  • Page 1 CONGRATULATIONS FEATURES / SPECIFICATIONS INSTALLATION WIRING POWER / GROUND CONNECTIONS CONNECTIONS (cont.) INPUTS / CONNECTIONS INPUTS C O N T E N T S (click on a topic to view) ENDPANEL LAYOUT ENDPANEL LAYOUT (cont.) TROUBLESHOOTING TROUBLESHOOTING (cont.) TROUBLESHOOTING (cont.) TROUBLESHOOTING (cont.) SYSTEM DIAGRAM 1 / 2 BLOCK DIAGRAM...

  • Page 2: For Your Records

    Thank you for choosing TUBE DRIVER. Tube Drivers musicality and absolute sonic transparency allow accurate reproduction of recorded music enabling you to hear as well as feel the music the way the artist intended. These handcrafted amplifiers feature full differential “front ends”...
  • Page 3 Fully regulated adaptive MosFET power supply Balanced Mini-Din Input High Voltage Input Capability with Input Attenuation Switch Gold Plated RCA Input connectors Mixed Mono/Stereo Operation Three Year Warranty when installed by an Authorized TD dealer S p e c i f i c a t i o n s Power Bandwidth: Total Harmonic Distortion: Input Topology:...
  • Page 4 To o l s / P a r t s N e e d e d f o r I n s t a l l a t i o n (not supplied) Small flat blade screwdriver Phillips screwdriver (#2 or medium sized) Wire cutters Wire strippers 4 –...
  • Page 5 P o w e r W i r e C a l c u l a t o r Recommended MINIMUM Gauge Total Current Draw (in Amps) 0 - 20 20 - 35 35 - 50 50 - 65 65 - 85 85 - 105 105 - 125 125 - 150...
  • Page 6 W a r n i n g ! To prevent a short to ground, disconnect the negative (-) terminal of the system’s battery before you begin. If the power cable shorts to ground, current will continue to flow until the short is opened, the main fuse blows, the battery explodes, or the wire melts.
  • Page 7 S p e a k e r C o n n e c t i o n s Follow these simple instructions and refer to the diagram below to make your speaker connections: • Using at least 16 gauge wire, run wire from the speakers to the amplifier(s) using the same precautions that you followed for running the power, ground, and remote wires •...
  • Page 8 B r i d g i n g All multi-channel T UBE DR IV E R S are capable of being bridged into a 4- Ohm mono output without switches or bridging modules. You can achieve this mono channel by using the left positive (+) speaker connection and the right negative (-) speaker connection.
  • Page 9 I n p u t J a c k s The TUBE DRIVER includes both RCA and Mini-Din (balanced) inputs. The supplied RCA connections allow you to use TUBE DRIVER with other brands of audio gear. Our Differential RCA inputs provide a dramatic improvement in noise reduction over standard RCA input types.
  • Page 10 I n p u t G a i n C o n t r o l There is an Input Gain Control located on the end panel under the RCA input jacks. This is not a volume control! This control matches the output signal voltage of the source unit to the amplifier inputs.

  • Page 11: Power / Ground

    P o w e r S i d e 1. POWER A red light indicates that the amplifiier is turned on (After warm-up sequence). 2. WARM UP A red light indicated that the tubes are warming up. (Refer to Pg. 4; Remote Turn-on) 3.
  • Page 12 I n p u t / C o n t r o l S i d e 1. SPEAKER OUTPUTS/REMOTE(Turn on) After connecting remote and speaker wires plug in the connector here. 2. GAIN CONTROL Use this control to match the output level of the head unit to the outputs of the amplifier 3.
  • Page 13 N o S o u n d Is the WARM UP LED illuminated? The warm up cycle can take up to 40 sec., Is there sound after that? Is there You’re done signal on the RCA’s? Contact your dealer A m p l i f i e r Tu r n i n g D o w n a t N o r m a l Vo l u m e Turn the system off, wait approx.
  • Page 14 N o S o u n d i n O n e C h a n n e l Check the pre-amp (RCA/Mini-Din) cables for open connections and make corrections. Did you find open connections? Reverse the left and right inputs. Opposite Channel Problem is further up the signal path.
  • Page 15 N o i s e s W h i l e t h e E n g i n e i s O n A l t e r n a t o r w h i n e : This noise changes in frequency with engine RPM.
  • Page 16 N o i s e s W h i l e t h e E n g i n e i s O n o r O f f S y s t e m h i s s : System hiss is a white noise that occurs even when the engine is off.
  • Page 17 Source Unit eject BASS BALANCE VOLUME LEFT LDX33 HIgh Pass TD275 Studio Driver System 2 Trk 1 TREBLE TRACK RIGHT FOWARD REVERSE Low Pass TD2150 Studio Driver 12" 4 ohm Woofer (Bridged) BACK TO CONTENTS...
  • Page 18 INPUT ATTENUATION BACK TO CONTENTS...
  • Page 19 Three-Year Limited U.S.A. Warranty This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. TUBE DRIVER warrants its products to be free from defects in materials and workmanship under normal use and service for a period of three (3) years from the date of original purchase when the unit is installed by an Authorized Dealer.
