COMPASS

FOR PPC/RPM™

Pressure Calibration Software

User's Manual

Table of Contents

Need help?

Do you have a question about the COMPASS FOR PPC - V2.0 and is the answer not in the manual?

Questions and answers

Summary of Contents for DH Instruments COMPASS FOR PPC - V2.0

Page 2 High pressure liquids and gases are potentially hazardous. Energy stored in these liquids and gases can be released unexpectedly and with extreme force. High pressure systems should be assembled and operated only by personnel who have been instructed in proper safety practices. ©...
Page 3: Table Of Contents
TABLE OF CONTENTS T AB L E O F C O N T E N T S ............. I T AB L E S .
Page 4 ® COMPASS FOR PPC/RPM™ USER’S MANUAL T H E [ D U T ] M E N U ............. 2 3 OVERVIEW ............................23 [DUT], [CREATE DUT] ..........................23 [DUT], [EDIT DUT FILE] ........................27...
Page 5 TABLE OF CONTENTS 10.3.1.4 [FILE], [CREATE TEMPLATE] ....................64 10.3.1.5 [FILE], [SAVE] .......................... 64 10.3.1.6 [FILE], [SAVE AS] ..........................65 10.3.1.7 [FILE], [SAVE ALL]..........................65 10.3.1.8 [FILE], [CLOSE] ........................... 65 10.3.1.9 [FILE], [CLOSE ALL] ..........................65 10.3.1.10 [FILE], [PRINT] ......................... 65 10.3.1.11 [FILE], [PRINT ALL]..........................
Page 6 ® COMPASS FOR PPC/RPM™ USER’S MANUAL 13.1.3 EXAMPLE #3............................85 13.1.3.1 EXAMPLE MULTIPLEXER SETUP ...................... 86 13.1.3.2 EXAMPLE DMM SETUP........................87 13.1.3.3 UPDATE THE CONFIGURATION......................87 13.1.3.4 CONNECT THE DUTS......................... 87 13.1.3.5 RUN THE TEST ........................... 87 1 4 . Q U I C K T I P S ..............8 9 14.1 HOW DO I? ............................89 1 5 .
Page 7: Tables
TABLES & FIGURES Table 1. Run Test Screen ..........................8 Table 2. Tools Available on the Toolbar ....................10 Table 3. <Test Complete> Screen Options....................20 Table 4. <DUT Definition/Profile> Screen....................24 Table 5. <Test Points> Table ........................31 Table 6. [Auto Fill Points] Tab........................32 Table 7.
Page 8 ® COMPASS FOR PPC/RPM™ USER’S MANUAL Figure 1. Language Selection ........................4 Figure 2. Run Test Screen ........................... 8 Figure 3. Select the DUT file for the Test Screen ..................13 Figure 4. DUT Definition (C:\COMP4PRS\DUT\DUCE …) Screen ............13 Figure 5.
Page 9 TABLES & FIGURES Figure 45. Example #1 Configuration ......................81 Figure 46. Example #1 DUT Interface Setup ..................... 81 Figure 47. Example #1 RS232 Setup with Ref Com2................82 Figure 48. Example #2 User Defined Unit Setup ..................83 Figure 49. Example #2 DMM DUT Data Acquisition.................. 83 Figure 50.
Page 11: U S E R R E G I S T R A T I On
USER REGISTRATION Pressure Calibration Software Please fill out this registration sheet and return it to DH Instruments. Registering as a user will allow us ® to contact you with important information about COMPASS including product upgrades, possible recalls and product announcements. ®...
Page 13: A B O U T T H I S M A N U Al
ABOUT THIS MANUAL Manual Conventions This manual provides the user with the basic information necessary to set up and run COMPASS for PPC/RPM. It also includes a great deal of additional information provided to help you optimize COMPASS use and take full advantage of its many features and functions. Before using the manual, take a moment to familiarize yourself with the Table of Contents structure.
Page 15: I N T R O D U C T I On
1. INTRODUCTION PRODUCT OVERVIEW ® Welcome to COMPASS for PPC/RPM™, the complete pressure calibration software package for users of DHI PPC2, PPC2+, PPCK and RPM3 pressure transfer standards. COMPASS for PPC/RPM is designed to supply the missing link needed to get from individual automated hardware components to an automated pressure calibration system.
Page 17: G E T T I N G S T Ar T E D
2. GETTING STARTED OVERVIEW This section explains how to install COMPASS for PPC/RPM on your computer. Although COMPASS for PPC/RPM is a multilingual application, the installation always uses English. SYSTEM REQUIREMENTS COMPASS for PPC/RPM is an application designed for Windows 32 bit operating systems. The following minimum configuration is required to run COMPASS: •...
Page 18: Uninstalling
® COMPASS FOR PPC/RPM™ USER’S MANUAL language. Subsequent runs of COMPASS display this dialog in the language selected in the previous run. The [English] button will always run COMPASS in English and has the same effect as choosing [English] from the language list. Check the <Do not display..> box at the bottom of the window to prevent this display in the future.
