{ServiceManual}{Production}{KodakServiceSupport}{ExternalAndInternal}
Publication No. SM1655-2
27JUN06
SERVICE MANUAL
for
Authorized Service Centers
for the
Kodak EasyShare Z612 ZOOM DIGITAL CAMERA
Service Code: 1655
Important
Qualified service personnel must repair this equipment.
Confidential
Restricted Information
© Eastman Kodak Company, 2006

Advertisement

loading
Need help?

Need help?

Do you have a question about the EasyShare Z612 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kodak EasyShare Z612

  • Page 1 {ServiceManual}{Production}{KodakServiceSupport}{ExternalAndInternal} Publication No. SM1655-2 27JUN06 SERVICE MANUAL Authorized Service Centers for the Kodak EasyShare Z612 ZOOM DIGITAL CAMERA Service Code: 1655 Important Qualified service personnel must repair this equipment. Confidential Restricted Information © Eastman Kodak Company, 2006...
  • Page 2 Eastman Kodak Company reserves the right to change this information without notice, and makes no warranty, express or implied, with respect to this information. Kodak shall not be liable for any loss or damage, including consequential or special damages, resulting from any use of this information, even if loss or damage is caused by Kodak’s negligence or other fault.
  • Page 3 SERIES 3 P252_0122BA Note • You must use the Kodak EasyShare Z612 ZOOM DIGITAL CAMERA with the Kodak EasyShare CAMERA DOCK SERIES 3. • The Kodak EasyShare Z612 ZOOM DIGITAL CAMERA is not compatible with other DOCKS. SM1655-2 – 27JUN06...
  • Page 4 SERVICE MANUAL Visual Index P276_1032ECA P276_1032EC 27JUN06 – SM1655-2...
  • Page 5 Illustrated Parts List Item Description “COVERS” on Page 6 “MAIN BOARD, VIEWFINDER and HOLDERS” on Page 8 “MODE DIAL, BATTERY COMPARTMENT AND SHUTTER BOARD” on Page 10 “STROBE and LENS AYs” on Page 11 SM1655-2 – 27JUN06...
  • Page 6 SERVICE MANUAL Equipment Parts Caution • See “COVER AYs” on Page 25 for the removal procedure of the BACK COVER and the FRONT COVER. • Dangerous Voltage • You must do a discharge of the CAPACITOR after removing the FRONT COVER. Figure 1 COVERS P276_1033ECA P276_1033EC...
  • Page 7 STRAP - neck Not visible in the graphic. * This part is not available because you must do a calibration of the CAMERA using Kodak proprietary technology to comply with the specification, or the part is not in stock. SM1655-2 – 27JUN06...
  • Page 8 SERVICE MANUAL Caution You must move the MAIN BOARD down and backward to disconnect the BOARD-TO-BOARD CONNECTOR. Figure 2 MAIN BOARD, VIEWFINDER and HOLDERS P276_1034DCA P276_1034DC 27JUN06 – SM1655-2...
  • Page 9 HOLDER - strap 3F9554 TRIPOD MOUNT * This part is not available because you must do a calibration of the CAMERA using Kodak proprietary technology to comply with the specification, or the part is not in stock. SM1655-2 – 27JUN06...
  • Page 10 SCREW - PHK, 1.7 x 3.0 - 3.0 x 0.5, Ni * This part is not available because you must do a calibration of the CAMERA using Kodak proprietary technology to comply with the specification, or the part is not in stock.
  • Page 11 Illustrated Parts List Figure 4 STROBE and LENS AYs P276_1035ECA P276_1035EC SM1655-2 – 27JUN06...
  • Page 12 LENS AY 3F9558 FFC - 12-pin * This part is not available because you must do a calibration of the CAMERA using Kodak proprietary technology to comply with the specification, or the part is not in stock. 27JUN06 – SM1655-2...
  • Page 13 Alphabetical Index Section 2: Alphabetical Index Alphabetical Index Part No. Description Figure No. BATTERY COMPARTMENT AND SHUTTER BOARD BOARD - main 3F9567 CAP - lens 3F9549 CAP AY - lens CAPACITOR - strobe 3F9541 COVER - back 3F9548 COVER - connector 3F9540 COVER - front 3F9555...
  • Page 14 SERVICE MANUAL Section 3: Diagnostics Error Codes Description Recommended Action A communication error occurred between the Install a new MAIN BOARD. MAIN CPU and the 16-BIT CPU. Description Recommended Action The program checksum is not correct. 1. Do Downloading the Firmware for the First Time. 2.
