  • Page 1 27M2N5800P User manual Register your product and get support at www.philips.com/welcome...
  • Page 2 6.1 Resolution & Preset Modes ..23 6.2 Resolution & Preset Modes ..23 7 Power Management 25 8 Customer care and warranty 26 8.1 Philips’ Flat Panel Monitors Pixel Defect Policy ........ 26 8.2 Customer Care & Warranty ..29 9 Troubleshooting & FAQs 30 9.1 Troubleshooting ......
  • Page 3 Keep the display away from oil. Oil may damage the plastic cover of the display and void the warranty. This electronic user’s guide is intended for anyone who uses the Philips • Remove any object that could fall monitor. Take time to read this user into ventilation holes or prevent manual before you use your monitor.
  • Page 4 damage will not be covered under • Oil-based cleaning solutions may warranty. damage the plastic parts and void the warranty. • Do not knock or drop the monitor during operation and/or • Unplug the monitor if you are not transportation. going to use it for an extensive period.
  • Page 5 1.2 Notational Descriptions Uninterrupted display of still or static images over an extended The following subsections describe the period may cause “burn-in”, also notational conventions used in this known as “after-imaging” or “ghost document. imaging”, on your screen. • “Burn-in”, “after-imaging”, or Notes, Cautions, and Warnings “ghost imaging”...
  • Page 6 From the planning, design, and production stages, Philips emphasizes the importance of making products that can easily be recycled. At Philips, end-of-life management primarily This marking on the product or its entails participation in national take-...
  • Page 7 2.1 Installation Package contents 27M2N5800P Quick Start Register your product and get support at www.philips.com/welcome 2. Hold the stand with both hands. Power (1) Gently attach the base to the stand. (2) Use your fi ngers to tighten the...
  • Page 8 Connecting to your PC 3. Connect the monitor signal cable to the video connector on the back of your computer. 4. Plug the power cord of your computer and your monitor into a nearby outlet. 5. Turn on your computer and monitor. If the monitor displays an image, USB UP installation is complete.
  • Page 9 The display must be powered ON at all times to be able to use this function. Description of the control buttons Some selected Philips displays may not Power or Charge your device when it enters “Sleep/Standby” mode (White power LED blinking). In that case, please enter to OSD Menu and select “USB...
  • Page 10 Description of the On-Screen Display What is On-Screen Display (OSD)? On-Screen Display (OSD) is a feature in all Philips LED monitors. It allows an end user to adjust screen performance or select functions of the monitors directly through an on- screen instruction window.
  • Page 11 Main menu Sub menu Standard, FPS, Racing, RTS, Movie, SmartImage Brightness 0~100 LowBlue Mode, EasyRead, Economy, Contrast 0~100 SmartUniformity, Game1, Game2 SmartContrast On, O Gamma 1.8, 2.0, 2.2, 2.4, 2.6 Sharpness 0~100 Native, sRGB, DCI-P3, Adobe RGB Color Space Color Temperature Native, Preset, 5000K, 6500K, 7500K, 8200K, 9300K, 11500K R.G.B.
  • Page 12 three selectable levels that Note offer texturized images with • Game mode: This model is equipped better color saturation with with new features in OSD which higher contrast so you can see gives you high-quality visual better in both light and dark experience.
  • Page 13 Height adjustment Resolution notification This monitor is designed for optimal performance at its native resolution:3840 x 2160. When the monitor is powered on at a different resolution, an alert is displayed on the screen as follows: Use 3840 x 2160 for best results. Display of the native resolution alert can 130mm be switched off from Setup in the OSD...
  • Page 14 2.3 Remove the Base Assembly Note This monitor accepts a 100mm x 100mm for VESA Mounting VESA-Compliant mounting interface. Before you start disassembling the VESA Mounting Screw M4. Always monitor base, please follow the contact manufacturer for wall-mount instructions below to avoid any possible installation.
  • Page 15 MultiView in OSD menu • PIP / PBP Mode: There are two Why do I need it? modes for MultiView: [PIP] and With the ultra-high-resolution Philips [PBP]. MultiView display, you can comfortably [PIP]: Picture in Picture experience a world of connectivity in the office or at home.
  • Page 16 Top-Left Top-Right When the sub source is not detected. (main) (main) (main) Note Bottom-Left Bottom-Right The black strip located on the top and the bottom of the screen is for measuring the correct aspect ratio when in the PBP mode. If you expect to see full- (main) (main) screen, adjust your device's resolutions...
  • Page 17 EasyRead, Economy, SmartUniformity, brightness, contrast, color, and sharpness Game1 and Game2. in real-time. Whether you're working with text applications, displaying images, or watching a video, Philips SmartImage delivers great monitor performance. SmartImage GAME Why do I need it? Standard...
  • Page 18 HDR Game rays from LED displays can cause eye damage and affect vision over HDR Movie time. Developed for well-being, the HDR Vivid Philips LowBlue Mode setting uses DisplayHDR 400 smart software technology to reduce Personal harmful shortwave blue light. Off...
  • Page 19 3.3 Customize color space Note To switch off the HDR function, please You can manually select the appropriate disable the Input device and its content. color space mode to properly display the Inconsistent HDR settings between the content you are viewing. input device and monitor may cause Select appropriate color space mode unsatisfying images.
