Summary of Contents for Vextra MI4002OM
- Page 1 Mi4002 User’s Guide ® Clock Radio for iPod with Two Alarms Before operating this product, please read these instructions completely.
-
Page 2: Safety Precautions
SAFETY PRECAUTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. (This Caution Marking is located at the rear enclosure and the Rating Label is located at the bottom enclosure of the unit.) DANGEROUS VOLTAGE: The lightning flash with arrowhead symbol within an... - Page 3 SAFETY PRECAUTIONS INFORMATION: This equipment complies with Class B digital device regulations. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
-
Page 4: Location Of Controls
LOCATION OF CONTROLS FRONT/TOP 1. iPod Dock with 11. MEM-DN (Memory Down) ® Connector & Button Interchangeable Adapters 12. RADIO/AUX IN (Function) 2. DISPLAY Button Button 3. ALARM 2 Button 13. BAND Button 4. ALARM 1 Button 14. PLAY/PAUSE/M-UP 5. POWER Button (Memory Up) Button 6. - Page 5 LOCATION OF CONTROLS (CONTINUED) REAR 1. VIDEO OUT Jack 2. AUX IN Jack 3. Battery Compartment (Bottom of Unit) 4. AC Cord 5. FM Wire Antenna...
-
Page 6: Power Source
POWER SOURCE AC CONNECTION Insert the AC plug (with the 2 blades) into a conveniently-located AC outlet having 120V, 60Hz. NOTE: The AC plug supplied with the AC Outlet unit is polarized to help minimize the possibility of electric shock. If the AC plug does not fit into a nonpolarized AC outlet, AC Plug do not file or cut the wide blade. -
Page 7: Optional Connection
OPTIONAL CONNECTION VIDEO OUT JACK (Rear of Unit) (For iPod Photo & iPod with Video [5th ® ® generation] only; not for iPod nano or ® other iPod models.) ® If you are using an iPod that has ® photo/video capability, and your TV has a Video input, you can connect the Mi4002 to the external TV with a Video cable. -
Page 8: Inserting An Ipod
INSERTING AN IPOD ® Locate the correct iPod Adapter to use Press the rear side of the adapter until it ® as shown on pages 16-17. Insert the is positioned inside the cavity. adapter into the cavity (as shown), NOTE: To remove the adapter, insert making sure the tabs are facing front, your finger (or other object) into the and slip the tabs into place. -
Page 9: Operation
OPERATION USING AN IPOD WITH THIS UNIT ® Operate the iPod as per its With an iPod connected (see previous ® ® page), turn the Mi4002 on by pressing owner’s manual and the sound will the POWER button (if it is not on be heard through the Mi4002’s already);... -
Page 10: Using The Radio
OPERATION (CONTINUED) USING THE RADIO Turn the Mi4002 on by pressing the If “AUX” appears, press the RADIO/AUX Power button; “AUX” or the AM/FM IN button 1 to select AM/FM. Then press the BAND button 2 repeatedly to select frequency will appear in the display. the desired band (AM or FM). - Page 11 OPERATION (CONTINUED) SETTING THE RADIO PRESETS (10 EACH BAND) Follow Steps 1-3 on the previous Press the TUNE Up/Down/Skip n / o buttons 1 to select a desired page to tune a station. Press and Preset (P01-P10). Press the hold the MEMORY/CLK SET MEMORY/CLK SET button 2 button;...
- Page 12 OPERATION (CONTINUED) TO SET OR RESET THE ACTUAL TIME Within 15 seconds, press the With the power off, press the MEMORY/CLK SET button until TUNE Up/Down/Skip n / o buttons to select between “12Hr” “12Hr” or “24Hr” blinks in the and “24Hr”.
- Page 13 OPERATION (CONTINUED) TO SET OR RESET THE ALARM TIME With the power off, press either the Within 3 seconds, press and hold the ALARM 1 button 1/ALARM 2 ALARM 1 button 1 (to set Alarm 1) button 2 again until the hour blinks or ALARM 2 button 2 (to set Alarm in the display.
- Page 14 OPERATION (CONTINUED) NOTES: • It is not necessary to set the volume level for the alarm. When the alarm time is reached, the alarm volume level will be set to the minimum and it will increase one step every five seconds continuously until it reaches Level 23.
- Page 15 OPERATION (CONTINUED) TO SHUT THE ALARM OFF Press the POWER button to turn off To not set the alarm for the next day, the alarm and the alarm will be set once you have turned the power off, for the next day. press the ALARM 1 1 or ALARM 2 2 button (which corresponds to the alarm that was set) until "AL1"...
- Page 16 OPERATION (CONTINUED) SLEEP With the unit in the AUX IN, iPod To view the remaining SLEEP time, ® Radio mode, press the SNOOZE/ press the SNOOZE/SLEEP button once. SLEEP button; the SLEEP indicator and Repeatedly press the SNOOZE/SLEEP "90" will appear in the display for three button to decrease the SLEEP time;...
- Page 17 OPERATION (CONTINUED) IPOD ADAPTERS ® Locate your iPod in the chart on the next two pages and select the ® respective Adapter (the Adapter No. is engraved at the front of the Adapters as shown on the next page) to match with your iPod .
- Page 18 OPERATION (CONTINUED) iPod Type Memory Adapter No. ® First 1 to No. 8 Generation iPod ® nano 30GB No. 9 Fifth Generation iPod ® (w/Video) No. 10 60GB/ 80GB NOTES: • For the Second Generation iPod nano, 2 to 8GB, please use the Universal ®...
-
Page 19: Troubleshooting Guide
TROUBLESHOOTING GUIDE If you experience a problem with this unit, check the chart below before calling for service. SYMPTOM CAUSE SOLUTION No sound. Volume is Increase volume. set to minimum. AM or FM, no sound. Power is not on. Press the POWER button, then see page 9 to select AM/FM. -
Page 20: Specifications
SPECIFICATIONS GENERAL: Power Source ..........120V, 60Hz AC Battery Backup........2 x “AA” size batteries Speaker...............2 x 4 ohms Output Power ............2 x 2W Weight...............3.3 Lbs Dimensions ......11.8 (L) X 5.5 (W) X 4 (H) inches Weight and dimensions are approximate. RADIO SECTION: Frequency Range (FM) ........87.5–108 MHz Frequency Range (AM) .......530–1710 KHz Specifications are subject to change without notice. - Page 21 Hopper, Inc. Weston, FL Printed in Hong Kong...
