- Page 1 4-466-613-11(3) DVD Home Theatre System Operating Instructions ©2013 Sony Corporation Printed in China DAV-TZ150...
- Page 2 WARNING To reduce the risk of fire or electric shock, do not expose this appliance to dripping or splashing, and do not place objects filled with liquids, such as vases, on the appliance. To reduce the risk of fire, do not cover the ventilation opening of the appliance with newspapers, tablecloths, curtains, etc.
- Page 3 HDMI Licensing LLC in the United States and other countries. “PlayStation” and “PS3” are registered trademarks of Sony Computer Entertainment Inc. “BRAVIA” is a trademark of Sony Corporation. MPEG Layer-3 audio coding technology and patents licensed from Fraunhofer IIS and Thomson.
- Page 4 CONSUMER FOR DECODING VIDEO IN COMPLIANCE WITH THE MPEG-4 VISUAL STANDARD (“MPEG-4 VIDEO”) THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NONCOMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO PROVIDE MPEG-4 VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE.
- Page 5 Playable Discs DVD-VIDEO DVD-ROM DVD-R/DVD-RW DVD+R/DVD+RW CD-DA (Music CD) CD-ROM CD-R/CD-RW VIDEO CD Super VCD A CD or DVD will not play if it has not been correctly finalized. For more information, refer to the operating instructions supplied with the recording device. Discs that cannot be played Blu-ray Discs HD DVDs...
- Page 6 Note on playback operations of a DVD Some playback operations of a DVD may be intentionally restricted by software producers. Since this system plays a DVD according to the disc contents the software producers designed, some playback features may not be available.
- Page 7 4) WMA DRM,WMA Lossless or WMA PRO format are not compatible. 5) AAC DRM and AAC Lossless formats are not supported. Note Some files may not play depending on the format, the encoding, or recording condition. Some USB devices may not work with this system.
- Page 8 Unpacking Checking the supplied items Main unit (1) Center speaker (1) Surround speaker (2) Front speaker (2) Subwoofer (1) Remote commander (remote) (1) Base (2) Post (2) Ring (2) Screw (4) FM wire antenna (1) Video cord (1) Speaker cords (1 set)
- Page 9 Preparing the remote control Insert two R6 (size AA) batteries (not supplied) by matching the and ends on the batteries to the markings inside the compartment.
- Page 10 Installing the front speakers Spread a cloth on the floor to avoid damaging the floor when you assemble the speakers. Insert the post () so that the slot on the lower post aligns with the projection of the base (), then secure the post with the ring (). Slot Projection ...
- Page 11 Insert the post () into the hole on the bottom of the speaker () so that the screw on the top of the post faces the front of the speaker. Be careful not to pinch the speaker cord between the speaker and the post. ...
- Page 12 Remove any bends in the speaker cord by gently pulling it from below the base (). To connect speaker cords to the speaker Rear of the speaker Colored tubes Center speaker: Green Surround left speaker: Blue Surround right speaker: Gray...
- Page 13 Connecting the Speakers Caution Do not use any speakers other than those supplied with this system. Insert the speaker cords to match the color of the SPEAKERS terminals of the unit. Rear panel of the main unit Speaker cord Contact area (+) Covering Colored tube Contact area (–)
- Page 14 Connecting your TV Depending on the jacks on your TV or set-top box, select the video and audio connection method. When connecting to a TV only When connecting a TV and set-top box/PlayStation®3 The TV has AUDIO OUT jacks*4: The TV has AUDIO OUT jacks: The TV does not have AUDIO OUT jacks: Audio Video...
- Page 15 Supplied only in certain areas. This is the basic connection via video cord (yellow). Supplied only in certain areas. Picture quality will be improved compared to a video cord. Sold separately. To listen to TV audio via the system, connect with an audio cord (red and white).
- Page 16 Install the speakers on a vertical and flat wall where reinforcement is applied. Sony is not responsible for accidents or damage caused by improper installation, insufficient wall strength or improper screw installation, natural calamity, etc.
