Summary of Contents for Fishman SBT-C
- Page 1 USER GUIDE...
-
Page 2: Read Me First
10 feet without signal deterioration. Use a high quality, low capacitance ¼” shielded instrument cable (models SBT-HP and SBT-E) or the provided cable (SBT-C). This will ensure minimal tone coloration and hum. - Page 3 Installing the Model SBT-C Parts • SBT-C Pickup with ⁄ ” Shielded Jack • (3) Double-sided Adhesive Pads • Adhesive-backed Jack Holder • Felt-covered Strain Relief Clip • 10’ Instrument Cable 1.5” 1.5”...
- Page 4 Preparation The model SBT-C may be mounted onto a classical guitar, a steel string guitar, a dulcimer and similar stringed instruments. The installation may be performed either on the outside of the instrument or inside the soundhole where the transducer will be out of harm’s way. In instruments with small soundholes (dulcimers, for example), internal installation may not be practical.
- Page 5 below the highest pitched string noting the position where these two measure- ments meet. This will serve as a test location. 2. Apply an adhesive pad to the shiny brass face of the transducer and mount at the location indicated in step 1. The transducer wire should follow the grain of the soundboard and point toward the soundhole of the instrument.
- Page 6 adjacent to the soundhole. 5. Insert the jack into the jack holder and plug the instrument cable into the jack. 6. Attach the felt-covered strain relief clip to the soundhole. Note: The felt-covered clip can be bent to accommodate different soundhole thicknesses.
- Page 7 Installing the Model SBT-E Follow the same procedure as the Model SBT-C on page 3 to mount the pickup element. Parts: • SBT-E Pickup • ¼” Fishman Switchjack stereo endpin jack • (3) Double-sided Adhesive Pads...
- Page 8 Install the pickup 1. Widen the endpin hole to 15/32” (11.9mm) to accommodate the endpin jack. For additional information, please refer to the Switchjack Installation Guide located at fi shman.com. 2. Solder the pickup “hot” wire to the Tip terminal, which is the shortest of the three tabs.
- Page 9 Installing the Model SBT-HP The Model SBT-HP is designed for harp or piano. Parts • SBT-HP with 42” Cord and ¼” Jack • (3) Double-sided Adhesive Pads • Adhesive-backed Jack Holder As a general rule, the transducer should be mounted over a freely vibrating location and not over a “dead”...
- Page 10 2. Apply an adhesive pad to the shiny brass face of the transducer and mount outside the instrument, at the location indicated in step 1. The transducer wire should follow the grain of the soundboard and point toward the bottom of the instrument.
- Page 11 For piano mounting The SBT-HP should be mounted to the piano soundboard at a location adjacent to the higher strings. For example, on a grand piano the transducer should be placed directly on the soundboard within the third-largest ranges of the piano. For additional instructions, see the above information for harp mounting.
- Page 12 www.fi shman.com 009-030-001 Rev D 5-10...
