- Page 1 CX6134 Clex prime wall mounted reader for outdoor use Only for versions with 2.4 GHz Bluetooth ® Low Energy Operating and assembly instructions...
- Page 2 CX6134 ABLE OF CONTENTS Legal Notice Operating and assembly instructions (original language) Wall mounted reader for outdoor use CX6134 (Instructions only for version with 2.4 GHz Bluetooth ® Low Energy) Document number: Version: 1.5 As per: 01.08.2022 Manufacturer Uhlmann & Zacher GmbH Gutenbergstraße 2–4...
- Page 3 CX6134 ABLE OF CONTENTS Table of contents About this document .................3 Warnings .................... 3 Symbols ....................3 Safety .....................4 Proper use ..................4 Improper use ..................4 General safety information ..............4 Product description ................5 Functional description ................5 Layout and scope of delivery ..............6 Technical data ..................
- Page 4 About this document These operating and assembly instructions describe the Clex prime wall mounted read- er for outdoor use (in short: CX6134). They are part of the product and contain im- portant information necessary for correct operation and maintenance. These operating and assembly instructions only apply for the version with 2.4 GHz...
- Page 5 Safety Proper use The CX6134 wall mounted reader is used to switch potential-free contacts (e.g. for electric door openers, electric locks, electric door and gate drives, elevators) by means of a contactless key held in front (passive transponder) or by actuating an active tran- sponder or, in the case of online devices, by pressing a button in the Keyvi software.
- Page 6 Product description Functional description The CX6134 wall mounted reader for outdoor use is a product in the Clex prime sys- tem. The entire electronics including switched-mode power supply, key reading unit, evaluation, control unit and switching relay are located in one compact unit. The product is specially designed for outdoor use and withstands harsh weather conditions.
- Page 7 CX6134 RODUCT DESCRIPTION Layout and scope of delivery Cable gland Sealing element Bottom part of housing Electronic knob Electronics (similar diagram) Technical data 3.3.1 General technical data Designation Value Product number CX6134 Power supply Supply voltage 8-40V DC or 8–24 V AC Power consumption typ.
- Page 8 –25 °C to +65 °C ture Storage temperature –40 °C to +65 °C Installation location Outdoors Protection class IP67 3.3.3 Standards The CX6134 wall mounted reader for outdoor use complies with the following stand- ards: EN 60529:2014 2011/65/EU 2014/53/EU...
- Page 9 CX6134 RODUCT DESCRIPTION 3.3.4 Drawings...
- Page 10 CX6134 OMMISSIONING Commissioning Management accessories The components of the Clex prime system described below are used to manage a Clex prime locking system. 4.1.1 CX6530 Keyvi management software The Keyvi management software for Clex prime enables the locking system to be man- aged centrally and conveniently from the PC.
- Page 11 CX6134 OMMISSIONING The following settings can be changed: Authorizations Time Time zones Switching time (determines how long the wall mounted reader remains switched af- ter an authorized key has been held in front). Expiry date of a key ...
- Page 12 CX6134 ONNECTION AND ASSEMBLY Connection and assembly General assembly information The electrical installation for the wall mounted reader must be carried out in ac- cordance with the connection diagrams and technical data of the devices to be controlled. ...
- Page 13 CX6134 ONNECTION AND ASSEMBLY Connection diagram Contact number Assignment 1 + 2 Power supply (any polarity) 3 + 4 Manipulation switch (any polarity) Relay K3, NO contact 5 + 6 (if equipped, any polarity) Relay K2, NO contact 7 + 8...
- Page 14 CX6134 ONNECTION AND ASSEMBLY Assembly Screw the housing finger-tight with the corresponding screws. Align the housing in the correct position and then screw tight. To do this, open the two screw covers outward. After assembly, close again until the covers audibly snap...
- Page 15 CX6134 PERATION Operation Operation with IDs authorized for locking e.g.: Transponder card Transponder fob Transponder key Smartphone app Switching wall mounted reader briefly Hold the authorized key (transponder or card) in the center in front of the reading unit.
- Page 16 CX6134 PERATION The wall mounted reader is now permanently switched. To cancel the toggle function, repeat the procedure. Signaling Function Signal (acoustic and optical) and explanation Not personalized LEDs flash alternately red/green Sleep mode (Personalized) LED flashes red Service mode ●...
- Page 17 CX6134 ALFUNCTIONS DURING OPERATION Malfunctions during operation Error signaling Function Acoustic signal Explanation Memory error/ 5 long tones ▬ ▬ ▬ ▬ ▬ ● 1 short tone configuration error 5 long tones Coupling error ▬ ▬ ▬ ▬ ▬ ● ●...
- Page 18 CX6134 ISASSEMBLY AND DISPOSAL Disassembly and disposal Disassembly Remove the two fixing screws of the wall mounted reader and remove it from the wall. Loosen the housing screw connections and lift the upper part of the housing. Disconnect terminal strips from the wall mounted reader and remove the wiring.
- Page 19 CX6134 ISASSEMBLY AND DISPOSAL Disposal Do not dispose of the wall mounted reader with household waste, but at a munici- pal collection point for special electrical waste in accordance with European Di- rective 2002/96/EC. Dispose of packaging for environmentally friendly recycling.
- Page 20 CX6134 LOSSARY Glossary Term Explanation ClexTouch Software for Windows handheld computers for configuring a locking system Intruder detection system Gira Brand name of a switch and housing series of the company Gira Giersiepen GmbH & Co. KG HITAG1 Technology for contactless transmission of identification...