- Page 17 Fasten the screws to the wall, then hang the speaker on the wall. Depth of fastened screw 8 to 10 mm For the center speaker 145 mm For the small speakers For the tall speakers 101.6 mm...
- Page 18 Color System Setup Connect the AC power cord (mains lead). Turn on the power of the main unit and TV. / / Press FUNCTION repeatedly or DVD/ CD to switch the function to DVD/CD. Playback starts automatically if a disc with an auto playback function is loaded.
- Page 19 Parts and Controls Front panel FUNCTION / (on/standby) Selects the playback source. Turns on the unit, or sets it to standby mode. VOLUME –/+ Adjusts the system’s volume. Play operation buttons ...
- Page 20 Remote control SHIFT Press and hold this button to use buttons with purple text labels. TV INPUT* Switches the TV’s input source between the TV signal and other input sources.
- Page 21 BRAVIA Sync ONE-TOUCH PLAY Activates One-Touch Play. TV I/ (on/standby)* Turns on the TV or sets it to standby mode. / (on/standby) Turns on the system or sets it to standby mode. Function selection buttons Select the playback source. DVD/CD TV/CABLE FUNCTION Selects the functions in sequence.
- Page 22 (play) (stop) Radio operation buttons PRESET +/– TUNING +/– * Works with Sony TVs only. Depending on your TV, you may not be able to use some of the buttons. Note AUDIO IN This button does not work.
- Page 23 Playing a Disc Press DVD/CD. You can also select this function by pressing FUNCTION repeatedly. Press to open the disc tray. Place a disc on the tray, then press . With the label side up. Press to start playback. Press VOLUME +/–...
- Page 24 Playing Files on a Disc/USB Device Press DVD/CD or USB. DVD/CD: For a disc. USB: For a USB device. You can also select the function by pressing FUNCTION repeatedly. Load the source. For a disc Place a disc on the tray by pressing to open/close the disc tray.
- Page 25 Other Playback Operations To change angles Press ANGLE during playback to select the desired angle. (This applies to DVD VIDEOs only.) To display subtitles Press SUBTITLE during playback to select the desired subtitle language. (This applies to DVD VIDEOs only.) To change the sound Press AUDIO repeatedly during playback to select the desired audio signal.
- Page 26 To search for a title/chapter/ track/scene, etc. When playing a DVD/VCD Press DISPLAY during play. The Display Menu appears on the TV screen. Press / to select an option, then press Press and hold SHIFT, then press the number buttons to jump to the desired option.
- Page 27 To play repeatedly/shuffle, etc. Press REPEAT repeatedly to select the desired playback mode. The selected mode appears in the front panel display. “REP CHP”: Repeats the current chapter. “REP TT”: Repeats the current title. “REP ALL”: Repeats all titles. “REP TRK”: Repeats the current track.
- Page 28 Selecting the Sound Effect To select an equalizer setting Press EQ to display the current mode. While the current mode is displayed, press EQ repeatedly until the desired mode appears on the front panel display. “AUTO”: Automatically selects the movie or music sound mode based on the disc type.
- Page 29 Using a Tuner To preset radio stations You can preset 20 FM stations. You can then tune in any of those stations simply by selecting the corresponding preset number. Press FM. Press and hold TUNING +/– for 2 seconds to start tuning until you find the desired radio station.
- Page 30 Convenient Functions About the Control for HDMI function (“BRAVIA” Sync) You can control a TV compatible with the Control for HDMI function by connecting it to the system via an HDMI cable. Available features One-Touch Play With one touch of ONE-TOUCH PLAY on the remote control, the system and your TV automatically turn on and the TV’s input is switched to the system;...
- Page 31 To cancel the sleep timer function Press and hold SHIFT, then press SLEEP repeatedly until “OFF” appears in the front panel display. To view information about the disc You can check the playing time and remaining time of the current title, chapter, or track.
- Page 32 Using the Setup Display You can make various adjustments to items such as picture and sound. Displayed items vary depending on the country model. The default setting is underlined. Press DVD/CD, then eject the disc. Press SETUP. The setup menu appears. Press /...
