (75MHz), rotate the left dial to '7' position and the right dial to '6' position.
NOTE: This module will only work with receivers that will accept positive shift
modulation. Compatible receivers include: Novak XXtra, Novak XXL, Airtronics, JR,
KO, and Multiplex receivers.
FCC NOTE: This device complies with part 15 and part 95 of the FCC rules
with the following condition: This device may not cause harmful interference.
Novak Electronics, Inc. guarantees the Switch transmitter module to be free from defects in materials and work-
manship for a period of 120 days from the original date of purchase (verified by dated, itemized sales receipt).
Warranty does not cover incorrect installation, components worn by use or excessive force, damage resulting from
using wrong receiver/crystal type, tampering with the electronics, allowing water, moisture, or any foreign material
to enter module or come in contact with the PC board, or any damage caused by vibration or shock.
Because Novak electronics, inc. has no control over connection and use of module, no liability may be assumed nor
will be accepted for damage resulting from the use of this product. Every module is thoroughly tested and tuned
before leaving our facility, and is therefore considered operational. By the act of installing/operating module, the
user accepts all resulting liability. In no case shall our liability exceed product's original cost. We reserve the right to
modify warranty provisions without notice.
2002 NOVAK ELECTRONICS, Inc.
S W
S W
SYNTHESIZED FM MODULE
A T I O N & O
A T I O N & O
The Switch meets all FCC radiation limits.
*No User Changeable Parts in this Module*

Product Warranty

I T C H
I T C H
P E R A T I O N I
P E R A T I O N
Be sure that the transmitter's pins align
All rights Reserved.
N T R U C T I O
I N T R U C T I O
#PB-2680-1
N S •
N S •
Squeeze
