- Page 1 ELECTRICAL VEHICLES USER MANUAL VM5 NEO www.volta.com.tr Please read this user manual carefully before using your vehicle!
- Page 2 All these components have placed Volta Motor vehicles at the top ranks in the list of high-quality transportation options in the modern world. This user manual will provide you with notes, warnings, suggestions, and information regarding usage, adjustments, and maintenance.
- Page 3 • After purchasing your e-bike, you must take it to the nearest authorized service for its first maintenance within 1 month. Pre-Use Warnings • Do not attach yourself or your bike to any vehicle. Do not ride with one hand. Only lift your feet off the pedals if road conditions require it. www.volta.com.tr...
- Page 4 ..................INTRODUCTION TO ELECTRIC VEHICLES ........................PRE-USE INSTRUCTIONS ......................DEFINITIONS AND SYMBOLS ........................SAFETY INFORMATION ........................... GENERAL VIEW ........................ACTUATION AND USAGE ......................MAINTENANCE AND CONTROL ......................STROAGE AND REACTIVATING ......................TECHNICIAL SPECIFICATIONS ....................MANUFACTURER INFORMATION ............................WARRANTY ..........................FINAL INSPECTION www.volta.com.tr...
- Page 5 Our VM5 Neo model falls under the L2e-P classification, which includes light three-wheeled motorcycles powered by electricity. Vehicles in the L2e-P category cannot exceed a maximum speed of 45 km/h and use motors with a power output of up to 4 kW (approximately 5.4 horsepower).
- Page 6 2. PRE-USE INSTRUCTIONS 2.1. Review the User Manual Carefully Before using your electric motorcycle, carefully read the user manual. The manual prepared by Volta Motor contains essential information about your vehicle and important precautions to follow. This manual is crucial for both rider safety and the proper functioning of the motorcycle.
- Page 7 Communication: Use signals and eye contact to communicate with other riders. • Stay Alert: Continuously observe other vehicles and road conditions. Regularly check your mirrors and assess your surroundings. • Following these instructions will provide a safer and more efficient riding experience. www.volta.com.tr...
- Page 8 This label contains the identification numbers specific to your motorcycle. Ensure that the L2e-P e5*168/2013*????? NPPMVHG5????????? numbers on the vehicle’s chassis plate match those on the certificate of conformity. -- dB(A) - --min 1.0kW 25km/h max 352kg www.volta.com.tr...
- Page 9 This symbol indicates that you should read the operating instructions. Products marked with this symbol meet all applicable European Economic Community regulations. www.volta.com.tr...
- Page 10 “ Ampere Electrik Current Ampere hour Energy Capacity Pressure Gram Mass Hour Time Hertz Frequency Kilogram Mass km/h Kilometre/hour Speed Kilopascal Pressure Speed Newton meter Torque inçkareye pound Pressure Volt Electric Voltage Watt Electric Power Watt saat Electric Capacity www.volta.com.tr...
- Page 11 Declaration of Conformity for the motorcycle to be sold. CAUTION The Certificate of Conformity is delivered with your vehicle. When receiving your vehicle, the Certificate of Conformity should be checked. It is essential to ensure that the document is not missing or incorrect/different. www.volta.com.tr...
- Page 12 • Receive proper training on correct and safe riding techniques. • When mechanical attention is required or indicated in the user manual, seek service from authorized Volta Motor technical service centers. • Do not operate the motorcycle without proper knowledge or training. Until you are fully familiar with your motorcycle and all of its functions, we recommend practicing in areas without traffic.
- Page 13 • Check their operation. • If necessary, have them serviced at an authorized Volta Motor service center. f. Riding Equipment and Controls • Riding Mode: Check the riding mode of the electric motorcycle. Verify whether there are any speed limits or special riding modes activated.
- Page 14 Handlebar and Grip: Check that the handlebars are working properly. Make sure that the grip is firm and secure. Without proper inspection or maintenance, the risk of accidents and equipment damage increases. Do not use your motorbike if you detect any problems. Have your vehicle checked by Volta Motor authorised services for any problems. 4.1.2. Important Considerations •...
- Page 15 Using non-original spare parts may not meet factory standards in terms of quality and compatibility, and can lead to unexpected malfunctions or damage. As a result, do not use non-original spare parts or accessories for your Volta Motor vehicle. Any damage caused by non-original parts will void your vehicle’s warranty.
- Page 16 • • Avoid large water puddles that may form during rainy weather. Avoid large water puddles that may form during rainy weather. • • Never ride under the influence of alcohol or drugs. Never ride under the influence of alcohol or drugs. www.volta.com.tr...
- Page 17 Ensure that your electric bike is regularly maintained. • Adhere to the maximum load limits specified in the manual. • Make sure to use the bike under appropriate weather and road conditions. • Check that your tire pressures are within the recommended range. www.volta.com.tr...