Page 19: O P E R At I N G P R I N C I P L E S
3. OPERATING PRINCIPLES OVERVIEW COMPASS for PPC/RPM is an application program intended to automate the test and calibration process to the extent supported by your calibration hardware and appropriate for the DUT being calibrated. COMPASS supports automated operation of DHI PPC and RPM transfer standards but can also be used with any type of pressure standard from any manufacturer.
Page 20: Basics Summary
® COMPASS FOR PPC/RPM™ USER’S MANUAL 3.1.1 BASICS SUMMARY In summary, the following steps and sections should be referred to while trying to set up and run a test for the first time. Subsequent tests will only require a selection of the desired DUT and test file.
Page 21: M Ai N R U N S C R E E N
4. MAIN RUN SCREEN OVERVIEW The main screen contains the: • Main menu bar to access all COMPASS menus and functions (see Section 4.2). • Run test toolbar with seven test running short cut keys (see Section 4.4). • Run test screen providing complete real time information on test progress and results as a test is running (see Section 4.3).
Page 22: Run Test Screen
® COMPASS FOR PPC/RPM™ USER’S MANUAL RUN TEST SCREEN The Run Test screen provides real time information on test execution while a test is running. Figure 2. Run Test Screen The run test screen is segmented into eight functional areas described on Table 1. Table 1.
Page 23: 4 . Q U I C K T I P
4. MAIN RUN SCREEN FEATURE DESCRIPTION Identifies the DUT that is currently being displayed in the test point log and in the run time <Current Display> Selector plot. DUTs are identified by serial number/ID. If multiple DUTs are being tested, a drop- (Top of bottom left hand down menu to select an individual DUT or <All>...
Page 24: Run Test Toolbar
® COMPASS FOR PPC/RPM™ USER’S MANUAL RUN TEST TOOLBAR The run test toolbar provides a shortcut method for starting a test, accessing DUT and test procedure information while a test is running and other test functions. The toolbar is located in the upper left-hand corner of the main run screen.
Page 25: T H E [ R U N ] M E N
5. THE [RUN] MENU OVERVIEW The [Run] menu is used to execute a test and to exit COMPASS. It has the following choices: [Run Test], [Re-Run Test] and [Exit]. [RUN], [RUN TEST] This menu selection is used to start execution of a test. Pressing the [Run] key on the run test toolbar has the same effect as selecting this menu option.
Page 26: Select Dut File
® COMPASS FOR PPC/RPM™ USER’S MANUAL Reference Verification/Range Selection (see Section 5.2.1.5): The reference verification screen is presented identifying the source of reference pressures to be used in running the test. If the reference has multiple ranges and can be communicated with remotely, the range selection function is included.
Page 27: Preview Dut
5. THE [RUN] MENU To select the DUT based on its file name, or if the file you want was not stored in the directory specified for DUTs in your file location preferences (see Section 8.3.5), click <Browse> to activate a standard Windows file selection pop-up. Figure 3.
Page 28: Select Test File
® COMPASS FOR PPC/RPM™ USER’S MANUAL 5.2.1.3 SELECT TEST FILE The select test file screen is presented identifying the primary and secondary test files associated with the current DUT and allowing browsing of the test files available. If this step is turned OFF, the screen is not shown and the primary test file associated with the DUT is automatically selected.
Page 29: Reference Verification
5. THE [RUN] MENU 5.2.1.5 REFERENCE VERIFICATION The reference verification screen is presented identifying the source of reference pressures to be used in running the test. If COMPASS can communicate with the reference remotely and the reference has multiple ranges, the reference range selection tool and head adjustment is also included.
Page 30: Setup Dut(S)
® COMPASS FOR PPC/RPM™ USER’S MANUAL 5.2.1.6 SETUP DUT(S) The setup DUT(s) screen is presented. This screen is intended to allow input of DUT identification and communication details if necessary. See Section 6.2 for information on DUT profiles vs. definition files and DUT data acquisition type.
Page 31 5. THE [RUN] MENU Setup DUT(s) - Data Acquisition When using the <Setup DUTs> screen, keep in mind that DUT Data Acquisition type refers to the manner in which data will be gathered from the DUT. DUTs with electrical outputs are read with a DMM and the data acquisition type is DMM (it is not the interface on the DMM such as RS232 or IEEE 488).
Page 32: User Id
® COMPASS FOR PPC/RPM™ USER’S MANUAL Position 3 of the communications setup, even if there is no entry in Positions 1 and 2). 5.2.1.7 USER ID The user ID entry screen is presented. The last user ID can be accepted, a new user ID may be entered, or a previously entered user ID may be selected from the user ID drop down list.
Page 33: Manual Entry Data Acquisition
5. THE [RUN] MENU Set pressure test point: The test pressure point is set. How the pressure is set is determined by the *.tst file. If pressure setting is manual, the user is prompted to set the pressure to the pressure point value. If pressure setting is automated, pressure is set automatically using either dynamic or static control as specified in the *.tst file.
