CH1303BLF-03
max weight
275lbs
1
2
CASTER
5-STAR BASE
Part #
Part #
H189079
H189078
4
3
2
1
3
3
4
GAS LIFT
DUST COVER
Part #
Part #
H188255
H189076
An assistant is required.
Es necesario un ayudante.
Un assistant est nécessaire.
5
SEAT PLATE W/
6
BACK CUSHION
SEAT CUSHION
Part #
Part #
S188190
H190220
Lot Code:
5
7
4
An assistant is required.
Es necesario un ayudante.
Un assistant est nécessaire.
7
8
ARMREST
SCREW
1 set
3
5/16" x 7/8" L
Part #
Part #
H188191
H189111
A188332C
7
9
ALLEN WRENCH, 5mm
Part #
H122485
Advertisement
Related Manuals for bbf CH1303BLF-03
Summary of Contents for bbf CH1303BLF-03
- Page 1 CH1303BLF-03 A188332C An assistant is required. An assistant is required. Es necesario un ayudante. Es necesario un ayudante. Un assistant est nécessaire. Un assistant est nécessaire. max weight 275lbs SEAT PLATE W/ ARMREST SCREW CASTER 5-STAR BASE GAS LIFT DUST COVER...
- Page 2 CH1303BLF-03 OPERATING INSTRUCTIONS A188332C Adjust Seat Height: To raise the seat height, stand up from the chair while lifting the lever (A) under the right side of the seat. To lower the seat height, lift the lever (A) while sitting in the chair.
- Page 3 CH1303BLF-03 OPERATING INSTRUCTIONS A188332C Backrest Recline Lock/Unlock Lift the lever (C) to allow chair back to recline when leaned against. Press lever (C) down to lock the chair back in the upright, vertical position. Respaldo de reclinación / desbloqueo Levante la palanca (C) para permitir que la silla se recline cuando se apoye.
- Page 4 CH1303BLF-03 OPERATING INSTRUCTIONS A188332C Sliding Seat Adjustment Push the lever (E) upward to allow seat to slide forward or backward. Release handle to lock in desired seat position Ajuste del asiento deslizable Empuje la palanca (E) hacia arriba para permitir que el asiento desliza hacia adelante o hacia atrás.
- Page 5 CH1303BLF-03 OPERATING INSTRUCTIONS A188332C Arm Width Adjustment To adjust armrest width, rotate the lever attached to the underside of the armrest bracket and move the armrest to the desired position. Rotate the lever back to starting position to lock armrest in place.
- Page 6 CHAIR WARNING DO NOT STAND ON THIS CHAIR. DO NOT USE THIS CHAIR AS A STEP LADDER. FAILURE TO FOLLOW THESE WARNINGS COULD RESULT IN SERIOUS INJURY! - Use this product only for seating one person at a time. - This chair has been tested and approved for users weighing 275lbs (125kg).
- Page 7 1,2,3 1,2,3 IT’S AS EASY AS IT’S AS EASY AS Assembly tips: Assembly tips: 1. Read the instructions and become familiar with the parts. 1. Read the instructions and become familiar with the parts. 2. Ensure this carton contains all parts, fasteners and 2.
- Page 8 WARRANTY INFORMATION/INFORMATIONS POUR LA GARANTIE/INFORMACIÓN DE GARANTÍA BUSH BUSINESS FURNITURE’S VOTRE GARANTIE BUSH BUSINESS GARANTIA ESCRITA DE BUSH WRITTEN WARRANTY TO YOU FURNITURE BUSINESS FURNITURE PARA USTED In order to provide you with timely assistance, Afin de vous assister rapidement, veuillez Para brindarle asistencia oportuna, por favor, please thoroughly inspect your furniture for inspecter votre mobilier en détail immédiatement...
