Description; Assembly - ALPATEC RHC TENDANCE User Manual

Notice RHC Tendance
1. Handle
2a. Light switche : Power I
2b. Light switche : Power II
3. Thermostat
4. Water tank (Humidification system)
5. Casters
6.Foot
7. Power cord box with tip
8. Power cord
PUISSANCE
I
Arrêt
II
Arrêt
a. 2 casters
b. 1 axe
c. 1 foot
d. 2 screw and nut parts
• Assemble on the handle side the foot (c) using one
screw and nut part (d).
• Assemble on the water tank side the axe (b) using the
second screw and nut part (d).
• Insert the casters (a) in the axe (b).