- Page 18 4. Ignition Key and Slot 5. Charging Port and Under Passenger Seat Compartment (Battery and Fuse Compartment) 6. Rear Wheel Rear Basket CAUTION The parts listed in the user manual are provided as a reference. The manufacturer may make changes without prior notice. www.volta.com.tr...
- Page 19 3. Front Rider Seat 4. Hand Brake 5. Handlebar 6. Foot Brake Wiper 8. Right Front Turn Signal and Headlight CAUTION The parts listed in the user manual are provided as a reference. The manufacturer may make changes without prior notice. www.volta.com.tr...
- Page 20 Position lamp Driving beam Reversing Direction indicator Ready to start READY km/h TRIP Speedometer Gear Low battery display Odometer CAUTION The parts listed in the user manual are provided as a reference. The manufacturer may make changes without prior notice. www.volta.com.tr...
- Page 21 Battery The battery indicator shows the current battery level of the motorcycle. The battery level should be monitored using this indicator to ensure the charging cycle is maintained. www.volta.com.tr...
- Page 22 The odometer shows the total distance traveled by the motorcycle in kilometers. This information is essential for tracking maintenance and service intervals. Speedometer The speedometer displays the current speed of the motorcycle in kilometers per hour (km/h). You can monitor your vehicle’s speed using this indicator. www.volta.com.tr...
- Page 23 Passing beam Driving beam Gear Direction indicator Horn Drive/Reverse www.volta.com.tr...
- Page 24 The forward/reverse button is used to determine the direction of the motorcycle’s movement. The forward position allows the motorcycle to move forward normally; the reverse position enables it to move backward. This button should only be used while the motorcycle is stationary, and direction changes should be made carefully. www.volta.com.tr...
- Page 25 NOTE The windshield washer reservoir has a capacity of 1000 ml. Be careful not to exceed this capacity during refilling. Windscreen wiping system Windscreen Washer wiper motor Windscreen Washer "off" kettle volume is 1000ml Windscreen wiping system "off " www.volta.com.tr...
- Page 26 Never turn the ignition key to the off position while riding the motorcycle. Doing so may shut down the electrical systems, leading to a loss of control or a potential accident. ON Position 2. OFF Position 3. Steering Lock Transition Range 4. Ignition Key Slot 5. Steering Lock Position www.volta.com.tr...
- Page 27 • To unlock the handlebar; Insert the ignition key into the slot. While the ignition is in the “5” LOCK position, press the key and turn it back through the transition range marked as “3” to the “2” OFF position. The handlebar will be unlocked, and you can then switch to the desired position and operate the vehicle. www.volta.com.tr...
- Page 28 To use the foot brake, press it forward with your foot. Release the foot brake slowly to stop braking. It is recommended to use both the hand and foot brakes simultaneously. Always release the throttle grip before applying the brakes. www.volta.com.tr...
- Page 29 • Brake pads should always be replaced with original parts. Low-quality components may damage other parts of the vehicle and affect overall performance. • The braking system is critical for your safety. Always have it inspected and adjusted regularly by authorized service centers according to the periodic maintenance schedule. www.volta.com.tr...
- Page 30 Following these guidelines will enhance your motorcycle’s performance and extend its lifespan. WARNING • Do not operate the engine in the red zone of the RPM gauge. • If you encounter any issues during the break-in period, contact an authorized Volta Motor service center as soon as possible. 6.5. Parking When parking your motorcycle, turn off the power.
- Page 31 • Avoid excessively increasing the electric motor’s RPM during acceleration. • Operating at high RPM increases energy consumption. • During extended stops due to loading, traffic, or waiting, switch off the electric motorcycle instead of leaving it powered on. www.volta.com.tr...
- Page 32 VOLTA MOTOR SAN. VE TIC. A.S. L2e-P e9*168/2013*????? ☆ NPPMVHG5? ???????? ☆ -- dB(A)- -- min 1.0 kW 25 km/h max 352 kg Chassis Plate Location www.volta.com.tr...
- Page 33 • This electric motorcycle is designed solely for use on paved roads. If used in extremely dusty, muddy, or wet environments, the air filter element should be cleaned or replaced more frequently. Otherwise, the electric motor may wear out prematurely. For accurate maintenance intervals, please consult authorized Volta Motor service centers. www.volta.com.tr...
- Page 34 The battery is located just behind the plastic protective cover under the seat. The battery connections should be checked and replaced with the correct connections if necessary. • Black Cable: Negative terminal connection • Red Cable: Positive terminal connection www.volta.com.tr...
- Page 35 • Keep waste batteries away from children. If the battery is drained, have it charged at an authorized Volta Motor service center as soon as possible. If additional accessories are installed on your motorcycle, keep in mind that the battery may drain more quickly.
- Page 36 • Using a fuse with a lower rating than specified may cause the system to trip continuously. Using a fuse with a higher rating than specified can lead to electronic component failure and cable damage due to excessive current. www.volta.com.tr...
- Page 37 It is recommended that replacements be performed using original spare parts by Volta Motor authorized service centers. Safety level checks and replacements should be carried out by authorized service providers. Brake pads that are not replaced can cause the brake system to operate with low performance, create noise, and in some cases, even damage other components.
