3200W Electric Leaf Blower

L772

v001: 17/04/23

Please read and retain these instructions for future reference

Power Details:

Net weight:

No load speed:

Max air volume:

Max. air speed

3 in 1 function

Mulching ratio:

Cable:

Sound pressure level LPA: 95dB(A), Kpa: 3.0dB(A)

Sound power level LWA:

Vibration:

Assembled size:

Use: This item requires one hand to use safely.

Please read this instruction manual thoroughly before starting and ensure you are

familiar with the operation of your new Electric Leaf Blower.

RECOMMENDED FOR PERSONS OVER 18 YEARS OF AGE.

ALWAYS USE HEAD, EYE AND EAR PROTECTION EQUIPMENT AND SAFETY SHOES

The Enterprise

Department

220-240V

Class II

3200W

50Hz

3.3kg

6000-14000 rpm

14m

/min

270km/h

35L collection bag

Vacuum, blower, mulcher

10:1

H05VV-F 2x0.75mm

110db(A)

4.95m/s

128(L)x16(W)x27(H)cm

AND HAND GLOVES

UK Head Office, 11 Bridge Street, Bishop's Stortford, CM23 2JU

Tel: 0330 331 0300

Fax: 01279 756595

www.coopersofstortford.co.uk

EU address: D.S.B. LD, 160 Bd. de Fourmies, 59100 Roubaix, France

Tel: (+44) 1279 701269

with BS plug length: 10m