Page 34: Test Conclusion
® COMPASS FOR PPC/RPM™ USER’S MANUAL 5.2.3 TEST CONCLUSION After run test is complete, test conclusion begins. Test conclusion has two steps. Test Notes: The <Test Notes> pop-up appears to allow the user to enter notes concerning the test run that has just completed. The notes are included in the raw data file and can be used in reports.
Page 35: Run], [Re-Run Test]
5. THE [RUN] MENU [RUN], [RE-RUN TEST] [Re-Run Test] is provided to restart a test that was aborted prior to completion for setup specific reasons, for example when a test was started without a pressure supply. If the test is aborted [Re-Run Test] can be used to skip the test initialization steps.
Page 37: T H E [ D U T ] M E N
6. THE [DUT] MENU OVERVIEW The DUT Menu accesses the functions used to set up and maintain *.dut files. *.dut files define the devices under test (DUTs) that are tested using COMPASS. [DUT], [CREATE DUT] The *.dut file defines all the characteristics of a DUT to be tested by COMPASS. [Create DUT] is used to create a new *.dut file from scratch.
Page 38: Table 4. Screen
® COMPASS FOR PPC/RPM™ USER’S MANUAL The purpose of the <DUT Definition/Profile> fields and settings as well as instructions on how to use them are provided in Table 4. Table 4. <DUT Definition/Profile> Screen FEATURE DESCRIPTION Determines whether the *.dut file created will be a DUT definition or a DUT profile. One must be DUT Definition / selected.
Page 39 6. THE [DUT] MENU FEATURE DESCRIPTION Pressure measurement mode (gauge or absolute) of the DUT. Clicking on this field causes the Pressure Mode <Unit/Mode Selection> pop-up to appear. Click the [Mode] tab and select <Absolute Mode> or (selection field) <Gauge Mode> by clicking the corresponding radio button. If the DUT measurement mode is differential, select gauge.
Page 40 ® COMPASS FOR PPC/RPM™ USER’S MANUAL FEATURE DESCRIPTION Specifies the value in % to use in calculating the DUT tolerance. If the DUT tolerance type is Tolerance Value %DUTspan or %DUTreading, there is only one entry field. If the DUT tolerance type is (%DUTspan (required entry or %DUTreading) or (%DUTspan + %DUT reading), there are two entry fields.
Page 41: Dut], [Edit Dut File]
6. THE [DUT] MENU [DUT], [EDIT DUT FILE] [Edit DUT File] is used to modify an existing *.dut file. Use [Edit DUT File] to change an existing *.dut file or make a new *.dut file from an old one (see Section 6.3). Selecting [DUT], [Edit DUT file], causes the DUT selection tool (see Section 5.2.1.1) to be presented to allow easy identification and selection of the DUT file to edit.
Page 43: T H E [ T E S T ] M E N
7. THE [TEST] MENU OVERVIEW The Test Menu accesses the functions used to set up and maintain *.tst files. *.tst files define the test procedures used by COMPASS to test DUTs in the run test portion of test execution (see Section 5.2.2). [TEST], [CREATE TEST] The *.tst file defines the test procedure that is used when COMPASS runs a test on a DUT.
Page 44: Test], [Create Test], Table
® COMPASS FOR PPC/RPM™ USER’S MANUAL The <Test Definition> screen is made up of six main sections: <Test Points> Table Lists the test points included in the test procedure. Test points can be edited in the table or using the [Auto Fill Points] tab (see Section 7.2.1). [Auto Fill Points] Tab Provides a short cut method for filling in the <Test Points>...
Page 45: Zero Absolute Test Points
7. THE [TEST] MENU Table 5. <Test Points> Table FEATURE DESCRIPTION Indicates either <%DUT Span> or <Pressure>. If the indication is <Pressure>, when a test Point Type is run the table values will be run directly as pressure values in the pressure unit and mode Indication specified in the DUT file.
Page 46: Test], [Create Test], [Leak Test] Tab
® COMPASS FOR PPC/RPM™ USER’S MANUAL Figure 14. Test Definition Screen - Auto Fill Points The purpose of the [Auto Fill Points] tab’s fields and settings as well as instructions on how to use them are provided Table 6. Table 6. [Auto Fill Points] Tab FEATURE DESCRIPTION Selects whether the points in the test point table represent <%DUT Span>...
Page 47: Table 7. [Leak Test] Tab
7. THE [TEST] MENU The leak rate is calculated as the difference in pressure from the beginning and end of the leak test divided by the leak time. The leak test pass/fail is determined by comparing this value to the <Leak Rate Limit> of the test file. Figure 15.
Page 48: Test], [Create Test], [Cycle] Tab
® COMPASS FOR PPC/RPM™ USER’S MANUAL FEATURE DESCRIPTION The selection determines whether test execution will continue if the leak test fails (a set Continue on pressure time-out occurs or the leak rate limit is exceeded). If <Yes> is selected, the test Failure will continue if the leak test fails and the failure will be indicated in the test data file.
