TJERNLUND 950-0014 RELAY-TIMER KIT NON-ADJUSTABLE 8504067 REV. 1097 Manual

24/24 vac non-adjustable relay/timer

24/24 VAC NON-ADJUSTABLE RELAY/TIMER

OWNERS INSTRUCTIONS

THESE INSTRUCTIONS MUST REMAIN

WITH EQUIPMENT

DO NOT DESTROY

A) Disconnect 115 VAC Power from the Power Venter before continuing.

B) All wiring from the Power Venter to the appliance must be appropriate class 1 wiring as follows: installed in rigid-metal conduit,

intermediate metal conduit, rigid non-metallic conduit, electrical metallic tubing, Type MI Cable, Type MC Cable or be otherwise

suitably protected from physical damage.

1. Remove the electrical box cover of the Power Venter.

2. Place the replacement Timer next to the defective Timer located in the Power Venter electrical box.

3. One by one, remove the wires from the defective Timer and connect them to the corresponding number on the replacement Timer.

4. Remove the defective Timer from the electrical box by pulling Timer up and off of mounting tabs.

5. Position new Timer over the 4 mounting studs and push down onto mounting tabs until Timer is secured into place.

6. If the defective Timer failed within the 1 year warranty period, you may return it along with proof of purchase to the Tjernlund

Distributor it was originally purchased from for a full refund.

TJERNLUND PRODUCTS, INC.

1601 Ninth Street • White Bear Lake, MN 55110-6794

PHONE (800) 255-4208 • (651) 426-2993 • FAX (651) 426-9547

Visit our web site • www.tjernlund.com

RELAY/TIMER PART NUMBER 950-0014

READ INSTRUCTIONS CAREFULLY

PART #950-0014 INSTALLATION INSTRUCTIONS

24/24 VAC INPUT APPROX. 45 SECOND

NON-ADJUSTABLE POST-PURGE RELAY/TIMER

REPLACEMENT OF DEFECTIVE RELAY/TIMER

ALWAYS FOLLOW HEATER

MANUFACTURER'S INSTRUCTION

FOR PROPER OPERATION OF

HEATER AND RELIGHTING OF PILOT

REV. 10/97

P/N 8504067