  • Page 20 4 Adaptive Sync AMD Radeon R7 260 • ■ Processor A-Series Desktop and Mobility APUs AMD A10-7890K • Adaptive Sync AMD A10-7870K • AMD A10-7850K PC gaming has long had an imperfect • experience because GPUs and monitors AMD A10-7800 •...
  • Page 21 5. HDR HDR Settings in Windows10 system. Steps 1. Right-click on the desktop, and enter Display settings. 2. Select the display/monitor. 3. Select an HDR-capable display under Rearrange your displays. 4. Select Windows HD Color settings. 5. Adjust Brightness for SDR content. Note Windows 10 edition is required.
  • Page 22 6. Technical Specifications Picture/Display Monitor Panel Type IPS Technology Backlight W-LED Panel Size 27" W (68.5 cm) Aspect Ratio 16:9 Pixel Pitch 0.1554 (H) mm x 0.1554 (V) mm Contrast Ratio(typ.) 1100:1 Recommended 3840 x 2160 @ 60 Hz Resolution 3840 x 2160 @ 240 Hz (UHD) Maximum Resolution 1920 x 1080 @ 480 Hz (FHD)
  • Page 23 English, German, Spanish, Greek, French, Italian, Hungarian, Dutch, Portuguese, Brazil Portuguese, Polish, Russian, OSD Languages Swedish, Finnish, Turkish, Czech, Ukranian, Simplified Chinese, Traditional Chinese, Japanese, Korean Other Convenience VESA mount (100 x 100 mm), Kensington Lock Plug & Play DDC/CI, sRGB, Windows 11/10, Mac OS X Compatibility Stand Tilt...
  • Page 24 50%. This monitor provides optimal visual comfort, minimizes eye strain, and supports sustained focus. Note The data mentioned in this section is subject to change without notice. Go to www. philips.com/support to download the latest version of the leaflet. 2. SmartUniformity and Delta E information sheets are included in the box.
  • Page 25 Please note that your display works best at the native resolution of 3840 x 2160. For best output performance, please always ensure that your graphic card is capable of achieving the maximum resolution and refresh rate of this Philips display.
  • Page 26 Display Input Format UHD Mode 444/RGB 444/RGB HDMI 2.1 DP 2.1 3840 x 2160 240Hz 10bits 3840 x 2160 240Hz 8bits Low resolutions 8/10bits FHD Mode 444/RGB 444/RGB HDMI 2.1 DP 2.1 1920 x 1080 @ 480Hz 10bits 1920 x 1080 @ 480Hz 8bits Low resolutions 8/10bits Note In order for the monitor to function properly, your PC's graphics card must support...
  • Page 27 7 Power Management If you have a VESA DPM compliance display card or software installed on your PC, the monitor can automatically reduce its power consumption when not in use. If an input from a keyboard, mouse, or other input device is detected, the monitor will 'wake up' automatically.
  • Page 28 Other Pixel Defect Policy combinations of lit and dark sub-pixels appear as single pixels of other colors. Philips strives to deliver the highest quality products. We use some of the Types of Pixel Defects industry's most advanced manufacturing...
  • Page 29 To qualify for repair or replacement due to pixel defects during the warranty Black Dot Defects period, a TFT Monitor panel in a Philips Black dot defects appear as pixels or flat panel monitor must have pixel sub-pixels that are always dark or 'off'.
  • Page 30 BRIGHT DOT DEFECTS ACCEPTABLE LEVEL 1 lit subpixel 2 adjacent lit subpixels 3 adjacent lit subpixels (one white pixel) Distance between two bright dot defects* >15mm Total bright dot defects of all types BLACK DOT DEFECTS ACCEPTABLE LEVEL 1 dark subpixel 3 or fewer 2 adjacent dark subpixels 2 or fewer...
  • Page 31 Please contact our Philips Customer Service Representative or local contact center (by Consumer care number) for more details. Philips Customer Care Center number listed below.
  • Page 32 • Disconnect the monitor from mains power source immediately for safety 9.1 Troubleshooting • Contact with Philips customer service This page deals with problems that can representative immediately. be corrected by a user. If the problem Imaging Problems persists after you have tried these...
  • Page 33 Service contact information listed in set at 3840 x 2160. the Important information manual • Shut down your computer, and contact a Philips customer service disconnect your old monitor, and representative. reconnect your Philips LED monitor. * Functionality is different according to display.
  • Page 34 Can I connect my LED monitor to please use isopropyl alcohol. Do any PC, workstation, or Mac? not use other solvents such as Ans.: Yes. All Philips LED monitors are ethyl alcohol, ethanol, acetone, fully compatible with standard hexane, etc.
  • Page 35 Q10: Are Philips LCD monitors Plug- Q13: How to unlock/lock my hotkey? and- Play? Ans.: Please press for 10 seconds Ans.: Yes, the monitors are Plug-and- to unlock/lock the hotkey, by Play compatible with Windows doing so, your display pops out 11/10, Mac OSX.
  • Page 36 9.3 Multiview FAQs Can I enlarge the PIP sub- window? Ans.: Yes, there are 3 sizes to select: [Small], [Middle], [Large]. You can press to enter the OSD menu. Select your preferred [PIP Size] option from the [PIP / PBP] main menu.
  • Page 37 This product has been manufactured by and is sold under the responsibility of Top Victory Investments Ltd., and Top Victory Investments Ltd. is the warrantor in relation to this product. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V.