- Page 38 • When the tread depth is worn down, or if there are nails, glass shards, or cracks on the sidewalls of the tires, you can have your tires replaced at an authorized Volta Motor service center. • The front and rear tires should be of the same brand, pattern, and series; otherwise, it may negatively affect the motorcycle’s handling characteristics.
- Page 39 Tires with low tread depth will reduce grip, especially on wet surfaces. The minimum tread depth is 2.0 mm for the front tire and 2.0 mm for the rear tire. These situations may lead to accidents. www.volta.com.tr...
- Page 40 NOTE • The position of the tire information label on the vehicle is marked on the image on the right. www.volta.com.tr...
- Page 41 7.6. Thorttle Adjustment The throttle should be checked for proper operation before each ride. Additionally, the throttle cable should be lubricated at the intervals specified in the periodic maintenance table, preferably by a Volta Motor authorized service center. • Check that the throttle moves freely from the lowest to the highest position.
- Page 42 Periodic maintenance should be performed by authorized Volta Motor service centers. The interval between two maintenance must not exceed 4 months or 2,000 km (whichever comes first). Vehicles not complying with the maintenance intervals will not be covered by the warranty.
- Page 43 Check that it does not produce any disturbing noise while Rear Suspension operating and ensure there are no oil leaks. Check the operation and throttle play; adjust if necessary. Throttle Grip Charger and Check the operation and connections. Socket Chain (If Equipped) Check its operation and connections. www.volta.com.tr...
- Page 44 Therefore, all bolts and nuts of the components will be tightened, and general checks will be performed. • The reliability of your vehicle depends on the proper completion of the initial use and the first periodic maintenance. www.volta.com.tr...
- Page 45 • Cover the motorcycle with a dry cover made from materials that are not plastic or rubber. Be mindful of storing it in a place where temperature changes are minimal. Extreme fluctuations in temperature can cause wear, damage, or cracking of various components of the motorcycle. www.volta.com.tr...
- Page 46 When calculating the load capacity of your vehicle, include all weight being carried — this includes the rider, any passenger, and all transported items. • Overloading the vehicle will make operation more difficult and shorten its lifespan. • Please do not exceed the maximum load limit specified in your technical documentation. www.volta.com.tr...
- Page 47 When transporting your electric vehicle, make sure that the ignition and the fuse are in the OFF position. To prevent any external damage to your vehicle, it is recommended to transport it securely on a metal frame covered with cardboard padding. 8.4. Assembly Your vehicle is delivered to you fully assembled. www.volta.com.tr...
- Page 48 Arka Tekerlek Ebat 3.00-10 Batarya Kapasitesi 72V 20Ah Yük Hız Endeksi Batarya Ağırlığı 36 Kg Lastik Hava Basıncı Batarya Tipi VRLA Jel Akü Ön Lastik 250kPa / 31 psi Şarj Süresi 6-8 Saat Arka Lastik 250kPa / 36 psi Tırmanma Kapasitesi www.volta.com.tr...
- Page 49 10. Manufacturer Information The service life of your Volta brand vehicle is 10 years, and the maximum repair period is 45 working days. If you encounter any problems with your vehicle, you can visit our website www.volta.com.tr and access information about authorized services and spare parts.
- Page 50 www.volta.com.tr...
- Page 51 You can scan the QR code below to choose the nearest sales point and get in touch. SALES You can scan the QR code below to choose the nearest service center and get in touch. SERVICE www.volta.com.tr...
- Page 52 www.volta.com.tr...
- Page 53 22. Battery swelling due to overcharging or sulphation due to non-compliance with charging rules 23. The faults during the warranty period must be repaired within the scope of the warranty by contacting the authorised services with the warranty certificate and user manual. www.volta.com.tr...
- Page 54 • Hail, storm, flood, lightning, and other natural disasters. • Cosmetic conditions, scratches in the paint. 10. During the warranty period, you should apply to our authorised service stations with the warranty certificate and user manual for the repair of malfunctions within the scope of the warranty. www.volta.com.tr...
- Page 55 15. Rear lights and brake lights are operational 16. Fuel gauge is working 17. Oil warning light is functioning correctly 18. Turn signals (flashers) are working 19. Control buttons are functioning 20. Start button is working VEHICLE OWNER NAME PHONE SIGNATURE www.volta.com.tr...
- Page 56 Has the motorcycle owner been advised that the engine oil should be checked every 1,000 km? Has the motorcycle owner been instructed on the contents of the user manual and advised to read it? VEHICLE OWNER NAME PHONE SIGNATURE www.volta.com.tr...
- Page 57 NOTES ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................www.volta.com.tr...
- Page 58 NOTES ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................www.volta.com.tr...
- Page 59 VM5 NEO Yaka Mah. 401. Sok, No: 19, 0380 731 25 25 0850 222 28 65 0850 222 28 65 0850 222 28 65 www.volta.com.tr www.volta.com.tr...
