RocketFish RF-CRSWIVEL User Manual

RocketFish RF-CRSWIVEL User Manual

High-speed cf/sd/sdhc usb 2.0 card reader
Hide thumbs Also See for RF-CRSWIVEL:
Table of Contents

Advertisement

Quick Links

High-Speed CF/SD/SDHC
USB 2.0 Card Reader
RF-CRSWIVEL
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RF-CRSWIVEL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RocketFish RF-CRSWIVEL

Summary of Contents for RocketFish RF-CRSWIVEL

  • Page 1 High-Speed CF/SD/SDHC USB 2.0 Card Reader RF-CRSWIVEL User Guide...

  • Page 2: Table Of Contents

    Introduction Congratulations on your purchase of a Rocketfish RF-CRSWIVEL high-speed CF/SD/SDHC USB 2.0 card reader. The RF-CRSWIVEL is a high-speed flash card reader ideal for professional photographers and users of digital single-lens reflex (DSLR) cameras. The reader has two slots, allowing it to read CF, SD, and SDHC format cards.

  • Page 3: Important Safety Instructions

    Package contents • Rocketfish high-speed CF/SD/SDHC card reader • A-male to A-female USB extension cable • Utility CD with User Guide RF-CRSWIVEL...

  • Page 4: Connecting The Card Reader

    Minimum system requirements • Pentium 133MHz or better processor • CD drive • 2 MB of hard drive space • One available external USB port • Windows 2000, Windows XP, Windows Vista, Windows 7, or Mac 10.x or higher Connecting the card reader Extend the swivel USB plug and insert it into an available USB port on your computer.
  • Page 5 The upper slot accepts SD and SDHC Cards. Note: An adapter is required for MiniSD and MicroSD cards. Insert direction CF/CF UDMA The lower slot accepts CompactFlash (CF) type I/II cards, CF UDMA cards, and Micro Drives. Insert direction RF-CRSWIVEL...
  • Page 6 Indicates 1 - Data LED on (yellow) - Light comes on when a card is inserted into the appropriate slot. The Data LED flashes when data is being transferred from the card or written to the card. 2 - Power LED on (green) - Light comes on when the card reader is inserted into a USB port.
  • Page 7 After the driver installation is complete, Windows displays two new drive icons for each of the slots instead of the standard Windows drive icon. When Windows detects a card in a slot, the corresponding drive icon changes from gray to a color that indicates the card type. RF-CRSWIVEL...

  • Page 8: Uninstalling The Software

    Uninstalling the software To uninstall the software in Windows Vista and Windows 7: Click Start, then Control Panel. Click Uninstall a Program. Locate the software in the list, then click Remove. Follow the on-screen instructions to uninstall the software. To uninstall the software in Windows XP and Windows 2000: Click Start, then Control Panel.
  • Page 9 Launch Disk Utility. In the left-hand column, select the memory card you want to erase, then click the Erase tab. Specify a volume format and name for the memory card. Click Erase. A Warning dialog box opens. Click Erase again. The process erases and reformats your memory card. RF-CRSWIVEL...

  • Page 10: Troubleshooting

    Troubleshooting Problem Suggestions Memory card does not appear in My • Make sure the card reader has been properly inserted into a USB port on your Computer or Windows Explorer computer. If utilizing the included USB extension cable, make sure that the (Windows 2000, XP, Vista, or 7).

  • Page 11: Legal Notices

    • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced technician for help. Canada ICES-003 statement This Class B digital apparatus complies with Canadian ICES-003. RF-CRSWIVEL...

  • Page 13: One-Year Limited Warranty

    Product is determined to be defective by an authorized Rocketfish repair center or store personnel, Rocketfish will (at its sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the Product at no charge with new or rebuilt comparable products or parts. Products and parts replaced under this warranty become the property of Rocketfish and are not returned to you.
  • Page 14 7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645 © 2009 Best Buy Enterprise Services, Inc. All rights reserved. ROCKETFISH is a trademark of Best Buy Enterprise Services, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
  • Page 15 RF-CRSWIVEL...
  • Page 16 7601 Penn Avenue South, Richfield, MN 55423-3645 USA © 2009 Best Buy Enterprise Services, Inc. All rights reserved. ROCKETFISH is a trademark of Best Buy Enterprise Services, Inc. All other products and brand names are trademarks of their respective owners.