Page 49: Test], [Create Test], [Control Settings] Tab
7. THE [TEST] MENU The purpose of the [Cycle] tab’s fields and settings as well as instructions on how to use them are provided in Table 8. Table 8. [Cycle] Tab FEATURE DESCRIPTION Determines whether pressure exercising will be conducted at the beginning of run test or Run Cycles not.
Page 50: Table 9. [Control Settings] Tab
® COMPASS FOR PPC/RPM™ USER’S MANUAL Figure 17. Test Definition Screen – Control Settings The purpose of the [Control Settings] tab’s fields and settings as well as instructions on how to use them are provided Table 9. Table 9. [Control Settings] Tab FEATURE DESCRIPTION Determines how pressure will be controlled to set pressures when running a test.
Page 51: Test], [Create Test], [Sequence] Tab
7. THE [TEST] MENU FEATURE DESCRIPTION Defines the amount of time in seconds before a time-out will occur if a ready condition has Control Time- not been achieved in response to a set pressure command to an automated pressure out(s) controller.
Page 52: Test], [Edit Test File]
® COMPASS FOR PPC/RPM™ USER’S MANUAL FEATURE DESCRIPTION COMPASS can run up to 10 test cycles in one test. A test cycle includes setting and taking data Number of Test at each of the test pressure points in the test point table. When test cycles are set to more than Cycles one test cycle, leak testing and exercising (see Section 5.2.2) occur only at the beginning of (entry field)
Page 53: T H E [ T O O L S ] M E N
8. THE [TOOLS] MENU OVERVIEW The [Tools] menu accesses tools that allow COMPASS configurations and options to be customized to the user’s preferences. A tool for direct, single command communication with remote devices is also included for troubleshooting. [TOOLS], [CONFIG HARDWARE] Selecting [Tools], [Config Hardware] sets up the hardware that is used by COMPASS to run tests.
Page 54: Tools], [Config Hardware], [Configuration] Tab
® COMPASS FOR PPC/RPM™ USER’S MANUAL 8.2.1 [TOOLS], [CONFIG HARDWARE], [CONFIGURATION] TAB [Tools], [Config Hardware], [CONFIGURATION] is a tab selected panel used to select the components to include in the hardware setup that COMPASS uses when running tests. Each hardware component is selected form a drop-down list. The selections available on the drop-down lists created...
Page 55: Tools], [Config Hardware], [Reference] Tab
8. THE [TOOLS] MENU Table 11. [CONFIGURATION] Tab FEATURE DESCRIPTION This is the device that will be used to supply reference pressures and, if it’s a controller, to Pressure set pressures when a test is run. The drop-down list choices are set up using the Reference [Reference] tab (see Section 8.2.2).
Page 56: Figure 20. Compass Configuration Settings
® COMPASS FOR PPC/RPM™ USER’S MANUAL The <Edit Reference Device> or <Add New Reference Device> pop-ups allow a reference device to be set up from scratch or edited from an existing one. Figure 20. COMPASS Configuration Settings Figure 21. Edit Reference Device Screen The purpose of the reference device definition fields and settings as well as instructions on how to use them are provided in Table 12.
Page 57: Tools], [Config Hardware], [Dmm] Tab
8. THE [TOOLS] MENU Table 12. [Reference] Tab FEATURE DESCRIPTION Defines the model of the reference device. The drop-down list choices include all of the DHI Model models which COMPASS supports with remote communications: PPC2, PPC2+, PPCK, (drop-down RPM1, RPM3. An <Other> choice is also available. Use this choice to set up reference selection list) devices other than the DHI models just listed.
Page 58: Figure 22. Compass Configuration Settings Screen - Dmm
® COMPASS FOR PPC/RPM™ USER’S MANUAL the device is successful, the results displayed; if communications cannot be established, an error message is displayed. Double clicking on the DMM listing, clicking on the <Edit> button or clicking on the <New> button, causes the <Edit DMM> or <Add New DMM> pop-up to appear. These pop-ups are identical but differentiated by name to make it clear which task is currently being performed.
Page 59: Table 13. [Dmm] Tab
8. THE [TOOLS] MENU Table 13. [DMM] Tab FEATURE DESCRIPTION Defines the model of the DMM. Model (required entry field) Write in the DMM serial number. Serial Number (required entry field) Write in a device identification, if desired. The field can be used for internal tracking of DMMs or Identification any other information desired.
Page 60: Tools], [Config Hardware], [Multiplexer] Tab
® COMPASS FOR PPC/RPM™ USER’S MANUAL 8.2.4 [TOOLS], [CONFIG HARDWARE], [MULTIPLEXER] TAB [Tools], [Config Hardware], [Multiplexer] is a tab selected panel used to set up the multiplexer(s) (MUX) available to COMPASS. The panel allows new MUXs to be created and existing MUXs to be edited.