  • Page 15 Diagnostics Description Recommended Action A signal did not occur from the VERTICAL DRIVER to 1. Check connections CN0101 on the MAIN BOARD to the MAIN BOARD. the CCD FPC. 2. Install a new: • CCD FPC • MAIN BOARD • LENS AY Description Recommended Action A focus error occurred or the CPU malfunctioned.
  • Page 16 SERVICE MANUAL Description Recommended Action The CAMERA does not recognize the format of the 1. Do Downloading the Firmware for the First Time. NANDFLASH memory. 2. Install a new MAIN BOARD. Description Recommended Action The firmware does not have the correct checksum. 1.
  • Page 17 • CAMERA from the CAMERA DOCK • BATTERY from the CAMERA [5] Connect the Kodak 3-V AC ADAPTER to the power port on the CAMERA. [6] Move the “On/Off” SWITCH to the right and release it to energize the CAMERA.
  • Page 18 SERVICE MANUAL [25] Press the SHUTTER BUTTON to “S1” position to check for focus of the image in the VIEWFINDER. [26] Press the “EVF/LCD” BUTTON to use the MONITOR LCD. [27] Check that the image in the MONITOR LCD has focus. [28] Capture 2 images.
  • Page 19 Diagnostics BUTTON/SWITCH CLOSE UP/ 1. Press the CLOSE UP/LANDSCAPE BUTTON. LANDSCAPE 2. Check that the MONITOR LCD displays the icon for “Close up”. 3. Press the CLOSE UP/LANDSCAPE BUTTON again to check that the icon changes to: • “Landscape” • “MF” •...
  • Page 20 SERVICE MANUAL [31] Check that the MONITOR LCD displays: • image • number of additional images that can be captured • icons: – if “AF Control” mode is selected – mode of the CAMERA – “Flash” mode – size of the image –...
  • Page 21 Diagnostics [36] Press the “OK” BUTTON to select one of the icons in the “SCN” position. For example: Selected “SCN” Icon: Manner/Museum 1. Check that “Manner/Museum:” displays on the MONITOR LCD. 2. Press the SHUTTER BUTTON. 3. Check that the following items are disabled: •...
  • Page 22 SERVICE MANUAL After moving the MODE DIAL to: “Video” 1. Check that “Video:” displays on the MONITOR LCD 2. Press and release the SHUTTER BUTTON. 3. During the video file recording, check: • green LED flashes • “REC” on the MONITOR LCD flashes •...
  • Page 23 Diagnostics Checking the COUNTERS Without the SERVICE SOFTWARE [1] Energize the CAMERA. [2] Press the “menu” BUTTON. [3] Use the 4-WAY BUTTON to do a search for “SETUP MENU”. [4] Press the “OK” BUTTON. [5] Use the 4-WAY BUTTON to do a search for “ABOUT...”. [6] At the same time, press: •...
  • Page 24 SERVICE MANUAL Checking the External Components of the CAMERA [1] Check the COVERS of the CAMERA for scratches. [2] If necessary, install new COVERS. [3] Clean: • COVERS • screen on the MONITOR LCD • VIEWFINDER WINDOW • FLASH COVER [4] Check and clean the LENS.
  • Page 25 Replacements Section 4: Replacements Important You must see the “Equipment Parts” on Page 6 for all parts. COVER AYs Prerequisites: None To Remove: EVF/LCD BUTTON 6 SCREWS BACK COVER P276_1029HCA P276_1029HC [1] Remove the 6 SCREWS. [2] Press down on the BACK COVER and hold at the area by the “EVF/LCD” BUTTON. [3] Pull and remove the BACK COVER.
  • Page 26 SERVICE MANUAL [4] Carefully press down on the lower edge of the FRONT COVER by the TRIPOD MOUNT. [5] Move the FRAME AY from the FRONT COVER. FRONT FRAME AY COVER TRIPOD MOUNT lower edge P276_1030GCA P276_1030GC [6] Press and hold the “On/Off” SWITCH to the “On” position.
  • Page 27 Replacements To Install: [1] Reverse the steps in the removal procedure. Postrequisites: None SM1655-2 – 27JUN06...
  • Page 28 Publication History Section 5: Publication History Publication Publication Changed File Date Pages Name Notes 27JUN06 SM1655-2 sm1655_2.fm New Publication Kodak and EasyShare are trademarks of Eastman Kodak Company. Printed in U.S.A. • sm1655_2.fm EASTMAN KODAK COMPANY Rochester, NY 14650...
