SIR-PS1 Powered Subwoofer

User Guide

Table of Contents

Summary of Contents for Directed Electronics SIR-PS1

Page 1 SIR-PS1 Powered Subwoofer User Guide...
Page 2: Table Of Contents
Congratulations! Your new SIR-PS1 Powered Subwoofer lets you enjoy SIRIUS Satellite Radio digital entertainment to its fullest sonic range. Use this manual to install your Powered Subwoofer and to familiarize yourself with all the features and capabilities of the subwoofer. For the latest information about this and other products, visit www.directedsirius.com. For technical help regard- ing this product please contact Directed Electronics, Inc.
Page 4: Cleaning The Unit
Note: Before disconnecting the vehicle’s negative bat- tery lead, ensure that any required security code for the head unit is available. This code may be required to restore the head unit to normal operation. © Directed Electronics, Inc. all rights reserved—Sirius Powered Subwoofer User Guide...
Page 5: Mounting Subwoofer
Visually inspect the selected Sirius Powered Subwoofer User Guide—© Directed Electronics, Inc. all rights reserved mounting area underneath or the other side of the mounting surface to assure proper clearance is available for the mounting screws.
Page 6: Tuning
Adjust this control for the point where the bass sounds the most natural from your normal listening position. In most cases the “0” or “180” settings will be used. © Directed Electronics, Inc. all rights reserved—Sirius Powered Subwoofer User Guide...
Page 7: Back Panel Connections/Controls
Back Panel Connections/Controls Sirius Powered Subwoofer User Guide—© Directed Electronics, Inc. all rights reserved AUTO TURN OFF DELAY (Max. 5 Min) AUTO TURN ON LINE GAIN CROSSOVER PHASE INPUT Auto 70 Hz 160 0° 180° FUSE 20A HIGH LEVEL +12V...
Page 8: Back Panel Controls
Crossover adjust—allows adjustment of the crossover fre- quency (70 to 160 Hz). Phase adjust—allows adjustment of the audio phase between the input audio and the subwoofer speaker audio (0 to 180 degrees). © Directed Electronics, Inc. all rights reserved—Sirius Powered Subwoofer User Guide...
Page 9: Specifications
Input Sensitivity 0.2–8.0V Size—inches 8.9W x 10.7H x 10.6D x 8.4T (mm) (225W x 272H x 296D x 213T) Sirius Powered Subwoofer User Guide—© Directed Electronics, Inc. all rights reserved Powered Subwoofer High Level Input Weight Frequency Response Fuse Size Minimum Power Wire Gauge 5–50 watts...
Page 10: Limited One Year Consumer Warranty
THE CONSUMER AGREES AND CONSENTS THAT ALL DISPUTES BETWEEN THE CONSUMER AND DIRECTED SHALL BE RESOLVED IN ACCORDANCE WITH CALI- FORNIA LAWS IN SAN DIEGO COUNTY, CALIFORNIA. © Directed Electronics, Inc. all rights reserved—Sirius Powered Subwoofer User Guide 920-0020 06-05...