Page 61: Table 14. [Multiplexer] Tab
8. THE [TOOLS] MENU Table 14. [Multiplexer] Tab FEATURE DESCRIPTION Defines the model of the multiplexer. Model (required entry field) Write in the multiplexer serial number. Serial Number (required entry field) Write in a device identification, if desired. The field can be used for internal tracking of Identification MUXs or any other information desired.
Page 62: Tools], [Config Hardware], [Ieee 488]
® COMPASS FOR PPC/RPM™ USER’S MANUAL 8.2.5 [TOOLS], [CONFIG HARDWARE], [IEEE 488] [Tools], [Config Hardware], [IEEE 488] is a tab selected panel used to set up the IEEE 488 cards that the computer running COMPASS can use for IEEE 488 communications. The panel allows a Capital Equipment Corporation (CEC) or National Instruments’...
Page 63: Tools], [Options]
8. THE [TOOLS] MENU Use the <Ref Com2> selection found at the end of the <COM Port> drop-down list to access the currently configured reference COM2 port rather than a standard communications port on the host PC. If the reference device does not have a remote interface, COMPASS will generate an error when trying to access the port.
Page 64: Tools], [Options], [Maintain Lists]
® COMPASS FOR PPC/RPM™ USER’S MANUAL 8.3.1 [TOOLS], [OPTIONS], [MAINTAIN LISTS] [Tools], [Options], [Maintain Lists] is a tab selected panel used to delete unwanted items from the various lists that COMPASS adds to automatically. To delete an item from a list, select the item from the drop-down list and click the corresponding <Del>...
Page 65: Tools], [Options], [Run Test]
8. THE [TOOLS] MENU Table 16. [Initialize Test] Tab FEATURE DESCRIPTION When OFF, the select DUT step is skipped and the last DUT that has been accessed Select DUT (edited, viewed, created or run) is automatically used as the selected DUT (see Section (check box) 5.2.1.1).
Page 66: Table 17. [Run Test] Tab
® COMPASS FOR PPC/RPM™ USER’S MANUAL Figure 30. Options Screen - Run Test The purpose and operation of the run test preferences are defined in Table 17. Table 17. [Run Test] Tab FEATURE DESCRIPTION These check boxes turn ON and OFF audible feedback associated with run time events. Audible Feedback On When the box is checked, audible feedback is ON, when the box is blank, audible (check boxes)
Page 67: Tools], [Options], [Data File]
8. THE [TOOLS] MENU FEATURE DESCRIPTION Affects how reference readings are taken when reference readings are entered manually Use common and multiple DUTs are being tested. If the box is checked, a single reference pressure manual reference entry will be made common for all of the DUT readings. If the box is not checked, an pressure for individual reference reading must be entered for each DUT.
Page 68: Tools], [Options], [File Locations]
® COMPASS FOR PPC/RPM™ USER’S MANUAL 8.3.5 [TOOLS], [OPTIONS], [FILE LOCATIONS] [Tools], [Options], [File Locations] is a tab selected panel used to view or modify the default directory path used to store each of the various file classes used by COMPASS. To edit the directory path for a specific file class either double click on that file class or single click the file class and then click <Edit>.
Page 69: Tools], [Remote Communications]
8. THE [TOOLS] MENU COMPASS for PPC/RPM uses the decimal separator set up in the international settings of Windows. This determines whether the separator is a “.” or a “,”. COMPASS is run in one language at a time. Any language selection using this option will not occur until COMPASS is restarted.
Page 70: Figure 33. Remote Communications Screen
® COMPASS FOR PPC/RPM™ USER’S MANUAL Figure 33. Remote Communications Screen © 1998-2000 DH Instruments, Inc. Page 56...
Page 71: T H E [ D At A ] M E N
9. THE [DATA] MENU OVERVIEW The [Data] menu accesses tools that work directly with COMPASS *.dat files. The *.dat files contain the data acquired during a test run (see Section 12). The data tools allow the “data” file to be viewed and printed. There is also a plotting tool to produce and print a variety of error plots for *.dat files.
Page 72: Data], [Print Test Data]
® COMPASS FOR PPC/RPM™ USER’S MANUAL [DATA], [PRINT TEST DATA] [Data], [Print Test Data] is used to print raw data files. When [Data], [Print Test Data] is selected, a standard Windows file browser appears with the default directly set to the default *.dat directory (see Section 8.3.5). Selecting a file causes the standard Windows print function to open allowing the file to be printed with any printer that is set up.
Page 73: Data], [Plot Test Data], [File]
9. THE [DATA] MENU 9.4.1 [DATA], [PLOT TEST DATA], [FILE] The [File] menu includes menu choices to: [Select Data File] Allows selection, using a standard Windows file browser, of a different data file to be plotted. [Print Graph] Allows the graph currently selected to be printed using the standard Windows print function.
