- Page 1 IN-E-HyClip DI-V1_10 Document code HygroClip DI digital interface: instruction manual Document title Instruction Manual © 2007; Rotronic AG Rotronic AG Bassersdorf, Switzerland Unit HygroClip DI Digital Interface v 1.0 Instruction Manual Document Type Page 1 of 24 IN-E-HyClip DI-V1_10.doc...
-
Page 2: Table Of Contents
IN-E-HyClip DI-V1_10 Document code HygroClip DI digital interface: instruction manual Document title Contents: Overview... 3 Models ... 3 Power supply ... 4 Probes ... 4 Connector identification ... 6 Pin-out diagrams ... 7 Operation with the HW4 software... 7 HW4 software requirements ... 7 HW4 Device Manager ... -
Page 3: Overview
IN-E-HyClip DI-V1_10 Document code HygroClip DI digital interface: instruction manual Document title Overview The HygroClip DI (Digital Interface) allows connecting up to two HygroClip digital humidity- temperature probes to a PC, either by means of a USB port or by means of a wired / wireless TCP/IP network (LAN / Internet). -
Page 4: Power Supply
IN-E-HyClip DI-V1_10 Document code HygroClip DI digital interface: instruction manual Document title HygroClip DI-4 • • • • HygroClip DI-4-WL • • • • Power supply The HygroClip DI is shipped with a regulated 12 VDC / 100…240 VAC adapter (170 mA). - Page 5 IN-E-HyClip DI-V1_10 Document code HygroClip DI digital interface: instruction manual Document title © 2007; Rotronic AG Rotronic AG Bassersdorf, Switzerland Unit Instruction Manual Document Type Page 5 of 24 HygroClip S measurement in air max. 85°C (185°F) – wire mesh filter...
-
Page 6: Connector Identification
IN-E-HyClip DI-V1_10 Document code HygroClip DI digital interface: instruction manual Document title The following probes have a 7-pin connector. An adapter cable such as the T7-03-B5 is required for connection to the HygroClip DI (see Accessories). Extension cable model AC1616 is not compatible with the HygroClip DI. -
Page 7: Pin-Out Diagrams
IN-E-HyClip DI-V1_10 Document code HygroClip DI digital interface: instruction manual Document title Pin-out diagrams Input 1, 2 and 3 (HygroLog NT2, NT3) - solder side of matching male connector 1: not used 2: power (DC+) 3: GND 4: DIO 5: not used... -
Page 8: Hw4 Device Manager
IN-E-HyClip DI-V1_10 Document code HygroClip DI digital interface: instruction manual Document title Operating System compatibility: ● Windows XP, NT4 with SP 6a or higher ● Windows 2000 with SP 2 or higher ● Windows Server 2003 HW4 was written for the Microsoft .NET framework and requires this framework to be installed on the computer. - Page 9 IN-E-HyClip DI-V1_10 Document code HygroClip DI digital interface: instruction manual Document title The forms that are available within the Device Manager form are listed in a tree located on the left pane of the form. To select a form, click on it with the left mouse button.
-
Page 10: Device Information
IN-E-HyClip DI-V1_10 Document code HygroClip DI digital interface: instruction manual Document title Device Information ● Device name: this text will be displayed next to the instrument model information. As far as possible use a unique device name. ● RS485 address: click on the underlined link to change the instrument address to be used in conjunction with an RS-485 network (multi-drop). - Page 11 IN-E-HyClip DI-V1_10 Document code HygroClip DI digital interface: instruction manual Document title Language / Unit System ● Units: use the underlined links to the right of the form to globally change the unit system used by the instrument. If the unit system offers several choices such as In Hg or PSI for pressure, choose a unit by left clicking on the arrow to the right of each text box.
- Page 12 IN-E-HyClip DI-V1_10 Document code HygroClip DI digital interface: instruction manual Document title Probe Inputs Clicking on the plus sign to the left of “Probe Inputs” expands the tree and displays probe inputs 1 and 2. Note: the HygroClip DI accepts HygroClip probes only.
