Summary of Contents for Precision Power G38106
- Page 1 PowerClass ® COMPONENT SPEAKER SYSTEM...
-
Page 2: Practice Safe Sound
INTRODUCTION Thank you for your purchase of this PowerClass System from PrecisionPower ™ materials such as foamed prolypropylene cones and vapor-deposit titanium dome tweeters with cutting edge industrial design to achieve competition-ready performance levels. PRACTICE SAFE SOUND ™ Continuous exposure to sound pressure levels over 100dB may cause permanent hearing loss. -
Page 3: Tools Of The Trade
TOOLS OF THE TRADE Listed below are tools you may wish to have on hand before starting your installation. Having the proper tools will make the installation much easier. Some of these tools are necessities, some will just make the job easier. •... -
Page 4: Rear Deck Mounting
REAR DECK MOUNTING In rear deck installations, check the operation of the trunk suspension springs or tension bars. These tension bars can move when opening and closing the trunk and can exert a great deal of force against anything that obstructs their movement, such as a speaker basket or motor assembly. - Page 5 Step 6: Using the plastic grille ring as a template, mark the mounting holes with a pen. Step 7: Pre-drill mounting holes using a 1/8" drill bit. WARNING: Window mechanisms and electrical wires and other expensive car parts have a nasty habit of hiding where you least expect.
-
Page 6: Installing The Tweeter
NOTE: To remove the trim ring from the tweeter housing: 1. Rotate the trim ring a few degrees in a clockwise direction until you feel a detent. 2. Remove the trim ring by lifting it straight up. INSTALLING THE TWEETER SURFACE MOUNTING Step 1: Determine the tweeter mounting location, then route the wires from the crossover to the tweeter location. - Page 7 SURFACE MOUNT TRIM RING TWEETER TWEETER WIRE FLUSH MOUNTING INTO REMOVED PANELS Step 1: Determine the tweeter mounting location, then route the wires from the crossover to the tweeter location. Step 2: Mark the center point of the tweeter location. Step 3: If using a hole saw, first drill a pilot hole, then cut out the hole using a standard 2-1/8"...
- Page 8 TRIM RING FLUSH MOUNTING INTO MOUNTED PANELS Step 1: Determine the tweeter mounting location, then route the wires from the crossover to the tweeter location. Step 2: Mark the center point of the tweeter location. Step 3: If using a hole saw, first drill a pilot hole, then cut out the hole using a standard 2-1/8"...
-
Page 9: Installing The Crossover
Step 8: Screw the bolts in until the tweeter housing is firmly mounted to the panel. (Make sure the arrow at the rear of the tweeter housing is pointing in the desired direction.) Step 9: Insert the tweeter into the housing and attach trim ring. INSTALLING THE CROSSOVER Step 1: Find a location for the crossover away from any factory or aftermarket electrical wires. -
Page 10: Specifications
PC PASSIVE CROSSOVER (COVER REMOVED) Woofer To amplifier Tweeter SPECIFICATIONS Model Nominal Impedance Power Continuous/Peak Frequency Response Sensitivity (2.83v @ 1w/1m) Woofer Mounting Depth Woofer Mounting Diameter Tweeter Mounting Diameter 0 -3 0,-3dB level switch PC 525S PC 650S 4 ohms 4 ohms 50/100 watts 60/120 watts... -
Page 11: Limited Two-Year Consumer Warranty
Warranty LIMITED TWO YEAR CONSUMER WARRANTY: Directed Electronics, Inc. promises to the original purchaser, to replace this product should it prove to be defective in workmanship or material under normal use, for a period of two years from the date of purchase from the dealer as indicated by the date code marking of the product PROVIDED the product was installed by an authorized Directed dealer.