Page 75: Overview
10. THE [REPORT] MENU 10.1 OVERVIEW The purpose of the COMPASS Report Editor is to generate test reports from *.dat files, view the reports and edit them. The COMPASS Report Editor can be accessed in three ways: by using the [Report] menu option or pressing the <Generate Report>...
Page 76: Main Menu Bar
® COMPASS FOR PPC/RPM™ USER’S MANUAL 10.3 MAIN MENU BAR The main menu of the report editor is divided into several sections each with a separate function. Many of these functions can also be accessed by a shortcut included on one of the COMPASS Report Editor toolbars.
Page 77: Fi L E ], [Ed I T Re P O R T ]
10. THE [REPORT] MENU 10.3.1.1 [FI L E ], [ED I T RE P O R T ] [Edit Report] is used to edit an existing report. Selecting this feature displays a standard Windows file selection tool set to the directory containing the data sub-directories in which reports are stored (see Section 12.3).
Page 78: File], [Create Template]
® COMPASS FOR PPC/RPM™ USER’S MANUAL The font and paragraph format of a field key is maintained during report generation. As a result the “data” file information that the field key represents will be inserted using the font and alignment characteristics of the field key.
Page 79: File], [Save As]
10. THE [REPORT] MENU 10.3.1.6 [FILE], [SAVE AS] [Save As] is used to save the current top file with a different name, essentially making a copy of the file. The option always displays a file selection box allowing the entry of a new file name and follows the same procedure as the [Save] option when an untitled file is saved (see Section 10.4.5).
Page 80: Edit] Menu
® COMPASS FOR PPC/RPM™ USER’S MANUAL 10.3.2 [EDIT] MENU The [Edit] menu provides common word processor editing functions. Many of these functions have several possible shortcuts. The toolbar and short cut keystrokes provide direct access to many editing features. All edit functions act on the current document only. A right mouse click in any open document accesses a mini edit menu with the basic edit options.
Page 81: Edit], [Find Next]
10. THE [REPORT] MENU Figure 37. Find Text Screen Table 19. <Find> Screen FEATURE DESCRIPTION The text entered in this field is the search text. Find What (required entry field) Select this feature when the search should match both case and text. Match Case Causes search to ignore occurrences of the search text that are Find Whole Word...
Page 82: Format], [Select Template]
® COMPASS FOR PPC/RPM™ USER’S MANUAL by clicking on the desired field name. The scroll bars may be used to move up and down in the category and name lists. Once the field name has been selected, click the <Insert> button to embed the link into the document at the current cursor location and close the Data Field Insertion Tool.
Page 83: Options] Menu
10. THE [REPORT] MENU Figure 39. Page Setup Screen 10.3.4 [OPTIONS] MENU The [Options] menu is the only main menu option that does not depend on the active document. The options in this menu toggle the display state of the program’s toolbars. 10.3.4.1 [OPTIONS], [TOOLBAR] The [Toolbar] refers to the main toolbar containing shortcuts to many of the file options.
Page 84: Options], [Ruler]
® COMPASS FOR PPC/RPM™ USER’S MANUAL Table 20. Font Format Toolbar FEATURE DESCRIPTION Displays and changes the current font. A complete list of all fonts supported by the PC displays in the font selection box. Font Selection Displays and changes the current font size. Enter the numerical value of the desired font size and press [ENTER].
Page 85: Window] Menu
10. THE [REPORT] MENU Figure 42. COMPASS Report Editor, Ruler Table 21. Ruler FEATURE DESCRIPTION Sets or displays the left indentation point of the first line of a paragraph. The ruler location of this indent always displays as the number of inches from the left margin. Left Indent Sets or displays the left hanging indent of subsequent lines in a paragraph.
Page 86: Drag And Drop
® COMPASS FOR PPC/RPM™ USER’S MANUAL 10.4.1 DRAG AND DROP The COMPASS Report Editor supports standard Windows file drag and drop features. A set of file names can be dragged to the title bar of the COMPASS Report Editor from Windows Explorer or the <Test Conclusion>...
Page 87: Overview
11. THE [HELP] MENU 11.1 OVERVIEW The [Help] accesses COMPASS on line help. [Show Help] opens the Help function to the Welcome screen from which Help functions can be accessed. [Search Help] opens the Help function to a standard keyword search tool. For further help on using COMPASS, refer to the on-line help.
Page 89: 2 . D At A F I L E
12. DATA FILES 12.1 OVERVIEW Data files (*.dat) are the files created by COMPASS to store the data relating to a test run on a DUT. Data files can be viewed, edited, printed and made into custom report all within COMPASS. Data files have also been designed to be easily exported to third party applications, such as spreadsheets or instrument management software.
Page 90: Data File Structure
® COMPASS FOR PPC/RPM™ USER’S MANUAL The automated *.dat file name follows dddddddaa0.dat where: ddddddd Is the date of the test using a four digit year followed by the Julian date (e.g., 1999001 for January 1, 1999). The year 2000 will, therefore be identified by 2000. “Data”...
