Dimplex 7207980300REV00 Practical User's Manual

36” outdoor electric fireplace

Hide thumbs

Table Of Contents

Quick Links

Download this manual

PRACTICAL USER'S GUIDE

FOR THE DIMPLEX 36" OUTDOOR

Serial Number _________________

Model Number _________________

CAT Number

__________________

Valued Customer,

We are pleased that you have chosen to purchase an electric fireplace

manufactured by Dimplex North America Ltd. Over the years, valuable

memories will occur around the warmth and comfort of your hearth. Thank

you for allowing our product to be the backdrop for those special moments.

ELECTRIC FIREPLACE

MODEL NUMBER:

DFO3607

Quality checked by:

7207980300REV00

Table of Contents

Need help?

Do you have a question about the 7207980300REV00 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dimplex 7207980300REV00

Page 1 Valued Customer, We are pleased that you have chosen to purchase an electric fireplace manufactured by Dimplex North America Ltd. Over the years, valuable memories will occur around the warmth and comfort of your hearth. Thank you for allowing our product to be the backdrop for those special moments.
Page 2: Table Of Contents
3. If you have any technical questions regarding the operation or service of your fireplace have your Model and Serial Number ready, and contact Dimplex North America technical support at 1-888- DIMPLEX (1-888-346-7539) before returning the product to the point of purchase.
Page 3 IMPORTANT INSTRUCTIONS SAVE THESE INSTRUCTIONS PLEASE RETAIN THIS USER’S GUIDE FOR FUTURE REFERENCE When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1. Read all instructions before using the electric fireplace. 2.
Page 4: Unpacking Instructions
UNPACKING INSTRUCTIONS 1. Remove firebox from carton. 2. Carefully lay unit on it’s back. 3. Remove screws from the left and right side of the front glass lower support. 4. Carefully insert the tip of a slot screwdriver between the glass edge and either the left or right side trim.
Page 5: Important Instructions
If you have any questions regarding our products please have the product model and serial numbers available upon calling Dimplex customer service or technical support. To locate the model and serial number labels see below (Figure 1). Record the Model number, Serial number, and CAT number on the front cover of this manual for future reference.
Page 6: Site Selection And Preparation
SITE SELECTION AND PREPARATION This section provides instructions for selecting a location and preparing the site to install the fireplace into your Dimplex mantel surround. 1. Select a suitable location. 2. For ease of electrical hook up you may wish to locate the fireplace near an existing outlet.
Page 7: Fireplace Installation
FIREPLACE INSTALLATION 11. Install the fireplace assembly only into the Dimplex outdoor mantel. (refer to mantel assembly instructions) OPERATION ELECTRIC FIREPLACE MANUAL CONTROL The manual controls for the firebox are located in the upper right hand corner behind the access panel. To access the controls, open the upper access panel by pulling forward and down.
Page 8 OPERATION The fireplace is supplied with an integrated radio frequency on/off remote control. The remote control has a range of approximately 50 feet (15.25m), it does not have to be pointed at the fireplace and can pass through most obstacles (including walls). To operate, push the ON button to turn fireplace on, push the OFF button to turn the fireplace off.
Page 9: Maintenance
MAINTENANCE WARNING Disconnect power before attempting any maintenance or cleaning to reduce the risk of fire, electric shock or damage to persons. GLASS CLEANING The glass is cleaned in the factory during the assembly operation. During shipment, installation, handling, etc., the glass may collect dust particles; these can be removed by dusting lightly with a clean dry cloth.
Page 10: Stereo Instructions
IMPORTANT INSTRUCTIONS 1. Never repair the stereo unit yourself. In case of any failure, please turn off the power, and contact Dimplex North America. This unit is composed of many precision electronic components. The dismantling or repair may cause damage.
Page 11: Basic Operation
BASIC OPERATION ON/OFF Press the on/off button to power on and press it again to power off. Press the on/off button to power the Radio CD and AUX/MP3 functions. DIS: Display the clock and the clock adjustment (1) Connect the faceplate to the stereo chassis and power on; the LCD will display the radio frequency.
Page 12 FAD BALANCE Press the SEL button four times or twice (EQ Preset Mode) to enter the FAD mode and the screen will display “FAD”. There are no rear speakers so this setting can stay at default or max out the front fade by turning the volume knob clockwise.
Page 13: Radio Operation
RPT: Repeat Playing Press the RPT button, the LCD will display “RPT”. The player will continuously repeat the selected track. To cancel this function press the RPT button again. RDM: Play at Random Press the RDM button, the LCD will display “RDM”. This setting will play all tracks on the current CD randomly.
Page 14 Notes for Using CD 1. Keep the disc clean as possible. 2. Do not play damaged or deformed discs. 3. Keep the disc away from direct sunlight or high temperatures. 4. Put the disc in case after use. 5. Fingerprints or other smears left on the disc may affect sound quality. You may use a dry soft cloth to clean the disc surface.
Page 15: Limited Warranty
Products covered by this limited warranty have been tested and inspected prior to shipment and, subject to the provisions of this warranty, Dimplex warrants such products to be free from defects in material and workmanship in respect to the fireplace components of this product for a period of 12 months;...
Page 16 Dimplex will in its sole discretion either repair or replace such defective Product or part without charge. If Dimplex is unable to repair or replace the Product or part, or if repair or replacement is not commercially practicable or cannot be timely made, Dimplex may, in lieu of repair or replacement, choose to refund the purchase price for the Product or part.