- Page 33 [4:3 Letter Box]: Displays a wide picture with black bands on the top and bottom. [4:3 Pan Scan]: Displays a full-height picture on the entire screen, with trimmed sides. [OSD Lang] (On-Screen Display) You can switch the display language on the TV screen.
- Page 34 [Screen Saver] [On]: The screen saver image appears if you do not operate the system for about 15 minutes. [Off]: Off. [Last Memory] This system recalls the point where you stopped the disc the last time it was played and resumes playback from that point the next time you insert the same disc.
- Page 35 [SR]: Adjusts the sound level of right surround speaker. It is possible to adjust the parameter from -6.0 dB to +6.0 dB. [SL]: Adjusts the sound level of left surround speaker. It is possible to adjust the parameter from -6.0 dB to +6.0 dB. [SW]: Adjusts the sound level of subwoofer.
- Page 36 Video Setup Page [HDMI Resolution] You can select the type of video signal that is output from the HDMI OUT jack. [Auto]: The system outputs the optimal video signal for the connected TV. [480p/576p]: The system outputs 720 × 480p* or 720 ×...
- Page 37 Press / to select a rating level from 1 to 8 or [Off], then press Press and hold SHIFT, then press the number buttons to enter your 6-digit password. [Default] This feature enables you to reset all the setup menu options and your personal settings to the factory defaults, except for your password for the [Password] and [Parental] items.
- Page 38 Do not use any type of abrasive pad, scouring powder, or solvent such as alcohol or benzine. If you have any questions or problems concerning your system, please consult your nearest Sony dealer.
- Page 39 On cleaning discs, disc/lens cleaners Do not use cleaning discs or disc/lens cleaners (including wet or spray types). These may cause the apparatus to malfunction. On your TV’s color IMPORTANT NOTICE Caution: This system is capable of holding a still video image or on-screen display image on your television screen indefinitely.
- Page 40 On heat radiation Due to the slim type of main unit design, you may feel some heat on the top of the unit. This is normal. Please consult your nearest Sony dealer if you have any questions.
- Page 41 Should any problem persist, consult your nearest Sony dealer. Note that if service personnel changes some parts during repair, these parts may be retained.
- Page 42 Picture There is no picture. The video connecting cords are not connected securely. The unit is not connected to the correct TV input jack. The system is not selected via the video input of the TV. Check the output method on your system. Even though you set the aspect ratio in [TV Display] of [General Setup Page], the picture does not fill the TV screen.
- Page 43 Sony dealer. A disc cannot be ejected and “LOCKED” appears in the front panel display. Contact your Sony dealer or local authorized Sony service facility. Radio stations cannot be tuned in. Check that the antenna (aerial) is connected securely.
- Page 44 A JPEG image file cannot be played. It is larger than 2,048 (width) × 1,536 (height) in normal mode, or more than 2,000,000 pixels in progressive format which is mainly used on Internet Web sites. A video file cannot be played. The video file resolution is larger than 720 (width) ×...
- Page 45 USB device “OVERLOAD“ appears in the front panel display. Remove the USB device from the (USB) port. Make sure there is no problem with the USB device. The USB device (audio file/JPEG image file) cannot be played. Files that are encrypted or protected by passwords, etc., cannot be played.
- Page 46 Specifications Amplifier Section POWER OUTPUT (rated): Front L + Front R 30 W + 30 W (at 8 ohms, 1 kHz, 1% THD) POWER OUTPUT (reference): Front L/Front R/ Center/Surround L/ Surround R: 50 W (per channel at 8 ohms, 1 kHz) Subwoofer: 50 W (at 8 ohms, 100 Hz)
- Page 47 Speakers Front SS-TS126 Dimensions (approx.) 165 mm × 570 mm × 165 mm (w/h/d) incl. projecting parts Mass (approx.) 1.7 kg Center SS-CT124 Dimensions (approx.) 265 mm × 94 mm × 70 mm (w/h/d) incl. projecting parts Mass (approx.) 0.6 kg Surround SS-TS127 Dimensions (approx.) 103 mm ×...