Page 91 12. DATA FILES Test Data Includes, for each pressure point in the test: Nominal Set Point, Set Time, Reference Pressure, DUT Output, Error and Status. Calculations Includes values calculated from the test data: linearity, hysteresis, best fit straight line slope and offset (see Section 15). Notes User notes entered at the end of the test.
Page 93: 3 . A P P L I C At I O N E X A M P L E
13. APPLICATION EXAMPLES 13.1 OVERVIEW This section contains several generic application examples that cover many common COMPASS setups. Using these examples and the How Do I? tips in Section 14 will greatly simplify the learning process to get a test started. Although each example may not include explicit instructions on all test steps, there are three required steps that must be followed before a test can be run: Create (or select) a *.tst file.
Page 94: Set Up A Ppc2+ As The Reference
® COMPASS FOR PPC/RPM™ USER’S MANUAL Figure 43. RS232 DUT Example The RS232 communications port and settings have not been entered. This selection occurs in one of the last steps in test initialization, <Setup DUT(s) - Data Acquisition> (see Section 5.2.1). Figure 47 and the associated note describe what is necessary to select the RS232 port and settings.
Page 95: 13.1.1.3 Run The Test
13. APPLICATION EXAMPLES the [CONFIGURATION] tab after saving the reference setup. Select the PPC2+ in the <Pressure Reference> list. Since the PPC2+ will use an IEEE 488 interface, make sure an <IEEE 488 Card> selection is made. The <DMM> and <Multiplexer>...
Page 96: Example #2
® COMPASS FOR PPC/RPM™ USER’S MANUAL The COM2 port of the PPC2+ can be used instead of a communications port on the PC by selecting <Ref Com2> found at the end of the <COM Port> list. This selection is valid for any RS232 device except the pressure reference itself. Figure 47.
Page 97: Figure 48. Example #2 User Defined Unit Setup
13. APPLICATION EXAMPLES Figure 48. Example #2 User Defined Unit Setup Select DMM in the <DUT Data Acquisition> since this DUT outputs in mV and will use a DMM to read this output. There may be a temptation to select IEEE 488 or RS232 as the <DUT Data Acquisition>...
Page 98: 13.1.2.2 Dmm Configuration Setup
® COMPASS FOR PPC/RPM™ USER’S MANUAL 13.1.2.2 DMM CONFIGURATION SETUP Use [Tools], [Config Hardware] then select the <DMM> tab and click <New> to create a new DMM. Enter the basic DMM setup information at the top of the form. This particular DMM supports both RS232 and IEEE 488. In this example IEEE 488 is used.
Page 99: 13.1.2.3 Run The Test
PPC2+?” An HP34970A is a DMM/Multiplexer unit manufactured by Hewlett Packard that can contain up to 60 relay channels which can be individually routed to an internal multimeter. Fluke and Keithley also manufacture similar instruments. To read a voltage on channel 1 of this instrument requires the command “MEAS:VOLT:DC? (@101)”.
Page 100: 13.1.3.1 Example Multiplexer Setup
® COMPASS FOR PPC/RPM™ USER’S MANUAL the DC voltage measurement. Issuing the command “READ?” following a measure command will output another reading using the same channel and reading configuration. It is a short cut to issuing another measurement command. This example demonstrates how to set up a DMM and multiplexer configuration.
Page 101: 13.1.3.2 Example Dmm Setup
13. APPLICATION EXAMPLES Figure 53. Example Multiplexer Setup 13.1.3.2 EXAMPLE DMM SETUP Since the HP34970A is also the DMM for the test follow the outline in EXAMPLE #2, Section 13.1.2.2 to set up this device as the DMM. The only special requirement will be to use the same <Remote Interface>...
Page 102: Figure 54. Multiple Dut Setup With Dmm+Multiplexer Daq
® COMPASS FOR PPC/RPM™ USER’S MANUAL to be used to isolate channel 4 prior to reading the DMM. The <Data Acquisition> column displays “DMM+Multiplexer” to denote the fact that the multiplexer is part of the configuration of the DMM data acquisition DUT. Press <OK> to start the test. COMPASS will step through the test point sequence gathering data from the PPC2+ and all 8 DUTs (see Section 5.2.2).
Page 103: How Do I
14. QUICK TIPS 14.1 HOW DO I? Set up and run a test? Create a *.tst file to define the test procedure (see Section 7.2). Create a *.dut file to define a device under test (see Section 6.2). Configure the test hardware to be used to run the test (see Section 8.2.1). Run test (see Section 5.2).
Page 104 ® COMPASS FOR PPC/RPM™ USER’S MANUAL Repeat the same test several times without having to pause or restart the test? Specify multiple test cycles in the *.tst file that defines the test procedure. In the [Sequence] tab of test definition (see Section 7.2.6) specify a number greater than one under <Number of Test Cycles>. The test pressure sequence will run for the number of times specified without initializing between runs.
