Digicom 8D5505 Brochure

Power SWITCH 10-100

DESCRIPTION
Nowadays Networking technologies are coming
frequently into our life. These were born to solve the
problems in the big companies, then used also in
medium-size companies and today used even in small
offices and at home.
The use of these technologies needs a special cabling
structure (not counting the long times and the costs)
that we usually don't have in our houses.
Digicom solves all these problems with
PowerSWITCH 10-100, that exploits the Powerline
technology, using the power line as the cabling for
the local network, to connect the various devices
(switch, router, etc.)
PowerSWITCH 10-100 is the digicom's switch with
Powerline technlogy, that uses the electric line,
available in the office or at home, to carry out a local
network without placing new cables and using radio
devices.
It has 4 Ethernet ports 10/100 Mbps where you can
directly connect PCs and printers.
The connection to other PowerSWITCHes (Up-link) is
carried out with the power cabling, through the power
plug. No configuration is required to install
PowerSWITCH. After it has been powered, it
immediately searches for eventual devices and in a
few minutes you build your LAN.
The Internet access (i.e. ADSL) will be available in
each room of your office or home.
To guarantee the maximum data security,
PowerSWITCH supports the DES 56bit cryptography.
PowerSWITCH 10/100 complies with the HomePlug
TM V1.0 standard.
The Networking solutions for fast and performing LANs.
For further information: international@digicom.it or http://www.digicom.it
Code: 8D5505
Switch 10/100 with Powerline technology
Power supply 230 Vac +/-10% 50-60 Hz
4 ports RJ-45 10/100 Mbps
Autosensing 10/100
Automatic MDI/MDI-X mode on all ports
Frequency Band: 4.3 MHz 20.9 MHz
Modulation: OFDM
Speed on physical level: 14Mbps
Data speed up to 6Mbps
Security: Cryptography DES 56bit
Point to Point and Multipoint
connections
LED indicators:
- Power
- Link
- Activity
- Collision
- 10 Mbps/100 Mbps
Complies with HomePlug TM V1.0
standard
Dimensions: 115 x 80 x 45 mm
CE Mark
ADSL
INTERNET
Power SWITCH 10-100 3.03.2003
PC
LAPTOP
POWERSWITCH
Printer
PC
ADSL
POWERSWITCH
Modem
