Technics SL-PS670D Service Manual
Technics SL-PS670D Service Manual

Technics SL-PS670D Service Manual

Compact disc player
Hide thumbs Also See for SL-PS670D:

Advertisement

Quick Links

Service
DIGITAL
MASH
DIGITAL
AUDIO
•tag.
Please file and use this manual together with the service manual
for Model No. SL-PS670A (E, EB. EG). Order No. MB9410050C2.
Note:
This service manual is provided to indicate the differences
between the original model No. SL-PS670A (E, EB, EG) and the
subsequent model No. SL-PS670D (E, EB, EG).
RAEI
1OOZ MECHANISM
Specifications
E Audio
No. of channels
Frequency
response
Output voltage
Dynamic
range
SIN
Harmonic
distortion
Total
harmonic
distortion
Wow
and
flutter
DA converter
Output impedance
Load impedance
Headphone output levet
Pickup
Wavelength
Laser
Power
This serviceinformation is designedfor experienced repairtechnicians onlyandis not designed for useby thegeneralpublic. It
doesnot containwarningsor cautionsto advisenon-technical individuals of potential d angersin attempting to servicea product.
Productspoweredby electricityshouldbe servicedor repairedonlyby experienced professional t echnicians. Any attemptto
serviceor repairtheproductor products dealtwithin thisserviceinformation byanyoneelsecouldresultin seriousinjuryor death.
TechnicS
Compact Disc Player
SERIES
2 (left and right, stereo)
2 - 20,000 Hz,
0.5 dB
98 dB
107 dB
0.002% (1 kHz. O dB)
0.0027% (1 kHz, O dB)
Below
measurable
MASH (1 bit)
600 Q
More
than
10 kQ
15 mw max. 32 Q (adjustable)
780
No hazardous
radiation
is emitted
(with safety protection)
Manual
General
Power consumption
Power supply
Dimensions (W x H x D)
Weight
Note:
Specifications are subject to change without notice.
Weight and dimensions are approximate.
limit
For United Kingdom only:
This apparatus was produced to BS 800.
nm
• MASH is a trademark
A WARNING
@ 1997 Matsushita ElectricIndustrial Co., Ltd.
All rights reserved. Unauthorized copying and
distribution is a violation of law.
ORDER
NO. MB9704076A2
Compact Disc Player
SL-PS670D
Colour (K)...Black Type
Areas
E.
. ..Europe.
EB...
Great
Britain.
Germany and Italy.
EG...
AC 50 Hz, 230 - 240 V
of NTT.
14W
mm
4.0 kg