Page 105 14. QUICK TIPS Set up and use a combination DMM/multiplexer in a single unit such as the HP34970A? There are two possibilities: 1. Treat the single device as if it were a separate DMM and multiplexer. You actually set it up “twice”, once in the <DMM>...
Page 107: 5 . C Al C U L At I O N
15. CALCULATIONS 15.1 OVERVIEW COMPASS operation includes certain internal calculations. Most of these calculations are related to analyzing the data taken during a test run. The internal calculations performed by COMPASS are documented in the sections that follow. The calculations have been verified both by comparison of the program code content to the defined formulas and by parallel manual calculation.
Page 108: Tolerance
® COMPASS FOR PPC/RPM™ USER’S MANUAL − ×100 % Re ading 15.4 TOLERANCE The determination of whether a point is in or out of tolerance depends on the type of tolerance selected, and the DUT and reference pressures. Tolerance values may be in %DUTspan, %Reading or a combination of the two (see Section 6.2).
Page 109: Hysteresis
15. CALCULATIONS If the test point sequence is made up of corresponding ascending and descending (or vice-versa) points, linearity is calculated by taking the average between corresponding DUT pressures, drawing a straight line between the minimum and maximum DUT pressures and determining the maximum deviation of any average DUT pressure from this line.
Page 110: Table 22. Pressure Unit Conversion Chart
® COMPASS FOR PPC/RPM™ USER’S MANUAL Table 22. Pressure Unit Conversion Chart TO CONVERT FROM PA TO MULTIPLY BY Pascal Millibar mbar 1.0 E-02 kilo Pascal 1.0 E-03 1.0 E-05 mmWa @ 4 °C millimeter of water 1.019716 E-01 millimeter of mercury mmHg @ 0°C 7.50063 E-03 pound per square inch...
Page 111: Overview
16. DDE SUPPORT 16.1 OVERVIEW COMPASS for PPC/RPM can be monitored using Windows Dynamic Data Exchange (DDE). This feature gives users the ability to write programs that monitor COMPASS tests and take specific actions during the test process. The monitoring program should not attempt to change the behavior of COMPASS using the DDE interface.
Page 113: Overview
17. TROUBLESHOOTING 17.1 OVERVIEW COMPASS for PPC/RPM is a sophisticated software package with many advanced features that can be misused and/or misunderstood. Before assuming that unexpected behavior is caused by a software or hardware defect, the operator should use this manual in conjunction with the documentation of other instruments used with COMPASS to determine the appropriate behavior.
Page 114 ® COMPASS FOR PPC/RPM™ USER’S MANUAL SYMPTOM PROBABLE CAUSE SOLUTION I chose the National Instruments IEEE 488 All tabs in the [CONFIGURATION] Only the [CONFIGURATION] tab card on the [IEEE 488] tab of the are displays of available itself is used to make a selection. [CONFIGURATION] and each time I selections.
Page 115: Glossary
18. APPENDIX 18.1 GLOSSARY Averaging Time The time over which reference and DUT readings are made when taking data at a pressure point. COMPASS makes as many readings as possible during the averaging time and then averages the readings to arrive at the reference and DUT reading for the pressure point. Control Time Out The amount of time, when setting a pressure point in a test using automated pressure control, that COMPASS will wait for a ready condition.
Page 116 ® COMPASS FOR PPC/RPM™ USER’S MANUAL Measurement Mode Whether pressure is being measured relative to absolute zero or vacuum (absolute mode) or relative to atmospheric pressure (gauge mode). Measurement mode of the DUT refers to whether the DUT is configured to measure absolute pressure or gauge pressure. MUX (Multiplexer) Device that can be used by COMPASS to switch the output of multiple DMM data acquisition type DUTs to a single DMM so that data can be taken from multiple DUTs during a test.
Page 117: Overview
19. END USER LICENSE AGREEMENT 19.1 OVERVIEW COMPASS for PPC/RPM (COMPASS) is protected by copyright laws and international copyright treaties, as well as other intellectual property laws. COMPASS is licensed, not sold. You may install or use one copy of COMPASS on a single computer. The primary user of the computer on which COMPASS is installed may make a second copy for his or her use on a second computer used only for producing reports using the COMPASS Report Editor function.
Page 119 INDEX Exit · 11, 20, 21, 57, 59, 65 Exit Test · 20 Abort Test · 10, 18 Audible Feedback · 51, 52, 90 Auto Fill Points · 30, 31, 32, 35 Failure · 25, 33, 34, 35, 88 Averaging Time · 37, 101 Field ·...
Page 120 ® COMPASS FOR PPC/RPM™ USER’S MANUAL New DMM · 44 Save · 20, 23, 29, 53, 63, 64, 65, 79 New DUT · 21 SCPI · 45, 82, 84 New Reference · 41, 42 Search · 62, 71, 73 Notes · 1, 2, 10, 11, 20, 38, 52, 77, 78, 90, 92, 98 Secondary Test ·...
