Soluzione Solare ENVMETER-485 PRO User Manual

GENERAL DESCRIPTION
Envmeter-485 Pro is a temperature and humidity sensor for meteorological uses with RS485 Modbus output, based on a top-of-
the-range hygrometer and on a microcontroller that manages the information and transmits it in RS485.
FEATURES
Misure:
Temperature range:
Relative humidity range:
Output:
serial:
Resolution:
Accuracy:
Temperature:
Relative humidity:
Non-linearity:
Working temperature range:
Supply voltage:
Consumption (@ 12V):
Encapsulation:
Casing:
Connector:
Dimensions:

(1) in the range 20 °C 60 °C - for measurement precision outside this range, consult the technical data sheet.

(2) in the range 0 80 %RH - for measurement accuracy outside this range, consult the technical data sheet.
Supplied material:
- Instrument
- User manual
- M8 4 pin female connector
- Support bracket for pole mounting (optional)
ENVMETER-485 PRO – User Manual (05/2023)
ENVMETER-485 PRO
USER MANUAL
hw rev. 95.00.-00.20
-40  125 °C
0  100 %HR
RS485, standard Modbus RTU protocol
0.1 of given value
 0,1 °C
 1,5 %HR
≤0.3%
-40  +125 °C
7,5  28Vdc (See page 2)
< 5 mA
resin conformal coating
6 plates in white resin resistant to atmospheric agents and UV
Male M8 4 pin
height 160mm, diameter 75mm
PRODUCTION BATCH DETAILS:
- Date:................................ Operator: ..........................................
- S/N:................................. Modbus Node: .........

(1)
(2)