-
Page 13: Digital Interface
IN-E-HyClip DI-V1_10 Document code HygroClip DI digital interface: instruction manual Document title Dew point (Dp) or Frost point (Fp): depending on the selection made here, HW4 will display either the symbol Dp or the symbol Fp. The symbol Fp indicates that any value below freezing is a frost point as opposed to a dew point. -
Page 14: Compliance With Fda 21Cfr Part Ii And Gamp
HygroClip DI-4 and DI-4-WL: after changing the baud rate in Device Manager, you should also reflect the change in the configuration of the internal Digi International module used by the device to connect to the LAN. See Baud rate compatibility requirements. - Page 15 IN-E-HyClip DI-V1_10 Document code HygroClip DI digital interface: instruction manual Document title To protect the device, click on the underlined link. HW4 opens the following form where a password can be entered (maximum 8 characters): Enter the password and click on the OK button. HW4 confirms that the device is now protected: ©...
- Page 16 IN-E-HyClip DI-V1_10 Document code HygroClip DI digital interface: instruction manual Document title To unprotect the device and enable all functions, click on the underlined link. HW4 opens the password form: Enter the password and click on the OK button. HW4 confirms that the device is now unprotected.
-
Page 17: Probe Adjustment
Manager function (Digital Interface tab) available from within the HW4 software. • The Baud rate of a Digi Module can be changed only from the module web interface. See separate document IN-E-TCPIP-Conf_10.doc (also available in PDF format). © 2007; Rotronic AG... -
Page 18: Ethernet Local Area Network
ROTRONIC devices with an Ethernet (TCP/IP) interface presently use an internal module manufactured by Digi International (Digi Connect ME for a wired connection, Digi Connect WI-ME for a wireless connection). Both types of module feature a web interface that is used to configure the module. - Page 19 IN-E-HyClip DI-V1_10 Document code HygroClip DI digital interface: instruction manual Document title for RS-485 slaves” is being used, HW4 automatically changes from 00 to 01 the RS-485 address of any master that has slaves attached. As a result, all masters end up with the same RS-485 network address (01).
-
Page 20: Specifications
IN-E-HyClip DI-V1_10 Document code HygroClip DI digital interface: instruction manual Document title 11. Specifications Model HygroClip DI-3 PC Interface Serial interface Baud rate : 19200 or 57600 (RS-485) Data bits : 8 Stop bits : 1 Parity Probe inputs 2 (HygroClip humidity-temperature probes only) Operating limits electronics 0…100 %RH / -40…85 °C (-40…185°F) -
Page 21: Accessories
IN-E-HyClip DI-V1_10 Document code HygroClip DI digital interface: instruction manual Document title 12. Accessories Order Code Description HW4-E HW4 Edition software (CD ROM), single user HW4-P HW4 Professional software (CD ROM) MOK-02-B5 Adapter cable for HygroClip probes with DAT05 connector (use for inputs 2 MOK-05-B5 to 7). -
Page 22: Electrical Installation Guidelines
IN-E-HyClip DI-V1_10 Document code HygroClip DI digital interface: instruction manual Document title 14. Electrical Installation Guidelines Power supply wiring Heavy machinery and instrumentation should not share the same power supply wiring. If this cannot be avoided, noise filters and surge protectors should be used. Most UPS devices have those features already integrated. - Page 23 IN-E-HyClip DI-V1_10 Document code HygroClip DI digital interface: instruction manual Document title Lightning protection Cabling in areas with a risk of lightning requires a lightning protection. For cabling underground in between buildings, we recommend the use of special fiber optic cables. If this is not possible, use copper cables that are suitable for underground installation.
-
Page 24: Document Releases
IN-E-HyClip DI-V1_10 Document code HygroClip DI digital interface: instruction manual Document title The following points should also be observed: • Close the parasitic circuit • Connect all devices to the potential equalizing cable as often as possible. Electrical conductors such as machine elements, metal tubes or supporting constructions should be integrated into the system.
